FCC ID M38-ST-3118C
Private land mobile radio
by Ranger Communications (M) SDN. BHD.
Grantee Code: M38 Product Code: ST3118C
Latest application date: 2016-02-01
Device Images
FCC ID Device Details
| FCC ID | M38-ST-3118C |
|---|---|
| Mirrors | fcc.id | gov | fccid.ai |
| Grantee Code | M38 |
| Product Code | ST3118C |
| Applicant Business | Ranger Communications (M) SDN. BHD. 🇲🇾 |
| Related Domains |  ranger.com.my  quietek.com |
| Equipment Class | Private land mobile radio |
| Test Firm | DEKRA TESTING AND CERTIFICATION CO., LTD. |
Operating Frequencies
| Frequency Range | Application Purpose | Final Action Date |
|---|---|---|
| 421-470 MHz | Original Equipment | 2016-02-01 |
Exhibits
| Document | Type | Available | File |
|---|---|---|---|
| User manual | Users Manual | 2016-02-01 | PDF 2.6 MB |
| Internal photo | Internal Photos | 2016-02-01 | PDF 535 KB |
| External photo | External Photos | 2016-02-01 | PDF 190.3 KB |
| ID Label | ID Label/Location Info | 2016-02-01 | PDF 54.6 KB |
| Label location info | ID Label/Location Info | 2016-02-01 | PDF 107.7 KB |
| Test setup photo | Test Setup Photos | 2016-02-01 | PDF 364.5 KB |
| Test report | Test Report | 2016-02-01 | PDF 3 MB |
| Attestation | Cover Letter(s) | 2016-02-01 | PDF 119.7 KB |
| DoC Attestation Letter | Cover Letter(s) | 2016-02-01 | PDF 13.3 KB |
| Confidentiality | Cover Letter(s) | 2016-02-01 | PDF 122.2 KB |
| EF letter form | Cover Letter(s) | 2016-02-01 | PDF 12.6 KB |
| RF Exposure | RF Exposure Info | 2016-02-01 | PDF 167.5 KB |
| Block diagram Metadata only | Block Diagram | PDF 481.6 KB | |
| Schematics Metadata only | Schematics | PDF 2 MB | |
| Operational description Metadata only | Operational Description | PDF 2.4 MB | |
| Parts list (BOM) Metadata only | Parts List/Tune Up Info | PDF 695.3 KB | |
| Tune up procedure Metadata only | Parts List/Tune Up Info | PDF 658.3 KB |
Application Information
| Application ID | 2V39nIywqssQFOT+v0y75Q== |
|---|---|
| Final Action Date | 2016-02-01 |
| Application Purpose | Original Equipment |
| Applicant FRN | 0024388951 |
| Model | ST-3118C |
| Frequency Range | 421-470 MHz |
| Equipment Class | TNB - Licensed Non-Broadcast Station Transmitter |
| Device Description | Private land mobile radio |
| Responsible Party | FOOK BOON JOON, Jcw@ranger.com.my , 60 6-2835729 |
| Agent | Roy Roy Roy, QuieTek Corporation, +886-3-592-8858 |
| Technical Contact | Neil Yeh, QuieTek Corporation, neilyeh@quietek.com , 886-3-592-8858 |
| Non-Technical Contact | Sabrina Tsai, QuieTek Corporation, sabrinatsai@quietek.com , 886-3-592-8858 |
| Test Firm | Warren Lin, DEKRA TESTING AND CERTIFICATION CO., LTD., warren.lin@dekra.com  , +886-3-582-8001 |
| TCB Email | certification@telefication.com  |
| TCB Scope | B3: Maritime & Aviation Radio Services equipment in 47 CFR parts 80 & 87 |
| Short-Term Confidentiality | No |
| Long-Term Confidentiality | Yes |
| Grant Deferral | No |
| Modular Equipment | Does not apply |
| Composite Device | No |
| Composite Part | No |
| Cognitive Radio | No |
| Authorization Waiver | No |
| Authorization Waiver Approved | No |
| Section 5301 Certification | Yes |
| Related OET Knowledge DataBase Inquiry | No |
| Grant Comments | Power output listed is at the antenna connector. The antenna(s) used for this transmitter must not exceed 2.15 dBi gain and must be installed to provide a minimum separation distance of 105cm from all persons as specified in the filing. End-users and installers must be provided with antenna installation instructions and transmitter operating conditions for satisfying RF exposure compliance. |
