FCC ID KA2AP1650A1
Wireless AC1200 Dual Band Gigabit Range Extender
by D-Link Corporation
Grantee Code: KA2 Product Code: AP1650A1
Latest application date: 2016-01-19
Device Images
FCC ID Device Details
Operating Frequencies
| Frequency Range | Application Purpose | Final Action Date |
|---|---|---|
| 5180-5240 MHz | Class II permissive change or modification of presently authorized equipment | 2016-01-19 |
| 2412-2462 MHz | Original Equipment | 2013-08-02 |
| 5180-5240 MHz | Original Equipment | 2013-08-02 |
Exhibits
| Document | Type | Available | File |
|---|---|---|---|
| User Manual.pdf | Users Manual | 2016-01-19 | PDF 295.4 KB |
| User Manual.pdf | Users Manual | 2013-08-02 | PDF 295.4 KB |
| Internal Photos.pdf | Internal Photos | 2016-01-19 | PDF 1,023 KB |
| Internal Photos.pdf | Internal Photos | 2013-08-02 | PDF 1.5 MB |
| External Photos.pdf | External Photos | 2016-01-19 | PDF 925.2 KB |
| External Photos.pdf | External Photos | 2013-08-02 | PDF 1.1 MB |
| Label and Location.pdf | ID Label/Location Info | 2013-08-02 | PDF 73.1 KB |
| Test Setup Photo.pdf | Test Setup Photos | 2016-01-19 | PDF 131.4 KB |
| Test Setup Photos.pdf | Test Setup Photos | 2013-08-02 | PDF 511 KB |
| Test Report.pdf | Test Report | 2016-01-19 | PDF 846.7 KB |
| Test Report (DTS).pdf | Test Report | 2013-08-02 | PDF 1 MB |
| Test Report (NII).pdf | Test Report | 2013-08-02 | PDF 423.7 KB |
| Attestation (Channel and Mode Declaration).pdf | Attestation Statements | 2013-08-02 | PDF 31.9 KB |
| Confidentiality Request - Long Term.pdf | Cover Letter(s) | 2016-01-19 | PDF 54.1 KB |
| Cover Letter - Agent Authorization.pdf | Cover Letter(s) | 2016-01-19 | PDF 33.5 KB |
| Cover Letter - Contact Authorization.pdf | Cover Letter(s) | 2016-01-19 | PDF 185.8 KB |
| Cover Letter - Description of Change.pdf | Cover Letter(s) | 2016-01-19 | PDF 44.5 KB |
| Confidentiality Request.pdf | Cover Letter(s) | 2013-08-02 | PDF 39.1 KB |
| Cover Letter (Agent Authorization).pdf | Cover Letter(s) | 2013-08-02 | PDF 36.3 KB |
| Cover Letter (Contact Authorization).pdf | Cover Letter(s) | 2013-08-02 | PDF 185.6 KB |
| RF Exposure Information (MPE).pdf | RF Exposure Info | 2016-01-19 | PDF 341.5 KB |
| RF Exposure Info (MPE).pdf | RF Exposure Info | 2013-08-02 | PDF 61.3 KB |
| Block Diagram.pdf Metadata only | Block Diagram | PDF 170.3 KB | |
| Schematics.pdf Metadata only | Schematics | PDF 439.3 KB | |
| Software Operating Description.pdf Metadata only | Operational Description | PDF 154.2 KB |
Application Information
| Application ID | IQOoJfUVAHqUGXzjctpoDQ== |
|---|---|
| Final Action Date | 2016-01-19 |
| Application Purpose | Class II permissive change or modification of presently authorized equipment |
| Applicant FRN | 0007371172 |
| Model | AP1650A1 |
| Frequency Range | 5180-5240 MHz |
| Equipment Class | NII - Unlicensed National Information Infrastructure TX |
| Device Description | Wireless AC1200 Dual Band Gigabit Range Extender |
| Responsible Party | Brett Adair, General Counsel, brett.adair@dlink.com  , 714-885-6282 |
| Test Firm | Richard Chen, Bureau Veritas CPS (H.K.) Ltd., Taoyuan Branch, richard.chen@bureauveritas.com  , +886-3-2600884 |
| TCB Email | certification@curtis-straus.com  |
| TCB Scope | A4: UNII devices & low power transmitters using spread spectrum techniques |
| Short-Term Confidentiality | No |
| Long-Term Confidentiality | Yes |
| Grant Deferral | No |
| Modular Equipment | Does not apply |
| Composite Device | Yes |
| Composite Part | No |
| Cognitive Radio | No |
| Authorization Waiver | No |
| Authorization Waiver Approved | No |
| Section 5301 Certification | Yes |
| Related OET Knowledge DataBase Inquiry | No |
| Grant Comments | Power listed is the maximum combined conducted output power. End-users and responsible parties must be provided with operating and installation instructions to ensure RF exposure compliance. The antenna(s) used for this transmitter must be installed to provide a separation distance of at least 20 cm from all persons and must not be co-located or operating in conjunction with any other antenna or transmitter. Operations in the 5.15-5.25GHz band are restricted to indoor usage only. Class II Permissive Change to update U-NII-1 and U-NII-3 to new rule. |
Applications
| Application ID | Date | Purpose |
|---|---|---|
| IQOoJfUVAHqUGXzjctpoDQ== | 2016-01-19 | Class II permissive change or modification of presently authorized equipment |
| Htg3b7QVJzfu8egO3WqZDA== | 2013-08-02 | Original Equipment |
| DDDLFoHhiD3NzCMUxAMpgQ== | 2013-08-02 | Original Equipment |
Equipment Authorization
Grants
TCB Grant - Application IQOoJfUVAHqUGXzjctpoDQ==
| TCB | GRANT OF EQUIPMENT AUTHORIZATION |
TCB |
| Certification | ||
| Issued Under the Authority of the | ||
| Federal Communications Commission | ||
| By: |
|
Bureau Veritas Consumer Products Services, Inc. One Distribution Center Circle Suite #1 Littleton, MA 01460 |
Date of Grant: 01/19/2016 Application Dated: 01/18/2016 |
| D-Link Corporation |
| 14420 Myford Road |
| Suite 100 |
| Irvine, CA 92606 |
| Attention: Brett Adair , General Counsel |
| NOT TRANSFERABLE |
| EQUIPMENT AUTHORIZATION is hereby issued to the named GRANTEE, and is VALID ONLY for the equipment identified hereon for use under the Commission's Rules and Regulations listed below. |
| FCC IDENTIFIER: | KA2AP1650A1 |
| Name of Grantee: | D-Link Corporation |
| Equipment Class: | Unlicensed National Information Infrastructure TX |
| Notes: | Wireless AC1200 Dual Band Gigabit Range Extender |
| Grant Notes | FCC Rule Parts | Frequency Range (MHZ) | Output Watts | Frequency Tolerance | Emission Designator |
| 38 CC MO | 15E | 5180.0 - 5240.0 | 0.19 | ||
| 38 CC MO | 15E | 5745.0 - 5825.0 | 0.193 |
| Power listed is the maximum combined conducted output power. End-users and responsible parties must be provided with operating and installation instructions to ensure RF exposure compliance. The antenna(s) used for this transmitter must be installed to provide a separation distance of at least 20 cm from all persons and must not be co-located or operating in conjunction with any other antenna or transmitter. Operations in the 5.15-5.25GHz band are restricted to indoor usage only. Class II Permissive Change to update U-NII-1 and U-NII-3 to new rule. |
| 38: | This device has shown compliance, in all grant-listed U-NII sub-bands, with the new rules for U-NII devices adopted under Docket No. 13-49 and may be marketed, manufactured or imported after the June 1, 2016 transition deadline. |
| CC: | This device is certified pursuant to two different Part 15 rules sections. |
| MO: | This Multiple Input Multiple Output (MIMO) device was evaluated for multiple transmitted signals as indicated in the filing. |
EAS Grant - Application IQOoJfUVAHqUGXzjctpoDQ==
| COPY |
FEDERAL COMMUNICATIONS COMMISSION WASHINGTON, D.C. 20554 GRANT OF EQUIPMENT AUTHORIZATION |
COPY |
| Certification |
|
D-Link Corporation 14420 Myford Road Suite 100 Irvine, CA 92606 United States |
Date of Grant: 01/19/2016 Application Dated: 01/18/2016 |
| Attention: Brett Adair , General Counsel |
| NOT TRANSFERABLE |
| EQUIPMENT AUTHORIZATION is hereby issued to the named GRANTEE, and is VALID ONLY for the equipment identified hereon for use under the Commission's Rules and Regulations listed below. |
| FCC IDENTIFIER: | KA2AP1650A1 |
| Name of Grantee: | D-Link Corporation |
| Equipment Class: | Unlicensed National Information Infrastructure TX |
| Notes: | Wireless AC1200 Dual Band Gigabit Range Extender |
| Modular Type: | Does not apply |
| Grant Notes | FCC Rule Parts | Frequency Range (MHZ) | Output Watts | Frequency Tolerance | Emission Designator |
| 38 CC MO | 15E | 5180.0 - 5240.0 | 0.19 | ||
| 38 CC MO | 15E | 5745.0 - 5825.0 | 0.193 |
| Power listed is the maximum combined conducted output power. End-users and responsible parties must be provided with operating and installation instructions to ensure RF exposure compliance. The antenna(s) used for this transmitter must be installed to provide a separation distance of at least 20 cm from all persons and must not be co-located or operating in conjunction with any other antenna or transmitter. Operations in the 5.15-5.25GHz band are restricted to indoor usage only. Class II Permissive Change to update U-NII-1 and U-NII-3 to new rule. |
| 38: | This device has shown compliance, in all grant-listed U-NII sub-bands, with the new rules for U-NII devices adopted under Docket No. 13-49 and may be marketed, manufactured or imported after the June 1, 2016 transition deadline. |
| CC: | This device is certified pursuant to two different Part 15 rules sections. |
| MO: | This Multiple Input Multiple Output (MIMO) device was evaluated for multiple transmitted signals as indicated in the filing. |
| Mail To: | |||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
| TCB | GRANT OF EQUIPMENT AUTHORIZATION |
TCB |
| Certification | ||
| Issued Under the Authority of the | ||
| Federal Communications Commission | ||
| By: |
|
Curtis-Straus LLC One Distribution Center Circle Suite #1 Littleton, MA 01460 |
Date of Grant: 08/02/2013 Application Dated: 08/02/2013 |
| D Link Corporation |
| 17595 Mt. Herrmann |
| Fountain Valley, CA 92708 |
| Attention: Michael Boschma , Engineer |
| NOT TRANSFERABLE |
| EQUIPMENT AUTHORIZATION is hereby issued to the named GRANTEE, and is VALID ONLY for the equipment identified hereon for use under the Commission's Rules and Regulations listed below. |
| FCC IDENTIFIER: | KA2AP1650A1 |
| Name of Grantee: | D Link Corporation |
| Equipment Class: | Digital Transmission System |
| Notes: | Wireless AC1200 Dual Band Gigabit Range Extender |
| Grant Notes | FCC Rule Parts | Frequency Range (MHZ) | Output Watts | Frequency Tolerance | Emission Designator |
| CC MO | 15C | 2412.0 - 2462.0 | 0.373 | ||
| CC MO | 15C | 5745.0 - 5825.0 | 0.194 |
| Power listed is the maximum combined conducted output power. End-users and responsible parties must be provided with operating and installation instructions to ensure RF exposure compliance. The antenna(s) used for this transmitter must be installed to provide a separation distance of at least 20 cm from all persons and must not be co-located or operating in conjunction with any other antenna or transmitter. |
| CC: | This device is certified pursuant to two different Part 15 rules sections. |
| MO: | This Multiple Input Multiple Output (MIMO) device was evaluated for multiple transmitted signals as indicated in the filing. |
EAS Grant - Application Htg3b7QVJzfu8egO3WqZDA==
| COPY |
FEDERAL COMMUNICATIONS COMMISSION WASHINGTON, D.C. 20554 GRANT OF EQUIPMENT AUTHORIZATION |
COPY |
| Certification |
|
D Link Corporation 17595 Mt. Herrmann Fountain Valley, CA 92708 United States |
Date of Grant: 08/02/2013 Application Dated: 08/02/2013 |
| Attention: Michael Boschma , Engineer |
| NOT TRANSFERABLE |
| EQUIPMENT AUTHORIZATION is hereby issued to the named GRANTEE, and is VALID ONLY for the equipment identified hereon for use under the Commission's Rules and Regulations listed below. |
| FCC IDENTIFIER: | KA2AP1650A1 |
| Name of Grantee: | D Link Corporation |
| Equipment Class: | Digital Transmission System |
| Notes: | Wireless AC1200 Dual Band Gigabit Range Extender |
| Modular Type: | Does not apply |
| Grant Notes | FCC Rule Parts | Frequency Range (MHZ) | Output Watts | Frequency Tolerance | Emission Designator |
| CC MO | 15C | 2412.0 - 2462.0 | 0.373 | ||
| CC MO | 15C | 5745.0 - 5825.0 | 0.194 |
| Power listed is the maximum combined conducted output power. End-users and responsible parties must be provided with operating and installation instructions to ensure RF exposure compliance. The antenna(s) used for this transmitter must be installed to provide a separation distance of at least 20 cm from all persons and must not be co-located or operating in conjunction with any other antenna or transmitter. |
| CC: | This device is certified pursuant to two different Part 15 rules sections. |
| MO: | This Multiple Input Multiple Output (MIMO) device was evaluated for multiple transmitted signals as indicated in the filing. |
| Mail To: | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
| TCB | GRANT OF EQUIPMENT AUTHORIZATION |
TCB |
| Certification | ||
| Issued Under the Authority of the | ||
| Federal Communications Commission | ||
| By: |
|
Curtis-Straus LLC One Distribution Center Circle Suite #1 Littleton, MA 01460 |
Date of Grant: 08/02/2013 Application Dated: 08/02/2013 |
| D Link Corporation |
| 17595 Mt. Herrmann |
| Fountain Valley, CA 92708 |
| Attention: Michael Boschma , Engineer |
| NOT TRANSFERABLE |
| EQUIPMENT AUTHORIZATION is hereby issued to the named GRANTEE, and is VALID ONLY for the equipment identified hereon for use under the Commission's Rules and Regulations listed below. |
| FCC IDENTIFIER: | KA2AP1650A1 |
| Name of Grantee: | D Link Corporation |
| Equipment Class: | Unlicensed National Information Infrastructure TX |
| Notes: | Wireless AC1200 Dual Band Gigabit Range Extender |
| Grant Notes | FCC Rule Parts | Frequency Range (MHZ) | Output Watts | Frequency Tolerance | Emission Designator |
| CC MO | 15E | 5180.0 - 5240.0 | 0.046 |
| Power listed is the maximum combined conducted output power. End-users and responsible parties must be provided with operating and installation instructions to ensure RF exposure compliance. The antenna(s) used for this transmitter must be installed to provide a separation distance of at least 20 cm from all persons and must not be co-located or operating in conjunction with any other antenna or transmitter. Operations in the 5.15-5.25GHz band are restricted to indoor usage only. |
| CC: | This device is certified pursuant to two different Part 15 rules sections. |
| MO: | This Multiple Input Multiple Output (MIMO) device was evaluated for multiple transmitted signals as indicated in the filing. |
EAS Grant - Application DDDLFoHhiD3NzCMUxAMpgQ==
| COPY |
FEDERAL COMMUNICATIONS COMMISSION WASHINGTON, D.C. 20554 GRANT OF EQUIPMENT AUTHORIZATION |
COPY |
| Certification |
|
D Link Corporation 17595 Mt. Herrmann Fountain Valley, CA 92708 United States |
Date of Grant: 08/02/2013 Application Dated: 08/02/2013 |
| Attention: Michael Boschma , Engineer |
| NOT TRANSFERABLE |
| EQUIPMENT AUTHORIZATION is hereby issued to the named GRANTEE, and is VALID ONLY for the equipment identified hereon for use under the Commission's Rules and Regulations listed below. |
| FCC IDENTIFIER: | KA2AP1650A1 |
| Name of Grantee: | D Link Corporation |
| Equipment Class: | Unlicensed National Information Infrastructure TX |
| Notes: | Wireless AC1200 Dual Band Gigabit Range Extender |
| Modular Type: | Does not apply |
| Grant Notes | FCC Rule Parts | Frequency Range (MHZ) | Output Watts | Frequency Tolerance | Emission Designator |
| CC MO | 15E | 5180.0 - 5240.0 | 0.046 |
| Power listed is the maximum combined conducted output power. End-users and responsible parties must be provided with operating and installation instructions to ensure RF exposure compliance. The antenna(s) used for this transmitter must be installed to provide a separation distance of at least 20 cm from all persons and must not be co-located or operating in conjunction with any other antenna or transmitter. Operations in the 5.15-5.25GHz band are restricted to indoor usage only. |
| CC: | This device is certified pursuant to two different Part 15 rules sections. |
| MO: | This Multiple Input Multiple Output (MIMO) device was evaluated for multiple transmitted signals as indicated in the filing. |
| Mail To: |
