FCC ID KA2AP3662A1
Wireless AC1200 Dual Band Outdoor PoE Access Point
by D-Link Corporation
Grantee Code: KA2 Product Code: AP3662A1
Latest application date: 2016-01-05
Device Images
FCC ID Device Details
| FCC ID | KA2AP3662A1 |
|---|---|
| Mirrors | fcc.id | gov | fccid.ai |
| Grantee Code | KA2 |
| Product Code | AP3662A1 |
| Applicant Business | D-Link Corporation 🇺🇸 |
| Related Domains |  dlink.com  sporton.com.tw |
| Equipment Class | Wireless AC1200 Dual Band Outdoor PoE Access Point |
| Test Firm | SPORTON International Inc. |
Operating Frequencies
| Frequency Range | Application Purpose | Final Action Date |
|---|---|---|
| 5180-5240 MHz | Class II permissive change or modification of presently authorized equipment | 2016-01-05 |
| 5180-5240 MHz | Original Equipment | 2015-01-28 |
| 2412-2462 MHz | Original Equipment | 2015-01-28 |
Exhibits
| Document | Type | Available | File |
|---|---|---|---|
| User manual | Users Manual | 2015-01-28 | PDF 331.5 KB |
| Internal photo | Internal Photos | 2015-01-28 | PDF 959.5 KB |
| External Photos | External Photos | 2016-01-05 | PDF 187.1 KB |
| External photo | External Photos | 2015-01-28 | PDF 359.4 KB |
| ID label/Location info | ID Label/Location Info | 2015-01-28 | PDF 56.3 KB |
| Test Setup Photos | Test Setup Photos | 2016-01-05 | PDF 371.2 KB |
| Test setup photo | Test Setup Photos | 2015-01-28 | PDF 299.3 KB |
| Test Report | Test Report | 2016-01-05 | PDF 2.3 MB |
| Co-Location Report | Test Report | 2015-01-28 | PDF 110.6 KB |
| MAXIMUM E.I.R.P. AT ANY ELEVATION ANGLE ABOVE 30 DEGREES | Test Report | 2015-01-28 | PDF 76.4 KB |
| Test report_DTS | Test Report | 2015-01-28 | PDF 2 MB |
| Test report_NII | Test Report | 2015-01-28 | PDF 1,006.7 KB |
| Class II permissive change letter for FCC | Cover Letter(s) | 2016-01-05 | PDF 22.5 KB |
| Confidentiality | Cover Letter(s) | 2016-01-05 | PDF 22.3 KB |
| POA | Cover Letter(s) | 2016-01-05 | PDF 19.4 KB |
| POA_Grantee contact person | Cover Letter(s) | 2016-01-05 | PDF 248.2 KB |
| Confidential Letter | Cover Letter(s) | 2015-01-28 | PDF 13 KB |
| DoC Letter | Cover Letter(s) | 2015-01-28 | PDF 12.3 KB |
| POA | Cover Letter(s) | 2015-01-28 | PDF 12.9 KB |
| POA_Grantee | Cover Letter(s) | 2015-01-28 | PDF 53.8 KB |
| RF Exposure Info | RF Exposure Info | 2016-01-05 | PDF 349.5 KB |
| Human Exposure | RF Exposure Info | 2015-01-28 | PDF 124.3 KB |
| Block diagram Metadata only | Block Diagram | PDF 90.3 KB | |
| Schematics Metadata only | Schematics | PDF 484.3 KB | |
| Operational Description Metadata only | Operational Description | PDF 60.5 KB | |
| Operational Description_Software Security Requirements revised Metadata only | Operational Description | PDF 32.9 KB | |
| Operational Description_Software Security Requirements revised 0205 Metadata only | Operational Description | PDF 30.1 KB | |
| Operational description Metadata only | Operational Description | PDF 106.6 KB | |
| Operational description for User Interface (UI) Metadata only | Operational Description | PDF 12.8 KB | |
| Operational description_Software Security Requirements Metadata only | Operational Description | PDF 30.4 KB | |
| Software Security Metadata only | Operational Description | PDF 45.1 KB | |
| Software Security Requirement revised Metadata only | Operational Description | PDF 290.9 KB | |
| revised software security document Metadata only | Operational Description | PDF 30.1 KB | |
| software security document Metadata only | Operational Description | PDF 32.9 KB | |
| Secu infority Metadata only | SDR Software/Security Inf | PDF 30.1 KB |
Application Information
| Application ID | ZIkluZqtu/dy1WYAlnZSWg== |
|---|---|
| Final Action Date | 2016-01-05 |
| Application Purpose | Class II permissive change or modification of presently authorized equipment |
| Applicant FRN | 0007371172 |
| Model | AP3662A1 |
| Frequency Range | 5180-5240 MHz |
| Equipment Class | NII - Unlicensed National Information Infrastructure TX |
| Device Description | Wireless AC1200 Dual Band Outdoor PoE Access Point |
| Responsible Party | Brett Adair, General Counsel, brett.adair@dlink.com , 714-885-6282 |
| Agent | Leo Leo Leo, Sporton International Inc., leohuang@sporton.com.tw , 886-3-656-9065 |
| Technical Contact | Sharon Jiang, Sporton International Inc., sharonjiang@sporton.com.tw , 886-3-656-9065 |
| Non-Technical Contact | Sharon Jiang, Sporton International Inc., sharonjiang@sporton.com.tw , 886-3-656-9065 |
| Test Firm | Leo Huang, SPORTON International Inc., leohuang@sporton.com.tw , 886-3-6569065 |
| TCB Email | certification@telefication.com  |
| TCB Scope | A4: UNII devices & low power transmitters using spread spectrum techniques |
| Short-Term Confidentiality | No |
| Long-Term Confidentiality | Yes |
| Grant Deferral | No |
| Modular Equipment | Does not apply |
| Composite Device | Yes |
| Composite Part | No |
| Cognitive Radio | No |
| Authorization Waiver | No |
| Authorization Waiver Approved | No |
| Section 5301 Certification | Yes |
| Related OET Knowledge DataBase Inquiry | No |
| Grant Comments | C2PC: Adding a new adapter(MU24A5480050-A1) & updating 5 GHz Band 3 to FCC new rules. Power output listed is conducted. The antenna(s) used for this transmitter must be used to provide a separation distance of at least 23 cm from all persons and must not be co-located or operating in conjunction with any other antenna or transmitter. End-users must be provided with antenna installation instructions and transmitter operating conditions for satisfying RF exposure compliance. This device has 20/40/80 MHz bandwidth modes. The 80 MHz BW mode is limited to channel 5210 & 5775 MHz. |
Applications
| Application ID | Date | Purpose |
|---|---|---|
| ZIkluZqtu/dy1WYAlnZSWg== | 2016-01-05 | Class II permissive change or modification of presently authorized equipment |
| t4ibAeDz3bdTxyX6+wAnaA== | 2015-01-28 | Original Equipment |
| II0FNi2dLnSn8ZnqFudGIg== | 2015-01-28 | Original Equipment |
Equipment Authorization
Grants
TCB Grant - Application ZIkluZqtu/dy1WYAlnZSWg==
| TCB | GRANT OF EQUIPMENT AUTHORIZATION |
TCB |
| Certification | ||
| Issued Under the Authority of the | ||
| Federal Communications Commission | ||
| By: |
|
Telefication B.V. Wilmersdorf 50 Apeldoorn, NL-7300 AC Netherlands |
Date of Grant: 01/05/2016 Application Dated: 01/05/2016 |
| D-Link Corporation |
| 14420 Myford Road |
| Suite 100 |
| Irvine, CA 92606 |
| Attention: Brett Adair , General Counsel |
| NOT TRANSFERABLE |
| EQUIPMENT AUTHORIZATION is hereby issued to the named GRANTEE, and is VALID ONLY for the equipment identified hereon for use under the Commission's Rules and Regulations listed below. |
| FCC IDENTIFIER: | KA2AP3662A1 |
| Name of Grantee: | D-Link Corporation |
| Equipment Class: | Unlicensed National Information Infrastructure TX |
| Notes: | Wireless AC1200 Dual Band Outdoor PoE Access Point |
| Grant Notes | FCC Rule Parts | Frequency Range (MHZ) | Output Watts | Frequency Tolerance | Emission Designator |
| 38 CC MO | 15E | 5180.0 - 5240.0 | 0.285 | ||
| 38 CC MO | 15E | 5745.0 - 5825.0 | 0.938 |
| C2PC: Adding a new adapter(MU24A5480050-A1) & updating 5 GHz Band 3 to FCC new rules. Power output listed is conducted. The antenna(s) used for this transmitter must be used to provide a separation distance of at least 23 cm from all persons and must not be co-located or operating in conjunction with any other antenna or transmitter. End-users must be provided with antenna installation instructions and transmitter operating conditions for satisfying RF exposure compliance. This device has 20/40/80 MHz bandwidth modes. The 80 MHz BW mode is limited to channel 5210 & 5775 MHz. |
| 38: | This device has shown compliance, in all grant-listed U-NII sub-bands, with the new rules for U-NII devices adopted under Docket No. 13-49 and may be marketed, manufactured or imported after the June 1, 2016 transition deadline. |
| CC: | This device is certified pursuant to two different Part 15 rules sections. |
| MO: | This Multiple Input Multiple Output (MIMO) device was evaluated for multiple transmitted signals as indicated in the filing. |
EAS Grant - Application ZIkluZqtu/dy1WYAlnZSWg==
| COPY |
FEDERAL COMMUNICATIONS COMMISSION WASHINGTON, D.C. 20554 GRANT OF EQUIPMENT AUTHORIZATION |
COPY |
| Certification |
|
D-Link Corporation 14420 Myford Road Suite 100 Irvine, CA 92606 United States |
Date of Grant: 01/05/2016 Application Dated: 01/05/2016 |
| Attention: Brett Adair , General Counsel |
| NOT TRANSFERABLE |
| EQUIPMENT AUTHORIZATION is hereby issued to the named GRANTEE, and is VALID ONLY for the equipment identified hereon for use under the Commission's Rules and Regulations listed below. |
| FCC IDENTIFIER: | KA2AP3662A1 |
| Name of Grantee: | D-Link Corporation |
| Equipment Class: | Unlicensed National Information Infrastructure TX |
| Notes: | Wireless AC1200 Dual Band Outdoor PoE Access Point |
| Modular Type: | Does not apply |
| Grant Notes | FCC Rule Parts | Frequency Range (MHZ) | Output Watts | Frequency Tolerance | Emission Designator |
| 38 CC MO | 15E | 5180.0 - 5240.0 | 0.285 | ||
| 38 CC MO | 15E | 5745.0 - 5825.0 | 0.938 |
| C2PC: Adding a new adapter(MU24A5480050-A1) & updating 5 GHz Band 3 to FCC new rules. Power output listed is conducted. The antenna(s) used for this transmitter must be used to provide a separation distance of at least 23 cm from all persons and must not be co-located or operating in conjunction with any other antenna or transmitter. End-users must be provided with antenna installation instructions and transmitter operating conditions for satisfying RF exposure compliance. This device has 20/40/80 MHz bandwidth modes. The 80 MHz BW mode is limited to channel 5210 & 5775 MHz. |
| 38: | This device has shown compliance, in all grant-listed U-NII sub-bands, with the new rules for U-NII devices adopted under Docket No. 13-49 and may be marketed, manufactured or imported after the June 1, 2016 transition deadline. |
| CC: | This device is certified pursuant to two different Part 15 rules sections. |
| MO: | This Multiple Input Multiple Output (MIMO) device was evaluated for multiple transmitted signals as indicated in the filing. |
| Mail To: | |||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
| TCB | GRANT OF EQUIPMENT AUTHORIZATION |
TCB |
| Certification | ||
| Issued Under the Authority of the | ||
| Federal Communications Commission | ||
| By: |
|
Telefication B.V. Wilmersdorf 50 Apeldoorn, NL-7300 AC Netherlands |
Date of Grant: 01/28/2015 Application Dated: 01/27/2015 |
| D-Link Corporation |
| 14420 Myford Road |
| Suite 100 |
| Irvine, CA 92606 |
| Attention: Brett Adair , General Counsel |
| NOT TRANSFERABLE |
| EQUIPMENT AUTHORIZATION is hereby issued to the named GRANTEE, and is VALID ONLY for the equipment identified hereon for use under the Commission's Rules and Regulations listed below. |
| FCC IDENTIFIER: | KA2AP3662A1 |
| Name of Grantee: | D-Link Corporation |
| Equipment Class: | Unlicensed National Information Infrastructure TX |
| Notes: | Wireless AC1200 Dual Band Outdoor PoE Access Point |
| Grant Notes | FCC Rule Parts | Frequency Range (MHZ) | Output Watts | Frequency Tolerance | Emission Designator |
| 39 CC MO | 15E | 5180.0 - 5240.0 | 0.285 |
| Power output listed is conducted. The antenna(s) used for this transmitter must be used to provide a separation distance of at least 23 cm from all persons and must not be co-located or operating in conjunction with any other antenna or transmitter. End-users must be provided with antenna installation instructions and transmitter operating conditions for satisfying RF exposure compliance. This device has 20/40/80 MHz bandwidth modes. The 80 MHz mode is limited to channel at 5210MHz. |
| 39: | This sub-band complies with the new rules for U-NII devices adopted under Docket No. 13-49. This device may not be sold or marketed after June 1, 2016, unless all grant-listed U-NII sub-bands demonstrate compliance with Docket No. 13-49. |
| CC: | This device is certified pursuant to two different Part 15 rules sections. |
| MO: | This Multiple Input Multiple Output (MIMO) device was evaluated for multiple transmitted signals as indicated in the filing. |
EAS Grant - Application t4ibAeDz3bdTxyX6+wAnaA==
| COPY |
FEDERAL COMMUNICATIONS COMMISSION WASHINGTON, D.C. 20554 GRANT OF EQUIPMENT AUTHORIZATION |
COPY |
| Certification |
|
D-Link Corporation 14420 Myford Road Suite 100 Irvine, CA 92606 United States |
Date of Grant: 01/28/2015 Application Dated: 01/27/2015 |
| Attention: Brett Adair , General Counsel |
| NOT TRANSFERABLE |
| EQUIPMENT AUTHORIZATION is hereby issued to the named GRANTEE, and is VALID ONLY for the equipment identified hereon for use under the Commission's Rules and Regulations listed below. |
| FCC IDENTIFIER: | KA2AP3662A1 |
| Name of Grantee: | D-Link Corporation |
| Equipment Class: | Unlicensed National Information Infrastructure TX |
| Notes: | Wireless AC1200 Dual Band Outdoor PoE Access Point |
| Modular Type: | Does not apply |
| Grant Notes | FCC Rule Parts | Frequency Range (MHZ) | Output Watts | Frequency Tolerance | Emission Designator |
| 39 CC MO | 15E | 5180.0 - 5240.0 | 0.285 |
| Power output listed is conducted. The antenna(s) used for this transmitter must be used to provide a separation distance of at least 23 cm from all persons and must not be co-located or operating in conjunction with any other antenna or transmitter. End-users must be provided with antenna installation instructions and transmitter operating conditions for satisfying RF exposure compliance. This device has 20/40/80 MHz bandwidth modes. The 80 MHz mode is limited to channel at 5210MHz. |
| 39: | This sub-band complies with the new rules for U-NII devices adopted under Docket No. 13-49. This device may not be sold or marketed after June 1, 2016, unless all grant-listed U-NII sub-bands demonstrate compliance with Docket No. 13-49. |
| CC: | This device is certified pursuant to two different Part 15 rules sections. |
| MO: | This Multiple Input Multiple Output (MIMO) device was evaluated for multiple transmitted signals as indicated in the filing. |
| Mail To: | |||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
| TCB | GRANT OF EQUIPMENT AUTHORIZATION |
TCB |
| Certification | ||
| Issued Under the Authority of the | ||
| Federal Communications Commission | ||
| By: |
|
Telefication B.V. Wilmersdorf 50 Apeldoorn, NL-7300 AC Netherlands |
Date of Grant: 01/28/2015 Application Dated: 01/27/2015 |
| D-Link Corporation |
| 14420 Myford Road |
| Suite 100 |
| Irvine, CA 92606 |
| Attention: Brett Adair , General Counsel |
| NOT TRANSFERABLE |
| EQUIPMENT AUTHORIZATION is hereby issued to the named GRANTEE, and is VALID ONLY for the equipment identified hereon for use under the Commission's Rules and Regulations listed below. |
| FCC IDENTIFIER: | KA2AP3662A1 |
| Name of Grantee: | D-Link Corporation |
| Equipment Class: | Digital Transmission System |
| Notes: | Wireless AC1200 Dual Band Outdoor PoE Access Point |
| Grant Notes | FCC Rule Parts | Frequency Range (MHZ) | Output Watts | Frequency Tolerance | Emission Designator |
| CC MO | 15C | 2412.0 - 2462.0 | 0.625 | ||
| CC MO | 15C | 5745.0 - 5825.0 | 0.748 |
| Power output listed is conducted. The antenna(s) used for this transmitter must be used to provide a separation distance of at least 23 cm from all persons and must not be co-located or operating in conjunction with any other antenna or transmitter. End-users must be provided with antenna installation instructions and transmitter operating conditions for satisfying RF exposure compliance. This device has 20/40/80 MHz bandwidth modes. The 80 MHz mode is limited to channel at 5775 MHz |
| CC: | This device is certified pursuant to two different Part 15 rules sections. |
| MO: | This Multiple Input Multiple Output (MIMO) device was evaluated for multiple transmitted signals as indicated in the filing. |
EAS Grant - Application II0FNi2dLnSn8ZnqFudGIg==
| COPY |
FEDERAL COMMUNICATIONS COMMISSION WASHINGTON, D.C. 20554 GRANT OF EQUIPMENT AUTHORIZATION |
COPY |
| Certification |
|
D-Link Corporation 14420 Myford Road Suite 100 Irvine, CA 92606 United States |
Date of Grant: 01/28/2015 Application Dated: 01/27/2015 |
| Attention: Brett Adair , General Counsel |
| NOT TRANSFERABLE |
| EQUIPMENT AUTHORIZATION is hereby issued to the named GRANTEE, and is VALID ONLY for the equipment identified hereon for use under the Commission's Rules and Regulations listed below. |
| FCC IDENTIFIER: | KA2AP3662A1 |
| Name of Grantee: | D-Link Corporation |
| Equipment Class: | Digital Transmission System |
| Notes: | Wireless AC1200 Dual Band Outdoor PoE Access Point |
| Modular Type: | Does not apply |
| Grant Notes | FCC Rule Parts | Frequency Range (MHZ) | Output Watts | Frequency Tolerance | Emission Designator |
| CC MO | 15C | 2412.0 - 2462.0 | 0.625 | ||
| CC MO | 15C | 5745.0 - 5825.0 | 0.748 |
| Power output listed is conducted. The antenna(s) used for this transmitter must be used to provide a separation distance of at least 23 cm from all persons and must not be co-located or operating in conjunction with any other antenna or transmitter. End-users must be provided with antenna installation instructions and transmitter operating conditions for satisfying RF exposure compliance. This device has 20/40/80 MHz bandwidth modes. The 80 MHz mode is limited to channel at 5775 MHz |
| CC: | This device is certified pursuant to two different Part 15 rules sections. |
| MO: | This Multiple Input Multiple Output (MIMO) device was evaluated for multiple transmitted signals as indicated in the filing. |
| Mail To: |
