CYWB1500 pHin Wireless Bridge Label Diagram - FCC ID MCL-CYWB1500
FCC ID MCL-CYWB1500
Lable and Location.pdf
pHin Wireless Bridge
Document preview loads when visible.
Document Details
| FCC ID | MCL-CYWB1500 |
|---|---|
| Document ID | 2998692 |
| Document Type | ID Label/Location Info |
| Description | Lable and Location.pdf |
| Applicant | HON HAI Precision Ind. Co., Ltd. |
| Equipment Class | pHin Wireless Bridge |
| Product Code | CYWB1500 |
| Application ID | qoH80KUOoR3FWO+I1KFuRw== |
| Application Purpose | Original Equipment |
| Application Date | 2016-05-23 |
| Frequency Range | 2402-2480 MHz |
| FRN | 0010777365 |
| Test Firm | Bureau Veritas Shenzhen Co., Ltd. Dongguan Branch |
| Certified By | Sam Tung |
| Short-Term Confidentiality | No |
| Long-Term Confidentiality | No |
| Grant Deferral | No |
| Modular Equipment | Does not apply |
| Composite Device | Yes |
| Composite Part | No |
| Submitted | 2016-05-20 |
| Available | 2016-05-23 |
| Created | 2016-04-21 |
| Modified | 2016-04-21 |
| Pages | 1 |
| File Type | Adobe Acrobat PDF |
| File Size | 88025 |
| File SHA-256 | bbfc88a678da4bdc5b121f9ec2dbc7fb7c036ef37febf6eb0c6f0532c8c4076e |
| PDF Metadata Producer | Foxit Reader PDF Printer Version 7.0.1.831 |
| FCC.gov Sources | FCC.gov 2998692, FCC.gov 2998651 |
