TRXL7202 Ankle Tag Teardown Internal Photos - FCC ID LSQ-TRXL-720-2

FCC ID LSQ-TRXL-720-2

Internal Photos II

Ankle Tag

by Attenti

Document preview loads when visible.

Document Details

FCC IDLSQ-TRXL-720-2
Document ID694199
Document TypeInternal Photos
DescriptionInternal Photos II
ApplicantAttenti
Equipment ClassAnkle Tag
Product CodeTRXL7202
Application IDi9Kb3RwV7km9cNYLpkqH1w==
Application PurposeOriginal Equipment
Application Date2006-08-16
Frequency Range433.92 MHz
FRN0007846728
Test FirmElbit Systems Land C41Tadiran Ltd.
Certified ByGil Gemer Vice President R&D;
Short-Term ConfidentialityNo
Long-Term ConfidentialityNo
Grant DeferralNo
Modular EquipmentDoes not apply
Composite DeviceNo
Composite PartNo
Submitted2006-08-16
Available2006-08-16
Created2006-08-16
Modified2006-08-16
Pages1
File TypeAdobe Acrobat PDF
File Size460859
File SHA-25619847c2645990bf5bcfe8ff1bb9fa70776c548d3d62ec51bc011a829b6340b63
PDF Metadata ProducerAdobe Acrobat 6.02 Adobe Acrobat 6.02 Image Conversion Plug-in
FCC.gov SourcesFCC.gov 694199
