R3010UW Ethernet Router Schematics - FCC ID LNQR3010UW
FCC ID LNQR3010UW
Schematics
Ethernet Router
Document preview loads when visible.
Document Details
| FCC ID | LNQR3010UW |
|---|---|
| Document ID | 221956 |
| Document Type | Schematics |
| Description | Schematics |
| Document Title | reno5add.PDF |
| Applicant | Actiontec Electronics Inc |
| Equipment Class | Ethernet Router |
| Product Code | R3010UW |
| Application ID | ADzl5vMtdSEZqkM7SuxfRA== |
| Application Purpose | Original Equipment |
| Application Date | 2002-01-14 |
| Frequency Range | 2412.41-2462.9 MHz |
| FRN | 0005810783 |
| Test Firm | Bay Area Compliance Laboratory |
| Certified By | Alice Yeung System/Process Analyst |
| Short-Term Confidentiality | No |
| Long-Term Confidentiality | No |
| Grant Deferral | No |
| Modular Equipment | Does not apply |
| Composite Device | No |
| Composite Part | No |
| Submitted | 2002-01-22 |
| Available | 2002-01-14 |
| Pages | 12 |
| File Type | Adobe Acrobat PDF |
| File Size | 314406 |
| File SHA-256 | 005b8c75ab27d53d1fcb4926be653e0a72bb8dcf76857dfc8d03ee190f472915 |
| PDF Metadata Author | Unknown |
| PDF Metadata Producer | reno5add.opj Acrobat PDFWriter 3.02 for Windows |
| FCC.gov Sources | FCC.gov 221956 |
