FCC ID L9VWAP-5940
Wireless Video Bridge
by Comtrend Corporation
Grantee Code: L9V Product Code: WAP5940
Latest application date: 2017-03-04
Device Images
FCC ID Device Details
| FCC ID | L9VWAP-5940 |
|---|---|
| Mirrors | fcc.id | gov | fccid.ai |
| Grantee Code | L9V |
| Product Code | WAP5940 |
| Applicant Business | Comtrend Corporation 🇹🇼 |
| Related Domains |  comtrend.com |
| Equipment Class | Wireless Video Bridge |
| Test Firm | SPORTON International Inc. |
Operating Frequencies
| Frequency Range | Application Purpose | Final Action Date |
|---|---|---|
| 5180-5240 MHz | Original Equipment | 2017-03-04 |
Exhibits
| Document | Type | Available | File |
|---|---|---|---|
| User manual | Users Manual | 2017-03-04 | PDF 1.8 MB |
| Internal photos | Internal Photos | 2017-03-04 | PDF 1.6 MB |
| External photos | External Photos | 2017-03-04 | PDF 512 KB |
| Label | ID Label/Location Info | 2017-03-04 | PDF 353.3 KB |
| Test setup | Test Setup Photos | 2017-03-04 | PDF 625.8 KB |
| Test report | Test Report | 2017-03-04 | PDF 2.8 MB |
| Cover letter | Cover Letter(s) | 2017-03-04 | PDF 30.8 KB |
| RF Exposure | RF Exposure Info | 2017-03-04 | PDF 153 KB |
| Block Diagram Metadata only | Block Diagram | PDF 89.4 KB | |
| Schematics Metadata only | Schematics | PDF 508 KB | |
| Operational Description Metadata only | Operational Description | PDF 124.1 KB | |
| Software Security Metadata only | SDR Software/Security Inf | PDF 81.2 KB |
Application Information
| Application ID | +Klt5cofIqCj86FqPc7KbA== |
|---|---|
| Final Action Date | 2017-03-04 |
| Application Purpose | Original Equipment |
| Applicant FRN | 0019788504 |
| Model | WAP-5940 |
| Frequency Range | 5180-5240 MHz |
| Equipment Class | NII - Unlicensed National Information Infrastructure TX |
| Device Description | Wireless Video Bridge |
| Responsible Party | Bill Wang, bill.wang@comtrend.com , +886-2-2999-8261 |
| Test Firm | Alex Chen, SPORTON International Inc., alex@sporton.com.tw  , 886-3-327-3456 |
| TCB Email | stuart.beck@nemko.com  |
| TCB Scope | A4: UNII devices & low power transmitters using spread spectrum techniques |
| Short-Term Confidentiality | No |
| Long-Term Confidentiality | Yes |
| Grant Deferral | No |
| Modular Equipment | Does not apply |
| Composite Device | No |
| Composite Part | No |
| Cognitive Radio | No |
| Authorization Waiver | No |
| Authorization Waiver Approved | No |
| Section 5301 Certification | Yes |
| Related OET Knowledge DataBase Inquiry | No |
| Grant Comments | Output power listed is conducted. This device has 20 MHz, 40MHz, and 80MHz bandwidth modes. The antenna(s) used for this transmitter must be installed to provide a separation distance of at least 20cm from all persons and must not be co-located or operating in conjunction with any other antenna or transmitter. End-users and installers must be provided with antenna installation instruction and transmitter operating conditions for satisfying RF exposure compliance. Operation in 5150-5250MHz is for indoor use only. |
Applications
| Application ID | Date | Purpose |
|---|---|---|
| +Klt5cofIqCj86FqPc7KbA== | 2017-03-04 | Original Equipment |
Equipment Authorization
Grants
TCB Grant - Application +Klt5cofIqCj86FqPc7KbA==
| TCB | GRANT OF EQUIPMENT AUTHORIZATION |
TCB |
| Certification | ||
| Issued Under the Authority of the | ||
| Federal Communications Commission | ||
| By: |
|
Nemko North America, INC. 303 River Road Ottawa, Ontario, K1V 1H2 Canada |
Date of Grant: 03/04/2017 Application Dated: 03/04/2017 |
| Comtrend Corporation |
| 3F-1, 10 Lane 609, Chung Hsin Road, Section 5, |
| San Chung Dist, |
| New Taipei City,, 24159 Taiwan |
| Attention: Bill Wang |
| NOT TRANSFERABLE |
| EQUIPMENT AUTHORIZATION is hereby issued to the named GRANTEE, and is VALID ONLY for the equipment identified hereon for use under the Commission's Rules and Regulations listed below. |
| FCC IDENTIFIER: | L9VWAP-5940 |
| Name of Grantee: | Comtrend Corporation |
| Equipment Class: | Unlicensed National Information Infrastructure TX |
| Notes: | Wireless Video Bridge |
| Grant Notes | FCC Rule Parts | Frequency Range (MHZ) | Output Watts | Frequency Tolerance | Emission Designator |
| 38 MO | 15E | 5180.0 - 5240.0 | 0.2393 | ||
| 38 MO | 15E | 5745.0 - 5825.0 | 0.3396 |
| Output power listed is conducted. This device has 20 MHz, 40MHz, and 80MHz bandwidth modes. The antenna(s) used for this transmitter must be installed to provide a separation distance of at least 20cm from all persons and must not be co-located or operating in conjunction with any other antenna or transmitter. End-users and installers must be provided with antenna installation instruction and transmitter operating conditions for satisfying RF exposure compliance. Operation in 5150-5250MHz is for indoor use only. |
| 38: | This device has shown compliance, in all grant-listed U-NII sub-bands, with the new rules for U-NII devices adopted under Docket No. 13-49 and may be marketed, manufactured or imported after the June 1, 2016 transition deadline. |
| MO: | This Multiple Input Multiple Output (MIMO) device was evaluated for multiple transmitted signals as indicated in the filing. |
EAS Grant - Application +Klt5cofIqCj86FqPc7KbA==
| COPY |
FEDERAL COMMUNICATIONS COMMISSION WASHINGTON, D.C. 20554 GRANT OF EQUIPMENT AUTHORIZATION |
COPY |
| Certification |
|
Comtrend Corporation 3F-1, 10 Lane 609, Chung Hsin Road, Section 5, San Chung Dist, New Taipei City,, 24159 Taiwan |
Date of Grant: 03/04/2017 Application Dated: 03/04/2017 |
| Attention: Bill Wang |
| NOT TRANSFERABLE |
| EQUIPMENT AUTHORIZATION is hereby issued to the named GRANTEE, and is VALID ONLY for the equipment identified hereon for use under the Commission's Rules and Regulations listed below. |
| FCC IDENTIFIER: | L9VWAP-5940 |
| Name of Grantee: | Comtrend Corporation |
| Equipment Class: | Unlicensed National Information Infrastructure TX |
| Notes: | Wireless Video Bridge |
| Modular Type: | Does not apply |
| Grant Notes | FCC Rule Parts | Frequency Range (MHZ) | Output Watts | Frequency Tolerance | Emission Designator |
| 38 MO | 15E | 5180.0 - 5240.0 | 0.2393 | ||
| 38 MO | 15E | 5745.0 - 5825.0 | 0.3396 |
| Output power listed is conducted. This device has 20 MHz, 40MHz, and 80MHz bandwidth modes. The antenna(s) used for this transmitter must be installed to provide a separation distance of at least 20cm from all persons and must not be co-located or operating in conjunction with any other antenna or transmitter. End-users and installers must be provided with antenna installation instruction and transmitter operating conditions for satisfying RF exposure compliance. Operation in 5150-5250MHz is for indoor use only. |
| 38: | This device has shown compliance, in all grant-listed U-NII sub-bands, with the new rules for U-NII devices adopted under Docket No. 13-49 and may be marketed, manufactured or imported after the June 1, 2016 transition deadline. |
| MO: | This Multiple Input Multiple Output (MIMO) device was evaluated for multiple transmitted signals as indicated in the filing. |
