FCC ID KA2WL6610APEB1
Unified AC Concurrent Dual-band PoE Access Point
by D-Link Corporation
Grantee Code: KA2 Product Code: WL6610APEB1
Latest application date: 2017-05-15
Device Images
FCC ID Device Details
| FCC ID | KA2WL6610APEB1 |
|---|---|
| Mirrors | fcc.id | gov | fccid.ai |
| Grantee Code | KA2 |
| Product Code | WL6610APEB1 |
| Applicant Business | D-Link Corporation 🇺🇸 |
| Related Domains |  dlink.com  cerpass.com.tw |
| Equipment Class | Unified AC Concurrent Dual-band PoE Access Point |
| Test Firm | Cerpass technology corporation Test Laboratory |
Operating Frequencies
| Frequency Range | Application Purpose | Final Action Date |
|---|---|---|
| 5180-5240 MHz | Original Equipment | 2017-05-15 |
| 2412-2462 MHz | Original Equipment | 2017-05-15 |
Exhibits
| Document | Type | Available | File |
|---|---|---|---|
| Users Manual | Users Manual | 2017-05-15 | PDF 5.8 MB |
| Internal Photos | Internal Photos | 2017-05-15 | PDF 959.3 KB |
| External Photos | External Photos | 2017-05-15 | PDF 680.1 KB |
| ID Label/Location Info | ID Label/Location Info | 2017-05-15 | PDF 145.1 KB |
| Test Setup Photos_NII | Test Setup Photos | 2017-05-15 | PDF 542.4 KB |
| Test Report_DTS | Test Report | 2017-05-15 | PDF 5 MB |
| Test Report_NII-1 | Test Report | 2017-05-15 | PDF 5.2 MB |
| Test Report_NII-2 | Test Report | 2017-05-15 | PDF 3.6 MB |
| Antenna Spec | Cover Letter(s) | 2017-05-15 | PDF 775.3 KB |
| Declaration of Conformity FCC subpart 15B | Cover Letter(s) | 2017-05-15 | PDF 33.7 KB |
| Declaration of authorization | Cover Letter(s) | 2017-05-15 | PDF 30.7 KB |
| confidentiality | Cover Letter(s) | 2017-05-15 | PDF 62.7 KB |
| MPE Report | RF Exposure Info | 2017-05-15 | PDF 234.7 KB |
| Block Diagram Metadata only | Block Diagram | PDF 53.1 KB | |
| Schematics Metadata only | Schematics | PDF 487.4 KB | |
| Operational Description Metadata only | Operational Description | PDF 63.5 KB | |
| Operational Description_NII Software Security Info Metadata only | Operational Description | PDF 59.2 KB |
Application Information
| Application ID | tD22XIXzyMuELLqYFL8E1g== |
|---|---|
| Final Action Date | 2017-05-15 |
| Application Purpose | Original Equipment |
| Applicant FRN | 0007371172 |
| Model | WL6610APEB1 |
| Frequency Range | 5180-5240 MHz |
| Equipment Class | NII - Unlicensed National Information Infrastructure TX |
| Device Description | Unified AC Concurrent Dual-band PoE Access Point |
| Responsible Party | Brett Adair, General Counsel, brett.adair@dlink.com , 714-885-6282 |
| Agent | Delia Delia Delia, Cerpass Technology Corporation, deliaf@cerpass.com.tw , 886-3-3226-888 |
| Technical Contact | ML Jean, D-Link Corporation, ML.Jean@dlinkcorp.com  , 886-2-66000123 |
| Non-Technical Contact | Delia Feng, Cerpass Technology Corp., deliaf@cerpass.com.tw , 886-3-3226-888 |
| Test Firm | Ben Wang, Cerpass technology corporation Test Laboratory, benw@cerpass.com.tw , +886-3-3226888 |
| TCB Email | certification@telefication.com  |
| TCB Scope | A4: UNII devices & low power transmitters using spread spectrum techniques |
| Short-Term Confidentiality | No |
| Long-Term Confidentiality | Yes |
| Grant Deferral | No |
| Modular Equipment | Does not apply |
| Composite Device | Yes |
| Composite Part | No |
| Cognitive Radio | No |
| Authorization Waiver | No |
| Authorization Waiver Approved | No |
| Section 5301 Certification | Yes |
| Related OET Knowledge DataBase Inquiry | No |
| Grant Comments | Output power listed is conducted. The antenna(s) used for this transmitter must be installed to provide a separation distance of at least 20 cm from all persons and must not be co-located or operating in conjunction with any other antenna or transmitter. End-users and installers must be provided with transmitter operating conditions for satisfying RF exposure compliance. This device has 20/40/80 MHz bandwidth modes. The 80 MHz mode is limited to channel at 5210MHz, and 5775 MHz. Operations in 5150-5250 MHz band is for indoor use only. |
Applications
| Application ID | Date | Purpose |
|---|---|---|
| tD22XIXzyMuELLqYFL8E1g== | 2017-05-15 | Original Equipment |
| oXlQoUInntjzGt7xRZyEZQ== | 2017-05-15 | Original Equipment |
Equipment Authorization
Grants
TCB Grant - Application tD22XIXzyMuELLqYFL8E1g==
| TCB | GRANT OF EQUIPMENT AUTHORIZATION |
TCB |
| Certification | ||
| Issued Under the Authority of the | ||
| Federal Communications Commission | ||
| By: |
|
Telefication B.V. Wilmersdorf 50 Apeldoorn, NL-7300 AC Netherlands |
Date of Grant: 05/15/2017 Application Dated: 05/10/2017 |
| D-Link Corporation |
| 14420 Myford Road |
| Suite 100 |
| Irvine, CA 92606 |
| Attention: Brett Adair , General Counsel |
| NOT TRANSFERABLE |
| EQUIPMENT AUTHORIZATION is hereby issued to the named GRANTEE, and is VALID ONLY for the equipment identified hereon for use under the Commission's Rules and Regulations listed below. |
| FCC IDENTIFIER: | KA2WL6610APEB1 |
| Name of Grantee: | D-Link Corporation |
| Equipment Class: | Unlicensed National Information Infrastructure TX |
| Notes: | Unified AC Concurrent Dual-band PoE Access Point |
| Grant Notes | FCC Rule Parts | Frequency Range (MHZ) | Output Watts | Frequency Tolerance | Emission Designator |
| 38 CC MO | 15E | 5180.0 - 5240.0 | 0.32 | ||
| 38 CC MO | 15E | 5745.0 - 5825.0 | 0.35 |
| Output power listed is conducted. The antenna(s) used for this transmitter must be installed to provide a separation distance of at least 20 cm from all persons and must not be co-located or operating in conjunction with any other antenna or transmitter. End-users and installers must be provided with transmitter operating conditions for satisfying RF exposure compliance. This device has 20/40/80 MHz bandwidth modes. The 80 MHz mode is limited to channel at 5210MHz, and 5775 MHz. Operations in 5150-5250 MHz band is for indoor use only. |
| 38: | This device has shown compliance, in all grant-listed U-NII sub-bands, with the new rules for U-NII devices adopted under Docket No. 13-49 and may be marketed, manufactured or imported after the June 1, 2016 transition deadline. |
| CC: | This device is certified pursuant to two different Part 15 rules sections. |
| MO: | This Multiple Input Multiple Output (MIMO) device was evaluated for multiple transmitted signals as indicated in the filing. |
EAS Grant - Application tD22XIXzyMuELLqYFL8E1g==
| COPY |
FEDERAL COMMUNICATIONS COMMISSION WASHINGTON, D.C. 20554 GRANT OF EQUIPMENT AUTHORIZATION |
COPY |
| Certification |
|
D-Link Corporation 14420 Myford Road Suite 100 Irvine, CA 92606 United States |
Date of Grant: 05/15/2017 Application Dated: 05/10/2017 |
| Attention: Brett Adair , General Counsel |
| NOT TRANSFERABLE |
| EQUIPMENT AUTHORIZATION is hereby issued to the named GRANTEE, and is VALID ONLY for the equipment identified hereon for use under the Commission's Rules and Regulations listed below. |
| FCC IDENTIFIER: | KA2WL6610APEB1 |
| Name of Grantee: | D-Link Corporation |
| Equipment Class: | Unlicensed National Information Infrastructure TX |
| Notes: | Unified AC Concurrent Dual-band PoE Access Point |
| Modular Type: | Does not apply |
| Grant Notes | FCC Rule Parts | Frequency Range (MHZ) | Output Watts | Frequency Tolerance | Emission Designator |
| 38 CC MO | 15E | 5180.0 - 5240.0 | 0.32 | ||
| 38 CC MO | 15E | 5745.0 - 5825.0 | 0.35 |
| Output power listed is conducted. The antenna(s) used for this transmitter must be installed to provide a separation distance of at least 20 cm from all persons and must not be co-located or operating in conjunction with any other antenna or transmitter. End-users and installers must be provided with transmitter operating conditions for satisfying RF exposure compliance. This device has 20/40/80 MHz bandwidth modes. The 80 MHz mode is limited to channel at 5210MHz, and 5775 MHz. Operations in 5150-5250 MHz band is for indoor use only. |
| 38: | This device has shown compliance, in all grant-listed U-NII sub-bands, with the new rules for U-NII devices adopted under Docket No. 13-49 and may be marketed, manufactured or imported after the June 1, 2016 transition deadline. |
| CC: | This device is certified pursuant to two different Part 15 rules sections. |
| MO: | This Multiple Input Multiple Output (MIMO) device was evaluated for multiple transmitted signals as indicated in the filing. |
| Mail To: | |||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
| TCB | GRANT OF EQUIPMENT AUTHORIZATION |
TCB |
| Certification | ||
| Issued Under the Authority of the | ||
| Federal Communications Commission | ||
| By: |
|
Telefication B.V. Wilmersdorf 50 Apeldoorn, NL-7300 AC Netherlands |
Date of Grant: 05/15/2017 Application Dated: 05/10/2017 |
| D-Link Corporation |
| 14420 Myford Road |
| Suite 100 |
| Irvine, CA 92606 |
| Attention: Brett Adair , General Counsel |
| NOT TRANSFERABLE |
| EQUIPMENT AUTHORIZATION is hereby issued to the named GRANTEE, and is VALID ONLY for the equipment identified hereon for use under the Commission's Rules and Regulations listed below. |
| FCC IDENTIFIER: | KA2WL6610APEB1 |
| Name of Grantee: | D-Link Corporation |
| Equipment Class: | Digital Transmission System |
| Notes: | Unified AC Concurrent Dual-band PoE Access Point |
| Grant Notes | FCC Rule Parts | Frequency Range (MHZ) | Output Watts | Frequency Tolerance | Emission Designator |
| CC MO | 15C | 2412.0 - 2462.0 | 0.9 |
| Output power listed is conducted. The antenna(s) used for this transmitter must be used to provide a separation distance of at least 20 cm from all persons and must not be co-located or operating in conjunction with any other antenna or transmitter. End-users must be provided with antenna installation instructions and transmitter operating conditions for satisfying RF exposure compliance. This device has 20/40 MHz bandwidth modes. |
| CC: | This device is certified pursuant to two different Part 15 rules sections. |
| MO: | This Multiple Input Multiple Output (MIMO) device was evaluated for multiple transmitted signals as indicated in the filing. |
EAS Grant - Application oXlQoUInntjzGt7xRZyEZQ==
| COPY |
FEDERAL COMMUNICATIONS COMMISSION WASHINGTON, D.C. 20554 GRANT OF EQUIPMENT AUTHORIZATION |
COPY |
| Certification |
|
D-Link Corporation 14420 Myford Road Suite 100 Irvine, CA 92606 United States |
Date of Grant: 05/15/2017 Application Dated: 05/10/2017 |
| Attention: Brett Adair , General Counsel |
| NOT TRANSFERABLE |
| EQUIPMENT AUTHORIZATION is hereby issued to the named GRANTEE, and is VALID ONLY for the equipment identified hereon for use under the Commission's Rules and Regulations listed below. |
| FCC IDENTIFIER: | KA2WL6610APEB1 |
| Name of Grantee: | D-Link Corporation |
| Equipment Class: | Digital Transmission System |
| Notes: | Unified AC Concurrent Dual-band PoE Access Point |
| Modular Type: | Does not apply |
| Grant Notes | FCC Rule Parts | Frequency Range (MHZ) | Output Watts | Frequency Tolerance | Emission Designator |
| CC MO | 15C | 2412.0 - 2462.0 | 0.9 |
| Output power listed is conducted. The antenna(s) used for this transmitter must be used to provide a separation distance of at least 20 cm from all persons and must not be co-located or operating in conjunction with any other antenna or transmitter. End-users must be provided with antenna installation instructions and transmitter operating conditions for satisfying RF exposure compliance. This device has 20/40 MHz bandwidth modes. |
| CC: | This device is certified pursuant to two different Part 15 rules sections. |
| MO: | This Multiple Input Multiple Output (MIMO) device was evaluated for multiple transmitted signals as indicated in the filing. |
