TRXS8402 Bracelet Transmitter Teardown... - FCC ID LSQ-TRXS-840-2

FCC ID LSQ-TRXS-840-2

Internal Photos

Bracelet Transmitter

by 3M Electronic Monitoring, Inc.

Document preview loads when visible.

Document Details

FCC IDLSQ-TRXS-840-2
Document ID1398379
Document TypeInternal Photos
DescriptionInternal Photos
Document TitleTRXS-840-2 internal_Photographs
Applicant3M Electronic Monitoring, Inc.
Equipment ClassBracelet Transmitter
Product CodeTRXS8402
Application IDRuBI40Jr71uqaNG0GB2MMA==
Application PurposeOriginal Equipment
Application Date2010-12-30
Frequency Range433.92 MHz
FRN0007846728
Test FirmITL Product Testing LTD
Certified ByGil Gemer CTO
Short-Term ConfidentialityNo
Long-Term ConfidentialityNo
Short-Term Confidentiality Date06/28/2011
Grant DeferralNo
Modular EquipmentDoes not apply
Composite DeviceNo
Composite PartNo
Submitted2010-12-30
Available2010-12-30
Created2010-12-28
Modified2010-12-28
Pages2
File TypeAdobe Acrobat PDF
File Size101252
File SHA-2568d5c763c58e84a90574f76651dcb3ce0d2e7a58458ce8e2d57fc3bdaed9635e1
PDF Metadata AuthorAradd
PDF Metadata CreatorPrimoPDF http://www.primopdf.com
PDF Metadata ProducerNitro PDF PrimoPDF
FCC.gov SourcesFCC.gov 1398379
