T1505 Wireless Low Power Medical Paging... - FCC ID M74T1505

FCC ID M74T1505

Revised Schematic

Wireless Low Power Medical Paging Transmitter

by Long Range Solutions, LLC

Document preview loads when visible.

Document Details

FCC IDM74T1505
Document ID408371
Document TypeSchematics
DescriptionRevised Schematic
ApplicantLong Range Solutions, LLC
Equipment ClassWireless Low Power Medical Paging Transmitter
Product CodeT1505
Application ID0Or1G3Q+R+Lv8J/c/vmk/A==
Application PurposeOriginal Equipment
Application Date2004-03-25
Frequency Range467.75 MHz
FRN0030081863
Test FirmTDK RF Solutions, Inc.
Certified ByJeffery A. Link President, Professional Testing Inc.
Short-Term ConfidentialityNo
Long-Term ConfidentialityNo
Grant DeferralNo
Modular EquipmentDoes not apply
Composite DeviceNo
Composite PartNo
Submitted2004-03-25
Available2004-03-25
Created2003-08-26
Modified2004-01-23
Pages4
File TypeAdobe Acrobat PDF
File Size187074
File SHA-256672ed4db253fff4c05e1353ce323f3760eb3d3e9ae96fb9a3455d51948974abe
PDF Metadata ProducerVisage eXPert PDF VSPDF.DLL http://www.visagesoft.com
FCC.gov SourcesFCC.gov 408371
