FCC ID KA2IR868LC1
Wireless AC1750 Dual Band Gigabit Cloud Router USB 3.0
by D-Link Corporation
Grantee Code: KA2 Product Code: IR868LC1
Latest application date: 2016-03-11
Device Images
FCC ID Device Details
Operating Frequencies
| Frequency Range | Application Purpose | Final Action Date |
|---|---|---|
| 5745-5825 MHz | Class II permissive change or modification of presently authorized equipment | 2016-03-11 |
| 5180-5240 MHz | Original Equipment | 2015-05-26 |
| 2412-2462 MHz | Original Equipment | 2015-05-26 |
Exhibits
| Document | Type | Available | File |
|---|---|---|---|
| User Manual (DAP-1750) rev.pdf | Users Manual | 2015-05-26 | PDF 5.7 MB |
| User Manual (DIR-868) rev.pdf | Users Manual | 2015-05-26 | PDF 5.7 MB |
| Internal Photos.pdf | Internal Photos | 2015-05-26 | PDF 4.7 MB |
| External Photos rev.pdf | External Photos | 2015-05-26 | PDF 1.4 MB |
| ID Label Location Information rev.pdf | ID Label/Location Info | 2015-05-26 | PDF 1.8 MB |
| Test Setup Photo.pdf | Test Setup Photos | 2016-03-11 | PDF 155.1 KB |
| Test Setup Photo.pdf | Test Setup Photos | 2015-05-26 | PDF 648.8 KB |
| Test Report (NII).pdf | Test Report | 2016-03-11 | PDF 820.1 KB |
| Test Report (DTS).pdf | Test Report | 2015-05-26 | PDF 2.8 MB |
| Test Report (NII).pdf | Test Report | 2015-05-26 | PDF 1.2 MB |
| Test Report (Transmit Simultaneously).pdf | Test Report | 2015-05-26 | PDF 898 KB |
| Attestation - Channel and Mode Declaration.pdf | Attestation Statements | 2015-05-26 | PDF 14.4 KB |
| Confidentiality Request - Long Term.pdf | Cover Letter(s) | 2016-03-11 | PDF 21.7 KB |
| Cover Letter - Agent Authorization.pdf | Cover Letter(s) | 2016-03-11 | PDF 20.2 KB |
| Cover Letter - Contact Authorization.pdf | Cover Letter(s) | 2016-03-11 | PDF 185.8 KB |
| Cover Letter - Description of Change rev.pdf | Cover Letter(s) | 2016-03-11 | PDF 51.1 KB |
| Cover Letter - Agent Authorization.pdf | Cover Letter(s) | 2015-05-26 | PDF 19.2 KB |
| Cover Letter - Confidentiality Request - Long Term.pdf | Cover Letter(s) | 2015-05-26 | PDF 20.7 KB |
| Cover Letter - Contact Authorization.pdf | Cover Letter(s) | 2015-05-26 | PDF 185.8 KB |
| RF Exposure Information (MPE).pdf | RF Exposure Info | 2016-03-11 | PDF 356.9 KB |
| RF Exposure Information (MPE).pdf | RF Exposure Info | 2015-05-26 | PDF 495.8 KB |
| Block Diagram.pdf Metadata only | Block Diagram | PDF 106.6 KB | |
| Block Diagram.pdf Metadata only | Block Diagram | PDF 91.4 KB | |
| Schematics.pdf Metadata only | Schematics | PDF 341.1 KB | |
| Schematics.pdf Metadata only | Schematics | PDF 392.9 KB | |
| Operational Description.pdf Metadata only | Operational Description | PDF 42.5 KB | |
| Software Operating Description.pdf Metadata only | Operational Description | PDF 123.8 KB | |
| Software Operating Description_D2 v01r03 rev.pdf Metadata only | Operational Description | PDF 80.3 KB |
Application Information
| Application ID | vw1Eb66UU/f0CP0V6MYrXQ== |
|---|---|
| Final Action Date | 2016-03-11 |
| Application Purpose | Class II permissive change or modification of presently authorized equipment |
| Applicant FRN | 0007371172 |
| Model | IR868LC1 |
| Frequency Range | 5745-5825 MHz |
| Equipment Class | NII - Unlicensed National Information Infrastructure TX |
| Device Description | Wireless AC1750 Dual Band Gigabit Cloud Router USB 3.0 |
| Responsible Party | Brett Adair, General Counsel, brett.adair@dlink.com  , 714-885-6282 |
| Test Firm | Eric Lin, Bureau Veritas CPS(H.K.) Ltd., Taoyuan Branch, eric-wp.lin@tw.bureauveritas.com  , 886-3-6668565 |
| TCB Email | certification@curtis-straus.com  |
| TCB Scope | A4: UNII devices & low power transmitters using spread spectrum techniques |
| Short-Term Confidentiality | No |
| Long-Term Confidentiality | Yes |
| Grant Deferral | No |
| Modular Equipment | Does not apply |
| Composite Device | Yes |
| Composite Part | No |
| Cognitive Radio | No |
| Authorization Waiver | No |
| Authorization Waiver Approved | No |
| Section 5301 Certification | Yes |
| Related OET Knowledge DataBase Inquiry | No |
| Grant Comments | Class II Permissive Change to update 5.8GHz band to U-NII-3 new rule. Power listed is the maximum combined conducted output power. End-users and responsible parties must be provided with operating and installation instructions to ensure RF exposure compliance. The antenna(s) used for this transmitter must be installed to provide a separation distance of at least 20 cm from all persons and must not be co-located or operating in conjunction with any other antenna or transmitter, except the collocation as described in this filing or in accordance with FCC multi-transmitter product guidelines. This device has 20 MHz, 40 MHz and 80 MHz bandwidth mode. |
