TXL7002 Ankle Tag Test Setup Photos - FCC ID LSQ-TXL-700-2

FCC ID LSQ-TXL-700-2

Test Setup Photos

Ankle Tag

by Attenti

Document preview loads when visible.

Document Details

FCC IDLSQ-TXL-700-2
Document ID557163
Document TypeTest Setup Photos
DescriptionTest Setup Photos
Document TitleTest Setup Pictures For TXL-700-2
ApplicantAttenti
Equipment ClassAnkle Tag
Product CodeTXL7002
Application IDZ4zdbgoyGUXOJJ+uOsPaCg==
Application PurposeOriginal Equipment
Application Date2005-06-30
Frequency Range433.92 MHz
FRN0007846728
Test FirmElbit Systems Land C41Tadiran Ltd.
Certified ByGil Gemer Vice President R&D;
Short-Term ConfidentialityNo
Long-Term ConfidentialityNo
Grant DeferralNo
Modular EquipmentDoes not apply
Composite DeviceNo
Composite PartNo
Submitted2005-06-30
Available2005-06-30
Created2005-06-28
Modified2005-06-28
Pages3
File TypeAdobe Acrobat PDF
File Size179568
File SHA-2565df81801ae23d2e9eca87d5b07158be0a0c7212f51221663c23112df6f500c82
PDF Metadata AuthorACER
PDF Metadata ProducerAcrobat Distiller 6.0.1 (Windows) ACER
FCC.gov SourcesFCC.gov 557163
