FCC ID LNQWEB5500
802.11ac Wireless Network Extender
by Actiontec Electronics Inc
Grantee Code: LNQ Product Code: WEB5500
Latest application date: 2017-05-04
Device Images
FCC ID Device Details
| FCC ID | LNQWEB5500 |
|---|---|
| Mirrors | fcc.id | gov | fccid.ai |
| Grantee Code | LNQ |
| Product Code | WEB5500 |
| Applicant Business | Actiontec Electronics Inc 🇺🇸 |
| Related Domains |  actiontec.com |
| Equipment Class | 802.11ac Wireless Network Extender |
| Test Firm | MiCOM Labs |
Operating Frequencies
| Frequency Range | Application Purpose | Final Action Date |
|---|---|---|
| 5180-5240 MHz | Original Equipment | 2017-05-04 |
| 2412-2462 MHz | Original Equipment | 2017-05-04 |
Exhibits
| Document | Type | Available | File |
|---|---|---|---|
| User Manual (1 of 2) | Users Manual | 2017-10-24 | PDF 592.7 KB |
| User Manual (2 of 2) | Users Manual | 2017-10-24 | PDF 430.7 KB |
| Internal Photos | Internal Photos | 2017-10-24 | PDF 1.5 MB |
| External Photos | External Photos | 2017-10-24 | PDF 603.1 KB |
| Label and Location | ID Label/Location Info | 2017-05-04 | PDF 71.7 KB |
| Test Setup Photos | Test Setup Photos | 2017-10-24 | PDF 1 MB |
| Test Setup Photos | Test Setup Photos | 2017-10-24 | PDF 872.1 KB |
| DTS Test Report (1 of 2, Conducted) | Test Report | 2017-05-04 | PDF 3.6 MB |
| DTS Test Report (2 of 2, Radiated) | Test Report | 2017-05-04 | PDF 915.1 KB |
| NII Test Report (1 of 2, Conducted) | Test Report | 2017-05-04 | PDF 5.4 MB |
| NII Test Report (2 of 2, Radiated) | Test Report | 2017-05-04 | PDF 1.3 MB |
| Test Report (15B) | Test Report | 2017-05-04 | PDF 705.8 KB |
| NII Software Configuration Control Declaration | Attestation Statements | 2017-05-04 | PDF 36.4 KB |
| Software Defined Radio (SDR) Declaration | Attestation Statements | 2017-05-04 | PDF 37 KB |
| Authorization Letter | Cover Letter(s) | 2017-05-04 | PDF 38.1 KB |
| Confidentiality Letter | Cover Letter(s) | 2017-05-04 | PDF 43.4 KB |
| Software Defined Radio (SDR) Request Letter | Cover Letter(s) | 2017-05-04 | PDF 36.3 KB |
| RF Exposure Report | RF Exposure Info | 2017-05-04 | PDF 134 KB |
| Block Diagram Metadata only | Block Diagram | PDF 124.9 KB | |
| Schematics Metadata only | Schematics | PDF 994.9 KB | |
| NII Software security operational description Metadata only | SDR Software/Security Inf | PDF 107.5 KB | |
| Operational Description Metadata only | Operational Description | PDF 83.3 KB | |
| Software Defined Radio (SDR) Security description Metadata only | SDR Software/Security Inf | PDF 314 KB | |
| BOM List Metadata only | Parts List/Tune Up Info | PDF 133.2 KB |
Application Information
| Application ID | hvb/l+HF708SICwqXCg5XA== |
|---|---|
| Final Action Date | 2017-05-04 |
| Application Purpose | Original Equipment |
| Applicant FRN | 0005810783 |
| Model | WEB5500 |
| Frequency Range | 5180-5240 MHz |
| Equipment Class | NII - Unlicensed National Information Infrastructure TX |
| Device Description | 802.11ac Wireless Network Extender |
| Responsible Party | Brian Henrichs, President, bhenrichs@actiontec.com , 4088579658 |
| Technical Contact | John Martin, Actiontec Electronics Inc, jmartin@actiontec.com , 4087527700 |
| Test Firm | Gordon Hurst, MiCOM Labs, gordon_hurst@micomlabs.com  , 925-462-0304 |
| TCB Email | certification@micomlabs.com |
| TCB Scope | A4: UNII devices & low power transmitters using spread spectrum techniques |
| Short-Term Confidentiality | Yes |
| Short-Term Confidentiality Date | 10/24/2017 |
| Long-Term Confidentiality | Yes |
| Grant Deferral | No |
| Modular Equipment | Does not apply |
| Composite Device | Yes |
| Composite Part | No |
| Cognitive Radio | Yes |
| Authorization Waiver | No |
| Authorization Waiver Approved | No |
| Section 5301 Certification | Yes |
| Related OET Knowledge DataBase Inquiry | Yes |
| Grant Comments | Software Defined Radio. Output power listed is maximum combined conducted power. Device is a 4x4 MIMO as is described in the filing. This device contains 20, 40 and 80 MHz signal bandwidth. The antennas used with this transmitter must be installed to provide a minimum separation distance of at least 30 cm from all persons. End-users must be provided with operating procedures for satisfying RF exposure compliance. |
