J27H02301 WLAN Module Test Setup Photos - FCC ID MCLJ27H02301

FCC ID MCLJ27H02301

test setup photo

WLAN Module

by HON HAI Precision Ind. Co., Ltd.

Document preview loads when visible.

Document Details

FCC IDMCLJ27H02301
Document ID1735072
Document TypeTest Setup Photos
Descriptiontest setup photo
Document Title32FE0108-HO-01-A-R1(FCC15C_Foxconn)
ApplicantHON HAI Precision Ind. Co., Ltd.
Equipment ClassWLAN Module
Product CodeJ27H02301
Application IDR18at6vyzrMAGwORtsFy6Q==
Application PurposeOriginal Equipment
Application Date2012-07-03
Frequency Range2412-2462 MHz
FRN0010777365
Test FirmUL Japan, Inc.
Certified ByRio Chen
Short-Term ConfidentialityNo
Long-Term ConfidentialityNo
Short-Term Confidentiality Date12/30/2012
Grant DeferralNo
Modular EquipmentLimited Single Modular Approval
Composite DeviceNo
Composite PartNo
Submitted2012-07-03
Available2012-12-30
Created2012-06-27
Modified2012-06-27
Pages7
File TypeAdobe Acrobat PDF
File Size1401049
File SHA-25641366be3c045738bd06c5cdee5ae806eb63fc5e14ea70ecd55e24159484e638b
PDF Metadata Author17348
PDF Metadata CreatorPScript5.dll Version 5.2.2
PDF Metadata ProducerAcrobat Distiller 9.3.3 (Windows)
FCC.gov SourcesFCC.gov 1735072
