WL5T Wireless Speaker Schematics - FCC ID LE2WL-5T
FCC ID LE2WL-5T
Schematic Diagram
Wireless Speaker
Document preview loads when visible.
Document Details
| FCC ID | LE2WL-5T |
|---|---|
| Document ID | 233125 |
| Document Type | Schematics |
| Description | Schematic Diagram |
| Applicant | JSW Pacific Corporation |
| Equipment Class | Wireless Speaker |
| Product Code | WL5T |
| Application ID | +JlZ5PmLdILGmwoK0FR2Ag== |
| Application Purpose | Original Equipment |
| Application Date | 2002-03-25 |
| Frequency Range | 2412 MHz |
| FRN | 0006323752 |
| Test Firm | Electronics Testing Center, Taiwan |
| Certified By | Will Yauo Manager ( AGENT ) |
| Short-Term Confidentiality | No |
| Long-Term Confidentiality | No |
| Grant Deferral | No |
| Modular Equipment | Does not apply |
| Composite Device | No |
| Composite Part | No |
| Submitted | 2002-03-25 |
| Available | 2002-03-25 |
| Created | 2002-03-18 |
| Modified | 2002-03-18 |
| Pages | 2 |
| File Type | Adobe Acrobat PDF |
| File Size | 61453 |
| File SHA-256 | 4b48db5c301af106d3bfcc4e30f9dcf0008e7df9bf4d4683a3dab8399e5acc9e |
| PDF Metadata Producer | Acrobat 5.0 Scan Plug-in for Windows Acrobat 5.0 Scan Plug-in for Windows |
| FCC.gov Sources | FCC.gov 233125 |
Related FCC Exhibits
| Document | Type | Available | File |
|---|---|---|---|
| User Manual | Users Manual | 2002-03-25 | PDF 20.2 KB |
| Internal Photos | Internal Photos | 2002-03-25 | PDF 1.1 MB |
| External Photos | External Photos | 2002-03-25 | PDF 538.9 KB |
| FCC ID label format and location | ID Label/Location Info | 2002-03-25 | PDF 25.4 KB |
| Block Diagram | Block Diagram | 2002-03-25 | PDF 7.4 KB |
| Schematic Diagram | Schematics | 2002-03-25 | PDF 60 KB |
| Operational Description | Operational Description | 2002-03-25 | PDF 3.1 KB |
| Test Setup Photos | Test Setup Photos | 2002-03-25 | PDF 380.2 KB |
| Test Report | Test Report | 2002-03-25 | PDF 537.3 KB |
