FCC ID LDK102103
Cisco Aironet 802.11ac Dual Band Outdoor Access Point
by Cisco Systems Inc
Grantee Code: LDK Product Code: 102103
Latest application date: 2016-12-09
Device Images
FCC ID Device Details
Operating Frequencies
| Frequency Range | Application Purpose | Final Action Date |
|---|---|---|
| 5180-5240 MHz | Original Equipment | 2016-12-09 |
| 2412-2462 MHz | Original Equipment | 2016-12-09 |
Exhibits
| Document | Type | Available | File |
|---|---|---|---|
| 1560hig_1 of 2 | Users Manual | 2016-12-09 | PDF 4.8 MB |
| 1560hig_2 of 2 | Users Manual | 2016-12-09 | PDF 3 MB |
| 1562E Internal Photos | Internal Photos | 2016-12-09 | PDF 798.3 KB |
| 1562E External Photos | External Photos | 2016-12-09 | PDF 507.5 KB |
| 1562E Label location_LABELS -B | ID Label/Location Info | 2016-12-09 | PDF 148.4 KB |
| AIR-AP1562E-B-K9 label | ID Label/Location Info | 2016-12-09 | PDF 165 KB |
| 1562 Test Setup Photos | Test Setup Photos | 2016-12-09 | PDF 382.9 KB |
| 1562E DFS Report | Test Report | 2016-12-09 | PDF 3.3 MB |
| 1562E Series 5150-5250 FCC Report | Test Report | 2016-12-09 | PDF 5.5 MB |
| 1562E Series 5250-5350 FCC Report | Test Report | 2016-12-09 | PDF 5 MB |
| 1562E Series 5470-5725 FCC Report | Test Report | 2016-12-09 | PDF 4.2 MB |
| 1562E Series 5725-5850 FCC Report | Test Report | 2016-12-09 | PDF 5.3 MB |
| 1562E Series_2412-2462 MHz_Report_1 of 2 | Test Report | 2016-12-09 | PDF 3.9 MB |
| 1562E Series_2412-2462 MHz_Report_2 of 2 | Test Report | 2016-12-09 | PDF 5.3 MB |
| FCC IC Agent Auth Letter (UL Verification Services Inc)_Cisco | Cover Letter(s) | 2016-12-09 | PDF 16.2 KB |
| FCC Request for Long Term Confidentiality Letter_1562_102103 | Cover Letter(s) | 2016-12-09 | PDF 71.3 KB |
| Letter_of_authorization_FCC | Cover Letter(s) | 2016-12-09 | PDF 27.5 KB |
| 1562E MPE Metadata only | RF Exposure Info | 2016-12-09 | PDF 311.6 KB |
| 1562E MPE_2 | RF Exposure Info | 2016-12-09 | PDF 345.2 KB |
| 1562E BlockDiagram Metadata only | Block Diagram | PDF 60.2 KB | |
| 1562E Series_Schematic Metadata only | Schematics | PDF 327.9 KB | |
| 1562_E_I_D_RF_Theory_of_Operation Metadata only | Operational Description | PDF 527.5 KB | |
| Power control per GUI for different antennas (sample) Metadata only | Operational Description | PDF 432.3 KB | |
| 280 D02 v01r03 U-NII Device SW Security Statement_1562 Metadata only | SDR Software/Security Inf | PDF 143.3 KB | |
| KDB 594280 D02 v01r03 U-NII Device SW Security Statement_1562 Metadata only | SDR Software/Security Inf | PDF 143.3 KB | |
| Software Defined Radio Security Description Metadata only | SDR Software/Security Inf | PDF 33.8 KB |
Application Information
| Application ID | NpUTGEIaxBv2Qh1J7M9IjQ== |
|---|---|
| Final Action Date | 2016-12-09 |
| Application Purpose | Original Equipment |
| Applicant FRN | 0004968939 |
| Model | 102103 |
| Frequency Range | 5180-5240 MHz |
| Equipment Class | NII - Unlicensed National Information Infrastructure TX |
| Device Description | Cisco Aironet 802.11ac Dual Band Outdoor Access Point |
| Responsible Party | Samuel Kim, Manager, Engineering, samukim@cisco.com  , 408-527-1446 |
| Agent | Ana Ana Ana, UL Verification Services, Inc., Ana.M.Aumentado@ul.com  , 510-319-4007 |
| Technical Contact | Ana Aumentado, UL Verification Services Inc, Ana.M.Aumentado@ul.com , 5103194007 |
| Test Firm | Gerald Thorpe, Cisco Systems, Inc., gthorpe@cisco.com , 408-525-7602 |
| TCB Email | certnotice@ccsemc.com  |
| TCB Scope | A4: UNII devices & low power transmitters using spread spectrum techniques |
| Short-Term Confidentiality | No |
| Long-Term Confidentiality | Yes |
| Grant Deferral | No |
| Modular Equipment | Does not apply |
| Composite Device | Yes |
| Composite Part | No |
| Cognitive Radio | Yes |
| Authorization Waiver | No |
| Authorization Waiver Approved | No |
| Section 5301 Certification | Yes |
| Related OET Knowledge DataBase Inquiry | Yes |
| Grant Comments | This device has 20 MHz, 40 MHz and 80 MHz bandwidth modes. This device is capable of 2x2 MIMO operation. Output power is maximum combined conducted power. The documented antennas with 8dBi and more gain used for this transmitter must be installed to provide a separation distance of at least 60 cm from all persons, those with less than 8dBi at least 25 cm. The specified antennas must not be co-located or operating in conjunction with any other antenna or transmitter. Users and installers must be provided with antenna installation instructions and transmitter operating conditions for satisfying RF exposure compliance. |
Applications
| Application ID | Date | Purpose |
|---|---|---|
| NpUTGEIaxBv2Qh1J7M9IjQ== | 2016-12-09 | Original Equipment |
| HOe6qUg/AoAHA8q/9sSZ5A== | 2016-12-09 | Original Equipment |
Equipment Authorization
Grants
TCB Grant - Application NpUTGEIaxBv2Qh1J7M9IjQ==
| TCB | GRANT OF EQUIPMENT AUTHORIZATION |
TCB |
| Certification | ||
| Issued Under the Authority of the | ||
| Federal Communications Commission | ||
| By: |
|
UL Verification Services Inc. (formerly UL CCS) 47173 Benicia Street Fremont, CA 94538 |
Date of Grant: 12/09/2016 Application Dated: 11/30/2016 |
| Cisco Systems Inc |
| 125 West Tasman Drive |
| San Jose, CA 95134-1706 |
| Attention: Samuel Kim , Manager, Engineering |
| NOT TRANSFERABLE |
| EQUIPMENT AUTHORIZATION is hereby issued to the named GRANTEE, and is VALID ONLY for the equipment identified hereon for use under the Commission's Rules and Regulations listed below. |
| FCC IDENTIFIER: | LDK102103 |
| Name of Grantee: | Cisco Systems Inc |
| Equipment Class: | Unlicensed National Information Infrastructure TX |
| Notes: | Cisco Aironet 802.11ac Dual Band Outdoor Access Point |
| Grant Notes | FCC Rule Parts | Frequency Range (MHZ) | Output Watts | Frequency Tolerance | Emission Designator |
| 36 38 CC MO ND | 15E | 5180.0 - 5240.0 | 0.479 | ||
| 36 38 CC MO ND | 15E | 5260.0 - 5320.0 | 0.229 | ||
| 36 38 CC MO ND | 15E | 5500.0 - 5720.0 | 0.246 | ||
| 36 38 CC MO ND | 15E | 5745.0 - 5825.0 | 0.49 |
| This device has 20 MHz, 40 MHz and 80 MHz bandwidth modes. This device is capable of 2x2 MIMO operation. Output power is maximum combined conducted power. The documented antennas with 8dBi and more gain used for this transmitter must be installed to provide a separation distance of at least 60 cm from all persons, those with less than 8dBi at least 25 cm. The specified antennas must not be co-located or operating in conjunction with any other antenna or transmitter. Users and installers must be provided with antenna installation instructions and transmitter operating conditions for satisfying RF exposure compliance. |
| 36: | Certain antennas used with this equipment require a minimum cable length, or have output power limitations as documented in the application. |
| 38: | This device has shown compliance, in all grant-listed U-NII sub-bands, with the new rules for U-NII devices adopted under Docket No. 13-49 and may be marketed, manufactured or imported after the June 1, 2016 transition deadline. |
| CC: | This device is certified pursuant to two different Part 15 rules sections. |
| MO: | This Multiple Input Multiple Output (MIMO) device was evaluated for multiple transmitted signals as indicated in the filing. |
| ND: | This UNII device complies with the Transmit Power Control (TPC) and Dynamic Frequency Selection (DFS) requirements in Section 15.407(h). |
EAS Grant - Application NpUTGEIaxBv2Qh1J7M9IjQ==
| COPY |
FEDERAL COMMUNICATIONS COMMISSION WASHINGTON, D.C. 20554 GRANT OF EQUIPMENT AUTHORIZATION |
COPY |
| Certification |
|
Cisco Systems Inc 125 West Tasman Drive San Jose, CA 95134-1706 United States |
Date of Grant: 12/09/2016 Application Dated: 11/30/2016 |
| Attention: Samuel Kim , Manager, Engineering |
| NOT TRANSFERABLE |
| EQUIPMENT AUTHORIZATION is hereby issued to the named GRANTEE, and is VALID ONLY for the equipment identified hereon for use under the Commission's Rules and Regulations listed below. |
| FCC IDENTIFIER: | LDK102103 |
| Name of Grantee: | Cisco Systems Inc |
| Equipment Class: | Unlicensed National Information Infrastructure TX |
| Notes: | Cisco Aironet 802.11ac Dual Band Outdoor Access Point |
| Modular Type: | Does not apply |
| Grant Notes | FCC Rule Parts | Frequency Range (MHZ) | Output Watts | Frequency Tolerance | Emission Designator |
| 36 38 CC MO ND | 15E | 5180.0 - 5240.0 | 0.479 | ||
| 36 38 CC MO ND | 15E | 5260.0 - 5320.0 | 0.229 | ||
| 36 38 CC MO ND | 15E | 5500.0 - 5720.0 | 0.246 | ||
| 36 38 CC MO ND | 15E | 5745.0 - 5825.0 | 0.49 |
| This device has 20 MHz, 40 MHz and 80 MHz bandwidth modes. This device is capable of 2x2 MIMO operation. Output power is maximum combined conducted power. The documented antennas with 8dBi and more gain used for this transmitter must be installed to provide a separation distance of at least 60 cm from all persons, those with less than 8dBi at least 25 cm. The specified antennas must not be co-located or operating in conjunction with any other antenna or transmitter. Users and installers must be provided with antenna installation instructions and transmitter operating conditions for satisfying RF exposure compliance. |
| 36: | Certain antennas used with this equipment require a minimum cable length, or have output power limitations as documented in the application. |
| 38: | This device has shown compliance, in all grant-listed U-NII sub-bands, with the new rules for U-NII devices adopted under Docket No. 13-49 and may be marketed, manufactured or imported after the June 1, 2016 transition deadline. |
| CC: | This device is certified pursuant to two different Part 15 rules sections. |
| MO: | This Multiple Input Multiple Output (MIMO) device was evaluated for multiple transmitted signals as indicated in the filing. |
| ND: | This UNII device complies with the Transmit Power Control (TPC) and Dynamic Frequency Selection (DFS) requirements in Section 15.407(h). |
