MI16433 RECEIVER FOR MACHINE TOOLS... - FCC ID KQGMI16-433

FCC ID KQGMI16-433

technical spec

RECEIVER FOR MACHINE TOOLS TELEMETRY RX

by Renishaw plc

Document preview loads when visible.

Document Details

FCC IDKQGMI16-433
Document ID254311
Document TypeOperational Description
Descriptiontechnical spec
Document TitleMP18-433MHz-Techn
ApplicantRenishaw plc
Equipment ClassRECEIVER FOR MACHINE TOOLS TELEMETRY RX
Product CodeMI16433
Application IDfE20bMxUMzOdQjFK0tPaGA==
Application PurposeOriginal Equipment
Application Date2002-11-08
Frequency Range433.075-434.775 MHz
FRN0007524929
Test FirmEMITECH Angers
Certified BySERGE CRESSON
Short-Term ConfidentialityNo
Long-Term ConfidentialityNo
Grant DeferralNo
Modular EquipmentDoes not apply
Composite DeviceNo
Composite PartYes
Submitted2002-07-03
Available2002-11-08
Created2002-05-03
Modified2002-05-03
Pages6
File TypeAdobe Acrobat PDF
File Size103011
File SHA-256fa43c2a7f44dd9dae7581dfc8e225ec1f3dac8d1bc16c8e24382cdf2bc90c0b1
PDF Metadata ProducerMicrosoft Word - MP18_433MHz.doc Acrobat PDFWriter 4.0 pour Windows
FCC.gov SourcesFCC.gov 254311
