6074RC01TX RC Car Block Diagram - FCC ID KTU-6074-RC01-TX

FCC ID KTU-6074-RC01-TX

Block Diagram

RC Car

by Supertoys Industrial Co Ltd

Document preview loads when visible.

Document Details

FCC IDKTU-6074-RC01-TX
Document ID338305
Document TypeBlock Diagram
DescriptionBlock Diagram
ApplicantSupertoys Industrial Co Ltd
Equipment ClassRC Car
Product Code6074RC01TX
Application IDIRgxNRl8WsWsi6flqvKCXA==
Application PurposeOriginal Equipment
Application Date2003-07-08
Frequency Range49.86 MHz
FRN0017837923
Test FirmIntertek Testing Services Hong Kong
Certified ByWilbur Ng Manager
Short-Term ConfidentialityNo
Long-Term ConfidentialityNo
Grant DeferralNo
Modular EquipmentDoes not apply
Composite DeviceNo
Composite PartYes
Submitted2003-07-08
Available2003-07-08
Created2003-07-05
Modified2003-07-05
Pages1
File TypeAdobe Acrobat PDF
File Size14103
File SHA-25634905d4248f6954500b99d8ba7fd2bdd4e877451aee29fa523a3f64c57409c6f
PDF Metadata AuthorITS ELECTRIC TOY
PDF Metadata ProducerHP 9100C Digital Sender
FCC.gov SourcesFCC.gov 338305
