S84002T Remote Control Transmitter Block Diagram - FCC ID L9GS84002T

FCC ID L9GS84002T

block diagram

Remote Control Transmitter

by Artin Industrial Co Ltd

Document preview loads when visible.

Document Details

FCC IDL9GS84002T
Document ID327632
Document TypeBlock Diagram
Descriptionblock diagram
ApplicantArtin Industrial Co Ltd
Equipment ClassRemote Control Transmitter
Product CodeS84002T
Application IDDdxWy0m69/m9ZT9IaVH8fw==
Application PurposeOriginal Equipment
Application Date2003-05-23
Frequency Range49.82-49.9 MHz
FRN0018034330
Test FirmSGS IECC Limited
Certified ByRonnie Yung Director
Short-Term ConfidentialityNo
Long-Term ConfidentialityNo
Grant DeferralNo
Modular EquipmentDoes not apply
Composite DeviceNo
Composite PartYes
Submitted2003-05-23
Available2003-05-23
Created2003-05-12
Modified2003-05-12
Pages1
File TypeAdobe Acrobat PDF
File Size11034
File SHA-256b48cdc53987a5779a0942be3e5e68488fd6ca4ab38bf70480d00caf35e6ac2bf
PDF Metadata ProducerAcrobat 5.0 Scan Plug-in for Windows Acrobat 5.0 Scan Plug-in for Windows
FCC.gov SourcesFCC.gov 327632
