331223 Inductive Toys Schematics - FCC ID LU9331223

FCC ID LU9331223

Circuit Diagram

Inductive Toys

by MGA Entertainment (HK) Ltd.

Document preview loads when visible.

Document Details

FCC IDLU9331223
Document ID682617
Document TypeSchematics
DescriptionCircuit Diagram
ApplicantMGA Entertainment (HK) Ltd.
Equipment ClassInductive Toys
Product Code331223
Application IDUZUFwKQHK4AIlOE3RqgHsg==
Application PurposeOriginal Equipment
Application Date2006-07-18
Frequency Range13.56 MHz
FRN0018148171
Test FirmIntertek Testing Services Hong Kong
Certified ByAnthony Chan Supervisor
Short-Term ConfidentialityNo
Long-Term ConfidentialityNo
Grant DeferralNo
Modular EquipmentDoes not apply
Composite DeviceNo
Composite PartNo
Submitted2006-07-18
Available2006-07-18
Created2006-07-11
Modified2006-07-11
Pages4
File TypeAdobe Acrobat PDF
File Size255540
File SHA-25651a0e5df41f89080b4099c16e934cc20ea540c5d5dc78bdaef329e333916fd8a
FCC.gov SourcesFCC.gov 682617
