20761X50 Scanning Receiver Test Setup Photos - FCC ID K6620761X50
FCC ID K6620761X50
Test Setup Photos
Scanning Receiver
Document preview loads when visible.
Document Details
| FCC ID | K6620761X50 |
|---|---|
| Document ID | 4975639 |
| Document Type | Test Setup Photos |
| Description | Test Setup Photos |
| Applicant | Yaesu Musen Co., Ltd. |
| Equipment Class | Scanning Receiver |
| Product Code | 20761X50 |
| Application ID | Pg7CGNwcXiRiCyNAJzDISA== |
| Application Purpose | Original Equipment |
| Application Date | 2020-11-04 |
| Frequency Range | 0.03-75 MHz |
| FRN | 0013655220 |
| Test Firm | SGS Japan Inc. Yokohama Lab |
| Certified By | Tetsuya Masubuchi Engineering Division / Quality Assurance |
| Short-Term Confidentiality | No |
| Long-Term Confidentiality | No |
| Short-Term Confidentiality Date | 12/19/2020 |
| Grant Deferral | No |
| Modular Equipment | Does not apply |
| Composite Device | No |
| Composite Part | No |
| Submitted | 2020-10-30 |
| Available | 2020-12-19 |
| Created | 2020-10-26 |
| Modified | 2020-10-27 |
| Pages | 2 |
| File Type | Adobe Acrobat PDF |
| File Size | 999117 |
| File SHA-256 | f8cd4c9d961a579bfd83cc2a1e33f82ab5e7237694ba1c6ce013c0d9f6e962be |
| PDF Metadata Producer | Antenna House Shunkan PDF Sakusei 7 䥫楮慲椠偄䘠㘮〮㈮〻潤楦楥搠畳楮朠楔數琠㈮ㄮ㜠批‱吳塔 |
| FCC.gov Sources | FCC.gov 4975639 |
