XTXX RFID reader Label Diagram - FCC ID M39XTXX

FCC ID M39XTXX

Label

RFID reader

Document preview loads when visible.

Document Details

FCC ID	M39XTXX
Document ID	2228801
Document Type	ID Label/Location Info
Description	Label
Document Title	XT-1 Labels
Applicant	Tagmaster AB
Equipment Class	RFID reader
Product Code	XTXX
Application ID	B23lBbFbvG1neECEA172Cg==
Application Purpose	Original Equipment
Application Date	2014-03-31
Frequency Range	902.75-927.25 MHz
FRN	0014700058
Test Firm	Intertek Semko AB
Certified By	Vathana Ven Senior Project Engineer
Short-Term Confidentiality	No
Long-Term Confidentiality	No
Grant Deferral	No
Modular Equipment	Does not apply
Composite Device	No
Composite Part	No
Submitted	2014-03-31
Available	2014-03-31
Created	2014-02-05
Modified	2014-02-05
Pages	1
File Type	Adobe Acrobat PDF
File Size	45440
File SHA-256	9b1819db87f88025af007ffdc62596fdb62f7db30b7f3e723043b6c3bc32149a
PDF Metadata Author	Marcus Dahl Organization
PDF Metadata Producer	Marcus Dahl Adobe PDF Library 10.0
FCC.gov Sources	FCC.gov 2228801

Document	Type	Available	File
Manual	Users Manual	2014-03-31	PDF 1.5 MB
Internal photos	Internal Photos	2014-03-31	PDF 214.7 KB
External photos	External Photos	2014-03-31	PDF 105.5 KB
Label	ID Label/Location Info	2014-03-31	PDF 44.4 KB
Label location	ID Label/Location Info	2014-03-31	PDF 2.8 MB
Test setup photos	Test Setup Photos	2014-03-31	PDF 232.7 KB
Test report	Test Report	2014-03-31	PDF 1.2 MB
Cover letter	Cover Letter(s)	2014-03-31	PDF 338.9 KB
RF Exposure info	RF Exposure Info	2014-03-31	PDF 291.9 KB
Block diagram Metadata only	Block Diagram		PDF 32 KB
Schematics Metadata only	Schematics		PDF 80.6 KB
Operational description Metadata only	Operational Description		PDF 220.1 KB
Part lists Metadata only	Parts List/Tune Up Info		PDF 11.2 KB
