FCC ID MCQ-PS2CTH
XBEE Pro S2C TH Module
by Digi International Inc
Grantee Code: MCQ Product Code: PS2CTH
Latest application date: 2016-05-02
Device Images
FCC ID Device Details
Operating Frequencies
| Frequency Range | Application Purpose | Final Action Date |
|---|---|---|
| 2405-2480 MHz | Class II permissive change or modification of presently authorized equipment | 2016-05-02 |
| 2405-2480 MHz | Class II permissive change or modification of presently authorized equipment | 2015-12-09 |
| 2405-2475 MHz | Original Equipment | 2014-08-06 |
Exhibits
| Document | Type | Available | File |
|---|---|---|---|
| User Manual | Users Manual | 2016-05-02 | PDF 1.8 MB |
| User Manual | Users Manual | 2015-12-09 | PDF 3.6 MB |
| User Manual | Users Manual | 2014-08-06 | PDF 3.7 MB |
| Internal Photos | Internal Photos | 2014-08-06 | PDF 3.1 MB |
| External Photos | External Photos | 2014-08-06 | PDF 3.2 MB |
| External Photos_Antennas | External Photos | 2014-08-06 | PDF 504.3 KB |
| Label & Location | ID Label/Location Info | 2014-08-06 | PDF 805 KB |
| Setup Photos | Test Setup Photos | 2016-05-02 | PDF 647 KB |
| Test Setup Photos | Test Setup Photos | 2015-12-09 | PDF 532.9 KB |
| Test Setup Photos | Test Setup Photos | 2014-08-06 | PDF 468.3 KB |
| Test Report | Test Report | 2016-05-02 | PDF 919 KB |
| Test Report | Test Report | 2015-12-09 | PDF 946 KB |
| Test Report | Test Report | 2014-08-06 | PDF 962.2 KB |
| Grantee Contact Authorization | Attestation Statements | 2016-05-02 | PDF 135.7 KB |
| Authority_Grantee Contact | Attestation Statements | 2014-08-06 | PDF 135.7 KB |
| Duty Cycle Attestation | Attestation Statements | 2014-08-06 | PDF 134.7 KB |
| Modular Approval Attestation | Attestation Statements | 2014-08-06 | PDF 947.1 KB |
| Part 15B Verification Letter | Attestation Statements | 2014-08-06 | PDF 132.1 KB |
| Authority Letter | Cover Letter(s) | 2016-05-02 | PDF 206.1 KB |
| C2PC Request Letter | Cover Letter(s) | 2016-05-02 | PDF 189.5 KB |
| Confidentiality Letter | Cover Letter(s) | 2016-05-02 | PDF 175.5 KB |
| Cover Letter | Cover Letter(s) | 2016-05-02 | PDF 95.1 KB |
| Agent Authorization Letter | Cover Letter(s) | 2015-12-09 | PDF 198 KB |
| C2PC Letter | Cover Letter(s) | 2015-12-09 | PDF 31.5 KB |
| Confidentiality Request | Cover Letter(s) | 2015-12-09 | PDF 34.6 KB |
| Cover Letter | Cover Letter(s) | 2015-12-09 | PDF 61.9 KB |
| Grantee Authorization | Cover Letter(s) | 2015-12-09 | PDF 135.7 KB |
| Authority Letter | Cover Letter(s) | 2014-08-06 | PDF 185.7 KB |
| Confidentiality Letter | Cover Letter(s) | 2014-08-06 | PDF 151.7 KB |
| Cover Letter | Cover Letter(s) | 2014-08-06 | PDF 90.7 KB |
| RF Exposure Info | RF Exposure Info | 2016-05-02 | PDF 101 KB |
| MPE Evaluation | RF Exposure Info | 2015-12-09 | PDF 73.4 KB |
| RF Exposure Info | RF Exposure Info | 2014-08-06 | PDF 73 KB |
| Block Diagram Metadata only | Block Diagram | PDF 125.9 KB | |
| Schematics Metadata only | Schematics | PDF 1.3 MB | |
| Operation Description Metadata only | Operational Description | PDF 122.2 KB | |
| Operational Description Metadata only | Operational Description | PDF 19.6 KB | |
| Operational Description Metadata only | Operational Description | PDF 35.1 KB | |
| Operational Description_Duty Cycle Metadata only | Operational Description | PDF 19.6 KB |
Application Information
| Application ID | WiXaO31nc89YY2+8RHbQyA== |
|---|---|
| Final Action Date | 2016-05-02 |
| Application Purpose | Class II permissive change or modification of presently authorized equipment |
| Applicant FRN | 0010283307 |
| Model | PS2CTH |
| Frequency Range | 2405-2480 MHz |
| Equipment Class | DTS - Digital Transmission System |
| Device Description | XBEE Pro S2C TH Module |
| Responsible Party | Erik Reynolds, Director of Engineering, erik.reynolds@digi.com  , 952-912-4248 |
| Agent | Dharmajit Dharmajit Dharmajit, UltraTech Engineering Labs Inc, dharmajit@ultratech-labs.com  , 9058291570 |
| Test Firm | Tri Luu, UltraTech Engineering Labs Inc., tri@ultratech-labs.com , 905-829-1570 |
| TCB Email | vic@ultratech-labs.com |
| TCB Scope | A4: UNII devices & low power transmitters using spread spectrum techniques |
| Short-Term Confidentiality | No |
| Long-Term Confidentiality | Yes |
| Grant Deferral | No |
| Modular Equipment | Single Modular Approval |
| Composite Device | No |
| Composite Part | No |
| Cognitive Radio | No |
| Authorization Waiver | No |
| Authorization Waiver Approved | No |
| Section 5301 Certification | Yes |
| Related OET Knowledge DataBase Inquiry | No |
| Grant Comments | Single Modular Approval. Power output listed is conducted. Output power is continuously variable from 1.37 mWatts to 80.54 mWatts. This module may only be installed by the OEM or an OEM integrator. For operations in mobile RF Exposure conditions, the antenna used for this transmitter must be installed to provide a separation distance of at least 20 cm from all persons. Antenna used for this transmitter must not be co-located or operating in conjunction with any other antenna or transmitter. Class II Permissive Change to enable additional channel (2480 MHz). Power output is reduced to 1.671 mWatts by firmware as described in this filing. Class II Permissive Change adds a new firmware option which uses RF duty cycle of up to 66% and output power limited to 0.07998 Watts and frequency to 2405-2470 MHz. |
