0114405 Keypad Proximity Reader Test Setup... - FCC ID K830114405
FCC ID K830114405
Test Setup Photos
Keypad Proximity Reader
Document preview loads when visible.
Document Details
| FCC ID | K830114405 |
|---|---|
| Document ID | 630201 |
| Document Type | Test Setup Photos |
| Description | Test Setup Photos |
| Document Title | 630201.DOC |
| Applicant | Matrix Systems Inc |
| Equipment Class | Keypad Proximity Reader |
| Product Code | 0114405 |
| Application ID | dO/ChX25o9mXgoNd+d9yow== |
| Application Purpose | Original Equipment |
| Application Date | 2006-02-20 |
| Frequency Range | 13.56 MHz |
| FRN | 0013698428 |
| Test Firm | CKC Laboratories, Inc. |
| Certified By | Mary Ellen Clayton Report Writer |
| Short-Term Confidentiality | No |
| Long-Term Confidentiality | No |
| Grant Deferral | No |
| Modular Equipment | Does not apply |
| Composite Device | No |
| Composite Part | No |
| Submitted | 2006-02-20 |
| Available | 2006-02-20 |
| Created | 2006-02-21 |
| Modified | 2006-02-21 |
| Pages | 5 |
| File Type | Microsoft Word |
| File Size | 176477 |
| File SHA-256 | e9a40ada59e85c2f0848e5ea96bdfa7c703db461e4e86ffbb146d2bd5010507a |
| PDF Metadata Author | Administrator |
| PDF Metadata Producer | Acrobat Distiller 5.0.5 (Windows) Administrator |
| FCC.gov Sources | FCC.gov 630201 |
