MX3FG 2.4G Radio Transmitter Schematics - FCC ID L73MX-3FG

FCC ID L73MX-3FG

Schematics

2.4G Radio Transmitter

by Sanwa Electronic Instrument Co Ltd

Document preview loads when visible.

Document Details

FCC IDL73MX-3FG
Document ID1012297
Document TypeSchematics
DescriptionSchematics
Document TitleNone
ApplicantSanwa Electronic Instrument Co Ltd
Equipment Class2.4G Radio Transmitter
Product CodeMX3FG
Application IDzVvO32mubxA+nLc7WwfUbQ==
Application PurposeOriginal Equipment
Application Date2008-10-07
Frequency Range2415-2465 MHz
FRN0009195744
Test FirmShenzhen Huatongwei International Insp. Co., Ltd
Certified ByYoshiki Ito Engineering Manager
Short-Term ConfidentialityNo
Long-Term ConfidentialityNo
Grant DeferralNo
Modular EquipmentDoes not apply
Composite DeviceNo
Composite PartNo
Submitted2008-10-07
Available2008-10-07
Created2008-09-12
Modified2008-09-25
Pages2
File TypeAdobe Acrobat PDF
File Size683117
File SHA-25666f058d88ba0b39155b50e4f5869c502af2bbf787deef5a7ca040242526fa8d2
PDF Metadata AuthorNone
PDF Metadata CreatorAdobe Illustrator 10.0
PDF Metadata ProducerAdobe PDF library 5.00
FCC.gov SourcesFCC.gov 1012297
