764016 Remote Control Transmitter Block Diagram - FCC ID L9G764016

FCC ID L9G764016

block diagram

Remote Control Transmitter

by Artin Industrial Co Ltd

Document preview loads when visible.

Document Details

FCC IDL9G764016
Document ID326842
Document TypeBlock Diagram
Descriptionblock diagram
ApplicantArtin Industrial Co Ltd
Equipment ClassRemote Control Transmitter
Product Code764016
Application IDzPE/o1OwVY0+iYpq2zMfFg==
Application PurposeOriginal Equipment
Application Date2003-05-20
Frequency Range26.96-27.28 MHz
FRN0018034330
Test FirmSGS IECC Limited
Certified ByRonnie Yung Director
Short-Term ConfidentialityNo
Long-Term ConfidentialityNo
Grant DeferralNo
Modular EquipmentDoes not apply
Composite DeviceNo
Composite PartNo
Submitted2003-05-20
Available2003-05-20
Created2003-05-05
Modified2003-05-05
Pages1
File TypeAdobe Acrobat PDF
File Size17017
File SHA-256f001ebe850fd7c00a8eb71a006d1d6f1f976b75c3939748e60d092a2718687c0
PDF Metadata ProducerAcrobat 5.0 Scan Plug-in for Windows Acrobat 5.0 Scan Plug-in for Windows
FCC.gov SourcesFCC.gov 326842
