5401 Radar Level Gauge External Photos - FCC ID K8C5401
FCC ID K8C5401
External Photos
Radar Level Gauge
Document preview loads when visible.
Document Details
| FCC ID | K8C5401 |
|---|---|
| Document ID | 375906 |
| Document Type | External Photos |
| Description | External Photos |
| Document Title | 375906.DOC |
| Applicant | Rosemount Tank Radar AB |
| Equipment Class | Radar Level Gauge |
| Product Code | 5401 |
| Application ID | UnxwH0nqDigkOGDzOV4IlQ== |
| Application Purpose | Original Equipment |
| Application Date | 2004-01-12 |
| Frequency Range | 6300 MHz |
| FRN | 0025969163 |
| Test Firm | Svenska EMC Lab AB |
| Certified By | Carl Fjelkner Product Manager |
| Short-Term Confidentiality | No |
| Long-Term Confidentiality | No |
| Grant Deferral | No |
| Modular Equipment | Does not apply |
| Composite Device | No |
| Composite Part | No |
| Submitted | 2003-11-25 |
| Available | 2004-01-12 |
| Created | 2003-11-25 |
| Modified | 2003-11-25 |
| Pages | 7 |
| File Type | Microsoft Word |
| File Size | 3958273 |
| File SHA-256 | ee3d7c5fa7bc4552e923ef10805fa048bfc81444e5d391c71c00273ec2a80a4c |
| PDF Metadata Author | fcc |
| PDF Metadata Producer | Acrobat Distiller 5.0.5 (Windows) fcc |
| FCC.gov Sources | FCC.gov 375906 |
