20825X22 Scanning receiver Test Setup Photos - FCC ID K6620825X22

FCC ID K6620825X22

Test setup photo

Scanning receiver

by Yaesu Musen Co., Ltd.

Document preview loads when visible.

Document Details

FCC IDK6620825X22
Document ID8418136
Document TypeTest Setup Photos
DescriptionTest setup photo
Document TitleTest Report_FCC15B_CSR_FT5DRx
ApplicantYaesu Musen Co., Ltd.
Equipment ClassScanning receiver
Product Code20825X22
Application IDRvzC4L0nTW2Jv2+eYLoXqg==
Application PurposeOriginal Equipment
Application Date2025-06-25
Frequency Range0.52-985 MHz
FRN0013655220
Test FirmSGS Japan Inc.
Certified ByMasatoshi Muraishi Engineering Division
Short-Term ConfidentialityNo
Long-Term ConfidentialityNo
Short-Term Confidentiality Date12/23/2025
Grant DeferralNo
Modular EquipmentDoes not apply
Composite DeviceYes
Composite PartNo
Submitted2025-06-25
Available2025-12-23
Created2025-05-26
Modified2025-05-28
Pages2
File TypeAdobe Acrobat PDF
File Size1586150
File SHA-256e0fd84f9f5f12054ff485ee5d18f42c4994f2ab9e4cefa70aa65ff70ce216f2b
PDF Metadata AuthorAtsushi Tamura
PDF Metadata ProducerAntenna House Shunkan PDF Sakusei 7 Microsoft: Print To PDF; modified using SignServer
FCC.gov SourcesFCC.gov 8418136
