FCC ID KA2WL3610APA1
Unified AC Selectable Dual-band PoE Access Point
by D-Link Corporation
Grantee Code: KA2 Product Code: WL3610APA1
Latest application date: 2018-05-07
Device Images
FCC ID Device Details
Operating Frequencies
| Frequency Range | Application Purpose | Final Action Date |
|---|---|---|
| 5180-5240 MHz | Class II permissive change or modification of presently authorized equipment | 2018-05-07 |
| 5180-5240 MHz | Original Equipment | 2017-04-28 |
| 2412-2462 MHz | Original Equipment | 2017-04-28 |
Exhibits
| Document | Type | Available | File |
|---|---|---|---|
| User Manual | Users Manual | 2018-11-03 | PDF 1.5 MB |
| Users Manual_1 | Users Manual | 2017-04-28 | PDF 3.3 MB |
| Users Manual_2 | Users Manual | 2017-04-28 | PDF 3 MB |
| Internal Photos | Internal Photos | 2017-04-28 | PDF 222.6 KB |
| External Photos | External Photos | 2017-04-28 | PDF 152.8 KB |
| ID Label/Location Info | ID Label/Location Info | 2017-04-28 | PDF 126 KB |
| Test Setup Photos RF | Test Setup Photos | 2018-11-03 | PDF 2.4 MB |
| Test Setup Photos | Test Setup Photos | 2017-04-28 | PDF 592.5 KB |
| MPE Test Report | RF Exposure Info | 2018-05-07 | PDF 149.2 KB |
| Test Report DFS | Test Report | 2018-05-07 | PDF 2.9 MB |
| Test Report NII | Test Report | 2018-05-07 | PDF 759.2 KB |
| Test Report_DTS_Part 1 | Test Report | 2017-04-28 | PDF 2.2 MB |
| Test Report_DTS_Part 2 | Test Report | 2017-04-28 | PDF 3.6 MB |
| Test Report_DTS_Part 3 | Test Report | 2017-04-28 | PDF 3.2 MB |
| Test Report_NII_1 | Test Report | 2017-04-28 | PDF 4.6 MB |
| Test Report_NII_2 | Test Report | 2017-04-28 | PDF 2.8 MB |
| DFS Declaration | Attestation Statements | 2018-05-07 | PDF 168.6 KB |
| Class 2 Permissive Change | Cover Letter(s) | 2018-05-07 | PDF 193.2 KB |
| Confidentiality Request | Cover Letter(s) | 2018-05-07 | PDF 310.4 KB |
| Contact Authorization | Cover Letter(s) | 2018-05-07 | PDF 268.6 KB |
| Antenna Spec | Cover Letter(s) | 2017-04-28 | PDF 324.5 KB |
| Antenna Spec.pdf | Cover Letter(s) | 2017-04-28 | PDF 324.5 KB |
| Declaration of Conformity FCC subpart 15B | Cover Letter(s) | 2017-04-28 | PDF 14.9 KB |
| Declaration of authorization | Cover Letter(s) | 2017-04-28 | PDF 28.6 KB |
| RF_260_02 Declaration of Conformity FCC subpart 15B | Cover Letter(s) | 2017-04-28 | PDF 14.9 KB |
| Request for LT or STC confidentiality FCC | Cover Letter(s) | 2017-04-28 | PDF 60.5 KB |
| MPE | RF Exposure Info | 2017-04-28 | PDF 222.5 KB |
| Block Diagram Metadata only | Block Diagram | PDF 64.1 KB | |
| Schematics Metadata only | Schematics | PDF 394.3 KB | |
| NII Software Security Info Metadata only | Operational Description | PDF 59 KB | |
| Operational Decription Metadata only | Operational Description | PDF 269.6 KB | |
| Operational Description Metadata only | Operational Description | PDF 63.4 KB | |
| OpDes Software Metadata only | SDR Software/Security Inf | PDF 1.5 MB |
Application Information
| Application ID | 2Y2fhK4N4zHcZg6q3e1Wqw== |
|---|---|
| Final Action Date | 2018-05-07 |
| Application Purpose | Class II permissive change or modification of presently authorized equipment |
| Applicant FRN | 0007371172 |
| Model | WL3610APA1 |
| Frequency Range | 5180-5240 MHz |
| Equipment Class | NII - Unlicensed National Information Infrastructure TX |
| Device Description | Unified AC Selectable Dual-band PoE Access Point |
| Responsible Party | Brett Adair, General Counsel, brett.adair@dlink.com  , 714-885-6282 |
| Test Firm | Richard Chen, Bureau Veritas CPS (H.K.) Ltd., Taoyuan Branch, richard.chen@bureauveritas.com  , +886-(0)3-260-0884 |
| TCB Email | TEI@TIMCOENGR.COM  |
| TCB Scope | A4: UNII devices & low power transmitters using spread spectrum techniques |
| Short-Term Confidentiality | Yes |
| Short-Term Confidentiality Date | 11/03/2018 |
| Long-Term Confidentiality | Yes |
| Grant Deferral | No |
| Modular Equipment | Does not apply |
| Composite Device | Yes |
| Composite Part | No |
| Cognitive Radio | No |
| Authorization Waiver | No |
| Authorization Waiver Approved | No |
| Section 5301 Certification | Yes |
| Related OET Knowledge DataBase Inquiry | Yes |
| Grant Comments | Output power listed is conducted. The antenna(s) used for this transmitter must be installed to provide a separation distance of at least 20 cm from all persons and must not be co-located or operating in conjunction with any other antenna or transmitter. End-users and installers must be provided with transmitter operating conditions for satisfying RF exposure compliance. This device has 20/40/80 MHz bandwidth modes. |
Applications
| Application ID | Date | Purpose |
|---|---|---|
| 2Y2fhK4N4zHcZg6q3e1Wqw== | 2018-05-07 | Class II permissive change or modification of presently authorized equipment |
| oGLOYeahejWH4vUZaL9acg== | 2017-04-28 | Original Equipment |
| 1YpardeLG/OwYen8MpS0Tg== | 2017-04-28 | Original Equipment |
Equipment Authorization
Grants
TCB Grant - Application oGLOYeahejWH4vUZaL9acg==
| TCB | GRANT OF EQUIPMENT AUTHORIZATION |
TCB |
| Certification | ||
| Issued Under the Authority of the | ||
| Federal Communications Commission | ||
| By: |
|
Telefication B.V. Wilmersdorf 50 Apeldoorn, NL-7300 AC Netherlands |
Date of Grant: 04/28/2017 Application Dated: 04/25/2017 |
| D-Link Corporation |
| 14420 Myford Road |
| Suite 100 |
| Irvine, CA 92606 |
| Attention: Brett Adair , General Counsel |
| NOT TRANSFERABLE |
| EQUIPMENT AUTHORIZATION is hereby issued to the named GRANTEE, and is VALID ONLY for the equipment identified hereon for use under the Commission's Rules and Regulations listed below. |
| FCC IDENTIFIER: | KA2WL3610APA1 |
| Name of Grantee: | D-Link Corporation |
| Equipment Class: | Unlicensed National Information Infrastructure TX |
| Notes: | Unified AC Selectable Dual-band PoE Access Point |
| Grant Notes | FCC Rule Parts | Frequency Range (MHZ) | Output Watts | Frequency Tolerance | Emission Designator |
| 38 CC MO | 15E | 5180.0 - 5240.0 | 0.22 | ||
| 38 CC MO | 15E | 5745.0 - 5825.0 | 0.26 |
| Output power listed is conducted. The antenna(s) used for this transmitter must be installed to provide a separation distance of at least 20 cm from all persons and must not be co-located or operating in conjunction with any other antenna or transmitter. End-users and installers must be provided with transmitter operating conditions for satisfying RF exposure compliance. This device has 20/40/80 MHz bandwidth modes. The 80 MHz modes are limited to channel at 5210 MHz and 5775 MHz. |
| 38: | This device has shown compliance, in all grant-listed U-NII sub-bands, with the new rules for U-NII devices adopted under Docket No. 13-49 and may be marketed, manufactured or imported after the June 1, 2016 transition deadline. |
| CC: | This device is certified pursuant to two different Part 15 rules sections. |
| MO: | This Multiple Input Multiple Output (MIMO) device was evaluated for multiple transmitted signals as indicated in the filing. |
EAS Grant - Application oGLOYeahejWH4vUZaL9acg==
| COPY |
FEDERAL COMMUNICATIONS COMMISSION WASHINGTON, D.C. 20554 GRANT OF EQUIPMENT AUTHORIZATION |
COPY |
| Certification |
|
D-Link Corporation 14420 Myford Road Suite 100 Irvine, CA 92606 United States |
Date of Grant: 04/28/2017 Application Dated: 04/25/2017 |
| Attention: Brett Adair , General Counsel |
| NOT TRANSFERABLE |
| EQUIPMENT AUTHORIZATION is hereby issued to the named GRANTEE, and is VALID ONLY for the equipment identified hereon for use under the Commission's Rules and Regulations listed below. |
| FCC IDENTIFIER: | KA2WL3610APA1 |
| Name of Grantee: | D-Link Corporation |
| Equipment Class: | Unlicensed National Information Infrastructure TX |
| Notes: | Unified AC Selectable Dual-band PoE Access Point |
| Modular Type: | Does not apply |
| Grant Notes | FCC Rule Parts | Frequency Range (MHZ) | Output Watts | Frequency Tolerance | Emission Designator |
| 38 CC MO | 15E | 5180.0 - 5240.0 | 0.22 | ||
| 38 CC MO | 15E | 5745.0 - 5825.0 | 0.26 |
| Output power listed is conducted. The antenna(s) used for this transmitter must be installed to provide a separation distance of at least 20 cm from all persons and must not be co-located or operating in conjunction with any other antenna or transmitter. End-users and installers must be provided with transmitter operating conditions for satisfying RF exposure compliance. This device has 20/40/80 MHz bandwidth modes. The 80 MHz modes are limited to channel at 5210 MHz and 5775 MHz. |
| 38: | This device has shown compliance, in all grant-listed U-NII sub-bands, with the new rules for U-NII devices adopted under Docket No. 13-49 and may be marketed, manufactured or imported after the June 1, 2016 transition deadline. |
| CC: | This device is certified pursuant to two different Part 15 rules sections. |
| MO: | This Multiple Input Multiple Output (MIMO) device was evaluated for multiple transmitted signals as indicated in the filing. |
| Mail To: | |||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
| TCB | GRANT OF EQUIPMENT AUTHORIZATION |
TCB |
| Certification | ||
| Issued Under the Authority of the | ||
| Federal Communications Commission | ||
| By: |
|
Timco Engineering, Inc. 849 NW State Road 45 Newberry, FL 32669 |
Date of Grant: 05/07/2018 Application Dated: 03/05/2018 |
| D-Link Corporation |
| 14420 Myford Road |
| Suite 100 |
| Irvine, CA 92606 |
| Attention: Brett Adair , General Counsel |
| NOT TRANSFERABLE |
| EQUIPMENT AUTHORIZATION is hereby issued to the named GRANTEE, and is VALID ONLY for the equipment identified hereon for use under the Commission's Rules and Regulations listed below. |
| FCC IDENTIFIER: | KA2WL3610APA1 |
| Name of Grantee: | D-Link Corporation |
| Equipment Class: | Unlicensed National Information Infrastructure TX |
| Notes: | Unified AC Selectable Dual-band PoE Access Point |
| Grant Notes | FCC Rule Parts | Frequency Range (MHZ) | Output Watts | Frequency Tolerance | Emission Designator |
| CC MO | 15E | 5180.0 - 5240.0 | 0.22 | ||
| CC MO | 15E | 5260.0 - 5320.0 | 0.238 | ||
| CC MO | 15E | 5500.0 - 5700.0 | 0.237 | ||
| CC MO | 15E | 5745.0 - 5825.0 | 0.26 |
| Output power listed is conducted. The antenna(s) used for this transmitter must be installed to provide a separation distance of at least 20 cm from all persons and must not be co-located or operating in conjunction with any other antenna or transmitter. End-users and installers must be provided with transmitter operating conditions for satisfying RF exposure compliance. This device has 20/40/80 MHz bandwidth modes. |
| CC: | This device is certified pursuant to two different Part 15 rules sections. |
| MO: | This Multiple Input Multiple Output (MIMO) device was evaluated for multiple transmitted signals as indicated in the filing. |
EAS Grant - Application 2Y2fhK4N4zHcZg6q3e1Wqw==
| COPY |
FEDERAL COMMUNICATIONS COMMISSION WASHINGTON, D.C. 20554 GRANT OF EQUIPMENT AUTHORIZATION |
COPY |
| Certification |
|
D-Link Corporation 14420 Myford Road Suite 100 Irvine, CA 92606 United States |
Date of Grant: 05/07/2018 Application Dated: 03/05/2018 |
| Attention: Brett Adair , General Counsel |
| NOT TRANSFERABLE |
| EQUIPMENT AUTHORIZATION is hereby issued to the named GRANTEE, and is VALID ONLY for the equipment identified hereon for use under the Commission's Rules and Regulations listed below. |
| FCC IDENTIFIER: | KA2WL3610APA1 |
| Name of Grantee: | D-Link Corporation |
| Equipment Class: | Unlicensed National Information Infrastructure TX |
| Notes: | Unified AC Selectable Dual-band PoE Access Point |
| Modular Type: | Does not apply |
| Grant Notes | FCC Rule Parts | Frequency Range (MHZ) | Output Watts | Frequency Tolerance | Emission Designator |
| CC MO | 15E | 5180.0 - 5240.0 | 0.22 | ||
| CC MO | 15E | 5260.0 - 5320.0 | 0.238 | ||
| CC MO | 15E | 5500.0 - 5700.0 | 0.237 | ||
| CC MO | 15E | 5745.0 - 5825.0 | 0.26 |
| Output power listed is conducted. The antenna(s) used for this transmitter must be installed to provide a separation distance of at least 20 cm from all persons and must not be co-located or operating in conjunction with any other antenna or transmitter. End-users and installers must be provided with transmitter operating conditions for satisfying RF exposure compliance. This device has 20/40/80 MHz bandwidth modes. |
| CC: | This device is certified pursuant to two different Part 15 rules sections. |
| MO: | This Multiple Input Multiple Output (MIMO) device was evaluated for multiple transmitted signals as indicated in the filing. |
| Mail To: | |||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
| TCB | GRANT OF EQUIPMENT AUTHORIZATION |
TCB |
| Certification | ||
| Issued Under the Authority of the | ||
| Federal Communications Commission | ||
| By: |
|
Telefication B.V. Wilmersdorf 50 Apeldoorn, NL-7300 AC Netherlands |
Date of Grant: 04/28/2017 Application Dated: 04/25/2017 |
| D-Link Corporation |
| 14420 Myford Road |
| Suite 100 |
| Irvine, CA 92606 |
| Attention: Brett Adair , General Counsel |
| NOT TRANSFERABLE |
| EQUIPMENT AUTHORIZATION is hereby issued to the named GRANTEE, and is VALID ONLY for the equipment identified hereon for use under the Commission's Rules and Regulations listed below. |
| FCC IDENTIFIER: | KA2WL3610APA1 |
| Name of Grantee: | D-Link Corporation |
| Equipment Class: | Digital Transmission System |
| Notes: | Unified AC Selectable Dual-band PoE Access Point |
| Grant Notes | FCC Rule Parts | Frequency Range (MHZ) | Output Watts | Frequency Tolerance | Emission Designator |
| CC | 15C | 2412.0 - 2462.0 | 0.84 |
| Output power listed is conducted. The antenna(s) used for this transmitter must be used to provide a separation distance of at least 20 cm from all persons and must not be co-located or operating in conjunction with any other antenna or transmitter. End-users must be provided with antenna installation instructions and transmitter operating conditions for satisfying RF exposure compliance. This device has 20/40 MHz bandwidth modes. |
| CC: | This device is certified pursuant to two different Part 15 rules sections. |
EAS Grant - Application 1YpardeLG/OwYen8MpS0Tg==
| COPY |
FEDERAL COMMUNICATIONS COMMISSION WASHINGTON, D.C. 20554 GRANT OF EQUIPMENT AUTHORIZATION |
COPY |
| Certification |
|
D-Link Corporation 14420 Myford Road Suite 100 Irvine, CA 92606 United States |
Date of Grant: 04/28/2017 Application Dated: 04/25/2017 |
| Attention: Brett Adair , General Counsel |
| NOT TRANSFERABLE |
| EQUIPMENT AUTHORIZATION is hereby issued to the named GRANTEE, and is VALID ONLY for the equipment identified hereon for use under the Commission's Rules and Regulations listed below. |
| FCC IDENTIFIER: | KA2WL3610APA1 |
| Name of Grantee: | D-Link Corporation |
| Equipment Class: | Digital Transmission System |
| Notes: | Unified AC Selectable Dual-band PoE Access Point |
| Modular Type: | Does not apply |
| Grant Notes | FCC Rule Parts | Frequency Range (MHZ) | Output Watts | Frequency Tolerance | Emission Designator |
| CC | 15C | 2412.0 - 2462.0 | 0.84 |
| Output power listed is conducted. The antenna(s) used for this transmitter must be used to provide a separation distance of at least 20 cm from all persons and must not be co-located or operating in conjunction with any other antenna or transmitter. End-users must be provided with antenna installation instructions and transmitter operating conditions for satisfying RF exposure compliance. This device has 20/40 MHz bandwidth modes. |
| CC: | This device is certified pursuant to two different Part 15 rules sections. |
| Mail To: |
