GX1280S VHF FM Marine Transceiver Label Diagram - FCC ID K66GX1280S
FCC ID K66GX1280S
label drawing
VHF FM Marine Transceiver
Document preview loads when visible.
Document Details
| FCC ID | K66GX1280S |
|---|---|
| Document ID | 322205 |
| Document Type | ID Label/Location Info |
| Description | label drawing |
| Document Title | K66GX1280S_Label.cdr |
| Applicant | Yaesu Musen Co., Ltd. |
| Equipment Class | VHF FM Marine Transceiver |
| Product Code | GX1280S |
| Application ID | Vcy90nUa8WgQHjLkXLz3Dw== |
| Application Purpose | Original Equipment |
| Application Date | 2003-05-01 |
| Frequency Range | 156.025-157.425 MHz |
| FRN | 0013655220 |
| Test Firm | M. Flom Associates, Inc. |
| Certified By | Tomiro Ohmoto General Manager, Export |
| Short-Term Confidentiality | No |
| Long-Term Confidentiality | No |
| Grant Deferral | No |
| Modular Equipment | Does not apply |
| Composite Device | No |
| Composite Part | No |
| Submitted | 2003-05-01 |
| Available | 2003-05-01 |
| Created | 2003-03-21 |
| Modified | 2003-03-21 |
| Pages | 1 |
| File Type | Adobe Acrobat PDF |
| File Size | 1273550 |
| File SHA-256 | f6bd1a13e0edb469427cd1cf6cf682490a2ec651cdc9f25d5a44dfd71f6976ed |
| PDF Metadata Author | Moto Kurihara |
| PDF Metadata Producer | Corel PDF Engine Version 10.427 CorelDRAW バージョン 10.0 |
| FCC.gov Sources | FCC.gov 322205 |
