FCC ID K6620523X51
ANALOGUE SCANNING RECEIVER
by Yaesu Musen Co., Ltd.
Grantee Code: K66 Product Code: 20523X51
Latest application date: 2016-03-11
Device Images
FCC ID Device Details
| FCC ID | K6620523X51 |
|---|---|
| Mirrors | fcc.id | gov | fccid.ai |
| Grantee Code | K66 |
| Product Code | 20523X51 |
| Applicant Business | Yaesu Musen Co., Ltd. 🇯🇵 |
| Related Domains |  yaesu.com  timcoengr.com |
| Equipment Class | ANALOGUE SCANNING RECEIVER |
| Test Firm | Timco Engineering, Inc. |
Operating Frequencies
| Frequency Range | Application Purpose | Final Action Date |
|---|---|---|
| 136-174 MHz | Original Equipment | 2016-03-11 |
Exhibits
| Document | Type | Available | File |
|---|---|---|---|
| User Manual | Users Manual | 2016-09-07 | PDF 905 KB |
| External Photos | External Photos | 2016-09-07 | PDF 1.8 MB |
| Label sample and location | ID Label/Location Info | 2016-03-11 | PDF 746.1 KB |
| Test set up photos | Test Setup Photos | 2016-03-11 | PDF 326 KB |
| Test set up photos | Test Setup Photos | 2016-03-11 | PDF 875.3 KB |
| Test Report | Test Report | 2016-03-11 | PDF 1.9 MB |
| Test Report | Test Report | 2016-03-11 | PDF 717.2 KB |
| Attestation Statement | Attestation Statements | 2016-03-11 | PDF 64.5 KB |
| Compliance Statement | Cover Letter(s) | 2016-03-11 | PDF 64.5 KB |
| Confidentiality request letter | Cover Letter(s) | 2016-03-11 | PDF 129 KB |
| Internal Photos Metadata only | Internal Photos | PDF 3.4 MB | |
| Block Diagram Metadata only | Block Diagram | PDF 407.7 KB | |
| Schematic - Main Unit Metadata only | Schematics | PDF 2.1 MB | |
| Schematic - Panel Unit Metadata only | Schematics | PDF 1.4 MB | |
| Schematic -Main unit Metadata only | Schematics | PDF 2.1 MB | |
| Operational Description Metadata only | Operational Description | PDF 86.8 KB | |
| Parts List Metadata only | Parts List/Tune Up Info | PDF 83.8 KB |
Application Information
| Application ID | xhggYwHlqY73oeZqJOI1ng== |
|---|---|
| Final Action Date | 2016-03-11 |
| Application Purpose | Original Equipment |
| Applicant FRN | 0013655220 |
| Model | 20523X51 |
| Equipment Class | JBC - Part 15 Class B Computing Device/Personal Computer |
| Device Description | ANALOGUE SCANNING RECEIVER |
| Responsible Party | Tetsuya Masubuchi, Engineering Division/Quality Assurance Leader, t.masubuchi@yaesu.com , 81-3-6711-4121 |
| Technical Contact | Chrisitan Pawlak, Timco Engineering, Inc., tei@timcoengr.com , 8884272424 |
| Non-Technical Contact | Sharon Hoffman, Timco Engineering, Inc., tei@timcoengr.com , 888-472-2424 |
| Test Firm | Bruno Clavier, Timco Engineering, Inc., bruno@timcoengr.com , 352-472-5500 |
| TCB Email | tei@timcoengr.com |
| TCB Scope | A1: Low Power Transmitters below 1 GHz (except Spread Spectrum), Unintentional Radiators, EAS (Part 11) & Consumer ISM devices |
| Short-Term Confidentiality | Yes |
| Short-Term Confidentiality Date | 09/07/2016 |
| Long-Term Confidentiality | Yes |
| Grant Deferral | No |
| Modular Equipment | Does not apply |
| Composite Device | Yes |
| Composite Part | No |
| Cognitive Radio | No |
| Authorization Waiver | No |
| Authorization Waiver Approved | No |
| Section 5301 Certification | Yes |
| Related OET Knowledge DataBase Inquiry | No |
Applications
| Application ID | Date | Purpose |
|---|---|---|
| xhggYwHlqY73oeZqJOI1ng== | 2016-03-11 | Original Equipment |
| 0QmhpPWF8JnySlGUmialvw== | 2016-03-11 | Original Equipment |
Equipment Authorization
| Frequency | Rules |
|---|---|
| 136-174 MHz | 15B |
Grants
TCB Grant - Application xhggYwHlqY73oeZqJOI1ng==
| TCB | GRANT OF EQUIPMENT AUTHORIZATION |
TCB |
| Certification | ||
| Issued Under the Authority of the | ||
| Federal Communications Commission | ||
| By: |
|
Timco Engineering, Inc. 849 NW State Road 45 Newberry, FL 32669 |
Date of Grant: 03/11/2016 Application Dated: 03/11/2016 |
| Yaesu Musen Co., Ltd. |
| Tennozu Parkside Building |
| 2-5-8 Higashi-Shinagawa, Shinagawa-ku |
| Tokyo, 140-0002 Japan |
| Attention: Tetsuya Masubuchi , Engineering Division/Quality Assurance Leader |
| NOT TRANSFERABLE |
| EQUIPMENT AUTHORIZATION is hereby issued to the named GRANTEE, and is VALID ONLY for the equipment identified hereon for use under the Commission's Rules and Regulations listed below. |
| FCC IDENTIFIER: | K6620523X51 |
| Name of Grantee: | Yaesu Musen Co., Ltd. |
| Equipment Class: | Part 15 Class B Computing Device/Personal Computer |
| Notes: | ANALOGUE SCANNING RECEIVER |
| Grant Notes | FCC Rule Parts | Frequency Range (MHZ) | Output Watts | Frequency Tolerance | Emission Designator |
| 15B | - |
