TP329 14 CH FRS TRANSCEIVER Teardown Internal... - FCC ID KLLTP-329

FCC ID KLLTP-329

Internal Photos

14 CH FRS TRANSCEIVER

by Tekcom Industries Limited

Document preview loads when visible.

Document Details

FCC IDKLLTP-329
Document ID414589
Document TypeInternal Photos
DescriptionInternal Photos
Document Title9
ApplicantTekcom Industries Limited
Equipment Class14 CH FRS TRANSCEIVER
Product CodeTP329
Application ID/V074DoGtJ31BXkfsi9q4A==
Application PurposeOriginal Equipment
Application Date2004-04-15
Frequency Range462.563-467.713 MHz
FRN0007839798
Test FirmTimco Engineering, Inc.
Certified ByArthur S.M. Kwan Managing Director
Short-Term ConfidentialityNo
Long-Term ConfidentialityNo
Grant DeferralNo
Modular EquipmentDoes not apply
Composite DeviceNo
Composite PartNo
Submitted2004-04-15
Available2004-04-15
Created2004-03-11
Modified2004-03-11
Pages3
File TypeAdobe Acrobat PDF
File Size673597
File SHA-256b87d656d5a6e88334e60cf75d135546d039367acf5abb8c6e9a4cbd8a6d233cb
PDF Metadata Authorerin
PDF Metadata ProducerAcrobat Distiller 6.0 (Windows) erin
FCC.gov SourcesFCC.gov 414589
