E2006L Mobile phone External Photos - FCC ID M9HE2006L
FCC ID M9HE2006L
External Photos
Mobile phone
Document preview loads when visible.
Document Details
| FCC ID | M9HE2006L |
|---|---|
| Document ID | 686384 |
| Document Type | External Photos |
| Description | External Photos |
| Document Title | untitled |
| Applicant | Sagem Wireless |
| Equipment Class | Mobile phone |
| Product Code | E2006L |
| Application ID | CosYduGh8y2OrSmPhjYMsA== |
| Application Purpose | Original Equipment |
| Application Date | 2006-07-26 |
| Frequency Range | 1850.2-1909.8 MHz |
| FRN | 0006731509 |
| Test Firm | SGS Taiwan Ltd. |
| Certified By | Miles Xu Agent |
| Short-Term Confidentiality | No |
| Long-Term Confidentiality | No |
| Grant Deferral | No |
| Modular Equipment | Does not apply |
| Composite Device | Yes |
| Composite Part | No |
| Submitted | 2006-07-26 |
| Available | 2006-07-26 |
| Created | 2006-07-25 |
| Modified | 2006-07-25 |
| Pages | 5 |
| File Type | Adobe Acrobat PDF |
| File Size | 219900 |
| File SHA-256 | b4d21bce1d98439d416ee9ba67bbee9122bd9ed5fb40f71e15a3dba4d9aa89d4 |
| PDF Metadata Producer | Acrobat Distiller 6.0 (Windows) |
| FCC.gov Sources | FCC.gov 686384 |
