FCC ID KA2WL6610APB1
Unified AC Concurrent Dual-band PoE Access Point
by D-Link Corporation
Grantee Code: KA2 Product Code: WL6610APB1
Latest application date: 2018-09-03
Device Images
FCC ID Device Details
Operating Frequencies
| Frequency Range | Application Purpose | Final Action Date |
|---|---|---|
| 5180-5240 MHz | Class II permissive change or modification of presently authorized equipment | 2018-09-03 |
| 5180-5240 MHz | Original Equipment | 2017-04-25 |
| 2412-2462 MHz | Original Equipment | 2017-04-25 |
Exhibits
| Document | Type | Available | File |
|---|---|---|---|
| User Manual | Users Manual | 2019-03-02 | PDF 1.1 MB |
| Users Manual | Users Manual | 2017-04-25 | PDF 5.9 MB |
| Internal Photos | Internal Photos | 2017-04-25 | PDF 905.9 KB |
| External Photos | External Photos | 2017-04-25 | PDF 1.3 MB |
| ID Label/Location Info | ID Label/Location Info | 2017-04-25 | PDF 142.1 KB |
| Test Setup Photos DFS | Test Setup Photos | 2019-03-02 | PDF 529.3 KB |
| Test Setup Photos RF | Test Setup Photos | 2019-03-02 | PDF 413 KB |
| Test Setup Photos_NII | Test Setup Photos | 2017-04-25 | PDF 509.9 KB |
| Test Report DFS | Test Report | 2018-09-03 | PDF 3 MB |
| Test Report NII | Test Report | 2018-09-03 | PDF 1.1 MB |
| Test Report_DTS | Test Report | 2017-04-25 | PDF 5.1 MB |
| Test Report_NII-1 | Test Report | 2017-04-25 | PDF 5.2 MB |
| Test Report_NII-2 | Test Report | 2017-04-25 | PDF 4 MB |
| Confidentiality Request Letter | Cover Letter(s) | 2018-09-03 | PDF 306 KB |
| Contact Authorization | Cover Letter(s) | 2018-09-03 | PDF 263.9 KB |
| DFS Declaration Letter | Cover Letter(s) | 2018-09-03 | PDF 165.5 KB |
| Description of Change | Cover Letter(s) | 2018-09-03 | PDF 188.3 KB |
| Declaration of Conformity FCC subpart 15B | Cover Letter(s) | 2017-04-25 | PDF 33.8 KB |
| Declaration of authorization | Cover Letter(s) | 2017-04-25 | PDF 31.2 KB |
| WIFI Channel 12 13 Declaration Letter | Cover Letter(s) | 2017-04-25 | PDF 26.6 KB |
| confidentiality | Cover Letter(s) | 2017-04-25 | PDF 62.8 KB |
| MPE Report | RF Exposure Info | 2018-09-03 | PDF 469.4 KB |
| MPE Report | RF Exposure Info | 2017-04-25 | PDF 237.8 KB |
| Block Diagram Metadata only | Block Diagram | PDF 53.1 KB | |
| Schematics Metadata only | Schematics | PDF 487.4 KB | |
| Operational Description Metadata only | Operational Description | PDF 190.8 KB | |
| Operational Description Metadata only | Operational Description | PDF 63.5 KB | |
| Operational Description Software Security Metadata only | SDR Software/Security Inf | PDF 1.5 MB | |
| Operational Description_NII Software Security Info Metadata only | Operational Description | PDF 59 KB |
Application Information
| Application ID | xpx263/Bmtd6IvXzFfCXWw== |
|---|---|
| Final Action Date | 2018-09-03 |
| Application Purpose | Class II permissive change or modification of presently authorized equipment |
| Applicant FRN | 0007371172 |
| Model | WL6610APB1 |
| Frequency Range | 5180-5240 MHz |
| Equipment Class | NII - Unlicensed National Information Infrastructure TX |
| Device Description | Unified AC Concurrent Dual-band PoE Access Point |
| Responsible Party | Brett Adair, General Counsel, brett.adair@dlink.com  , 714-885-6282 |
| Test Firm | Richard Chen, Bureau Veritas CPS (H.K.) Ltd., Taoyuan Branch, richard.chen@bureauveritas.com  , +886-(0)3-260-0884 |
| TCB Email | TEI@TIMCOENGR.COM  |
| TCB Scope | A4: UNII devices & low power transmitters using spread spectrum techniques |
| Short-Term Confidentiality | Yes |
| Short-Term Confidentiality Date | 03/02/2019 |
| Long-Term Confidentiality | Yes |
| Grant Deferral | No |
| Modular Equipment | Does not apply |
| Composite Device | Yes |
| Composite Part | No |
| Cognitive Radio | No |
| Authorization Waiver | No |
| Authorization Waiver Approved | No |
| Section 5301 Certification | Yes |
| Related OET Knowledge DataBase Inquiry | Yes |
| Grant Comments | Output power listed is conducted. The antenna(s) used for this transmitter must be used to provide a separation distance of at least 20 cm from all persons and must not be co-located or operating in conjunction with any other antenna or transmitter. End-users must be provided with antenna installation instructions and transmitter operating conditions for satisfying RF exposure compliance. This device has 20, 40, and 80 MHz bandwidth modes. |
Applications
| Application ID | Date | Purpose |
|---|---|---|
| xpx263/Bmtd6IvXzFfCXWw== | 2018-09-03 | Class II permissive change or modification of presently authorized equipment |
| LAnhs5fhoSoFfi1JGKFI5Q== | 2017-04-25 | Original Equipment |
| 3GMxyV+4bK9hTxpfocxFKw== | 2017-04-25 | Original Equipment |
Equipment Authorization
Grants
TCB Grant - Application xpx263/Bmtd6IvXzFfCXWw==
Internal Server Error - Read
The server encountered an internal error or misconfiguration and was unable to
complete your request.
Reference #3.258eedcc.1641906586.43b9be7f
EAS Grant - Application xpx263/Bmtd6IvXzFfCXWw==
Internal Server Error - Read
The server encountered an internal error or misconfiguration and was unable to
complete your request.
Reference #3.258eedcc.1641906584.43b9adaf
TCB Grant - Application LAnhs5fhoSoFfi1JGKFI5Q==
| TCB | GRANT OF EQUIPMENT AUTHORIZATION |
TCB |
| Certification | ||
| Issued Under the Authority of the | ||
| Federal Communications Commission | ||
| By: |
|
Telefication B.V. Wilmersdorf 50 Apeldoorn, NL-7300 AC Netherlands |
Date of Grant: 04/25/2017 Application Dated: 04/20/2017 |
| D-Link Corporation |
| 14420 Myford Road |
| Suite 100 |
| Irvine, CA 92606 |
| Attention: Brett Adair , General Counsel |
| NOT TRANSFERABLE |
| EQUIPMENT AUTHORIZATION is hereby issued to the named GRANTEE, and is VALID ONLY for the equipment identified hereon for use under the Commission's Rules and Regulations listed below. |
| FCC IDENTIFIER: | KA2WL6610APB1 |
| Name of Grantee: | D-Link Corporation |
| Equipment Class: | Unlicensed National Information Infrastructure TX |
| Notes: | Unified AC Concurrent Dual-band PoE Access Point |
| Grant Notes | FCC Rule Parts | Frequency Range (MHZ) | Output Watts | Frequency Tolerance | Emission Designator |
| 38 CC MO | 15E | 5180.0 - 5240.0 | 0.35 | ||
| 38 CC MO | 15E | 5745.0 - 5825.0 | 0.36 |
| Output power listed is conducted. The antenna(s) used for this transmitter must be used to provide a separation distance of at least 20 cm from all persons and must not be co-located or operating in conjunction with any other antenna or transmitter. End-users must be provided with antenna installation instructions and transmitter operating conditions for satisfying RF exposure compliance. This device has 20/40/80 MHz bandwidth modes. The 80 MHz mode is limited to channel at 5210MHz and 5775 MHz. |
| 38: | This device has shown compliance, in all grant-listed U-NII sub-bands, with the new rules for U-NII devices adopted under Docket No. 13-49 and may be marketed, manufactured or imported after the June 1, 2016 transition deadline. |
| CC: | This device is certified pursuant to two different Part 15 rules sections. |
| MO: | This Multiple Input Multiple Output (MIMO) device was evaluated for multiple transmitted signals as indicated in the filing. |
EAS Grant - Application LAnhs5fhoSoFfi1JGKFI5Q==
| COPY |
FEDERAL COMMUNICATIONS COMMISSION WASHINGTON, D.C. 20554 GRANT OF EQUIPMENT AUTHORIZATION |
COPY |
| Certification |
|
D-Link Corporation 14420 Myford Road Suite 100 Irvine, CA 92606 United States |
Date of Grant: 04/25/2017 Application Dated: 04/20/2017 |
| Attention: Brett Adair , General Counsel |
| NOT TRANSFERABLE |
| EQUIPMENT AUTHORIZATION is hereby issued to the named GRANTEE, and is VALID ONLY for the equipment identified hereon for use under the Commission's Rules and Regulations listed below. |
| FCC IDENTIFIER: | KA2WL6610APB1 |
| Name of Grantee: | D-Link Corporation |
| Equipment Class: | Unlicensed National Information Infrastructure TX |
| Notes: | Unified AC Concurrent Dual-band PoE Access Point |
| Modular Type: | Does not apply |
| Grant Notes | FCC Rule Parts | Frequency Range (MHZ) | Output Watts | Frequency Tolerance | Emission Designator |
| 38 CC MO | 15E | 5180.0 - 5240.0 | 0.35 | ||
| 38 CC MO | 15E | 5745.0 - 5825.0 | 0.36 |
| Output power listed is conducted. The antenna(s) used for this transmitter must be used to provide a separation distance of at least 20 cm from all persons and must not be co-located or operating in conjunction with any other antenna or transmitter. End-users must be provided with antenna installation instructions and transmitter operating conditions for satisfying RF exposure compliance. This device has 20/40/80 MHz bandwidth modes. The 80 MHz mode is limited to channel at 5210MHz and 5775 MHz. |
| 38: | This device has shown compliance, in all grant-listed U-NII sub-bands, with the new rules for U-NII devices adopted under Docket No. 13-49 and may be marketed, manufactured or imported after the June 1, 2016 transition deadline. |
| CC: | This device is certified pursuant to two different Part 15 rules sections. |
| MO: | This Multiple Input Multiple Output (MIMO) device was evaluated for multiple transmitted signals as indicated in the filing. |
| Mail To: | |||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
| TCB | GRANT OF EQUIPMENT AUTHORIZATION |
TCB |
| Certification | ||
| Issued Under the Authority of the | ||
| Federal Communications Commission | ||
| By: |
|
Telefication B.V. Wilmersdorf 50 Apeldoorn, NL-7300 AC Netherlands |
Date of Grant: 04/25/2017 Application Dated: 04/20/2017 |
| D-Link Corporation |
| 14420 Myford Road |
| Suite 100 |
| Irvine, CA 92606 |
| Attention: Brett Adair , General Counsel |
| NOT TRANSFERABLE |
| EQUIPMENT AUTHORIZATION is hereby issued to the named GRANTEE, and is VALID ONLY for the equipment identified hereon for use under the Commission's Rules and Regulations listed below. |
| FCC IDENTIFIER: | KA2WL6610APB1 |
| Name of Grantee: | D-Link Corporation |
| Equipment Class: | Digital Transmission System |
| Notes: | Unified AC Concurrent Dual-band PoE Access Point |
| Grant Notes | FCC Rule Parts | Frequency Range (MHZ) | Output Watts | Frequency Tolerance | Emission Designator |
| CC MO | 15C | 2412.0 - 2462.0 | 0.93 |
| Output power listed is conducted. The antenna(s) used for this transmitter must be used to provide a separation distance of at least 20 cm from all persons and must not be co-located or operating in conjunction with any other antenna or transmitter. End-users must be provided with antenna installation instructions and transmitter operating conditions for satisfying RF exposure compliance. This device has 20/40 MHz bandwidth modes. |
| CC: | This device is certified pursuant to two different Part 15 rules sections. |
| MO: | This Multiple Input Multiple Output (MIMO) device was evaluated for multiple transmitted signals as indicated in the filing. |
EAS Grant - Application 3GMxyV+4bK9hTxpfocxFKw==
| COPY |
FEDERAL COMMUNICATIONS COMMISSION WASHINGTON, D.C. 20554 GRANT OF EQUIPMENT AUTHORIZATION |
COPY |
| Certification |
|
D-Link Corporation 14420 Myford Road Suite 100 Irvine, CA 92606 United States |
Date of Grant: 04/25/2017 Application Dated: 04/20/2017 |
| Attention: Brett Adair , General Counsel |
| NOT TRANSFERABLE |
| EQUIPMENT AUTHORIZATION is hereby issued to the named GRANTEE, and is VALID ONLY for the equipment identified hereon for use under the Commission's Rules and Regulations listed below. |
| FCC IDENTIFIER: | KA2WL6610APB1 |
| Name of Grantee: | D-Link Corporation |
| Equipment Class: | Digital Transmission System |
| Notes: | Unified AC Concurrent Dual-band PoE Access Point |
| Modular Type: | Does not apply |
| Grant Notes | FCC Rule Parts | Frequency Range (MHZ) | Output Watts | Frequency Tolerance | Emission Designator |
| CC MO | 15C | 2412.0 - 2462.0 | 0.93 |
| Output power listed is conducted. The antenna(s) used for this transmitter must be used to provide a separation distance of at least 20 cm from all persons and must not be co-located or operating in conjunction with any other antenna or transmitter. End-users must be provided with antenna installation instructions and transmitter operating conditions for satisfying RF exposure compliance. This device has 20/40 MHz bandwidth modes. |
| CC: | This device is certified pursuant to two different Part 15 rules sections. |
| MO: | This Multiple Input Multiple Output (MIMO) device was evaluated for multiple transmitted signals as indicated in the filing. |
| Mail To: |
