FMR2XKF Level-probing Radar Teardown... - FCC ID LCGFMR2XKF
FCC ID LCGFMR2XKF
internal_pictures
Level-probing Radar
Document preview loads when visible.
Document Details
| FCC ID | LCGFMR2XKF |
|---|---|
| Document ID | 3254541 |
| Document Type | Internal Photos |
| Description | internal_pictures |
| Applicant | Endress and Hauser SE Co. KG |
| Equipment Class | Level-probing Radar |
| Product Code | FMR2XKF |
| Application ID | 1Hzi8R/BXDvlO3AOo1uEaA== |
| Application Purpose | Original Equipment |
| Application Date | 2017-01-11 |
| Frequency Range | 2402-2480 MHz |
| FRN | 0010915122 |
| Test Firm | CTC advanced GmbH |
| Certified By | Gerd Bechtel Mr. |
| Short-Term Confidentiality | No |
| Long-Term Confidentiality | No |
| Grant Deferral | No |
| Modular Equipment | Does not apply |
| Composite Device | Yes |
| Composite Part | No |
| Submitted | 2017-01-11 |
| Available | 2017-01-11 |
| Created | 2016-05-13 |
| Modified | 2016-05-13 |
| Pages | 6 |
| File Type | Adobe Acrobat PDF |
| File Size | 1614767 |
| File SHA-256 | 5e9b577978d0aba351cac80775b18aabede8b170ba2f775e201e2815261d5b3a |
| PDF Metadata Author | Gaetzi, Lukas |
| PDF Metadata Producer | Microsoft® Word 2016 Microsoft® Word 2016 |
| FCC.gov Sources | FCC.gov 3254541, FCC.gov 3254515 |
