FCC ID MCQ-S2CTH
XBee S2C TH Module
by Digi International Inc
Grantee Code: MCQ Product Code: S2CTH
Latest application date: 2016-04-13
Device Images
FCC ID Device Details
Operating Frequencies
| Frequency Range | Application Purpose | Final Action Date |
|---|---|---|
| 2405-2480 MHz | Class II permissive change or modification of presently authorized equipment | 2016-04-13 |
| 2405-2480 MHz | Original Equipment | 2014-05-23 |
Exhibits
| Document | Type | Available | File |
|---|---|---|---|
| User Manual | Users Manual | 2016-04-13 | PDF 1.8 MB |
| User Manual | Users Manual | 2014-05-23 | PDF 3.6 MB |
| Internal Photos | Internal Photos | 2014-05-23 | PDF 661.7 KB |
| Antenna Photo | External Photos | 2014-05-23 | PDF 504.3 KB |
| External Photos | External Photos | 2014-05-23 | PDF 593.9 KB |
| Label & Location | ID Label/Location Info | 2014-05-23 | PDF 274.6 KB |
| Setup Photos | Test Setup Photos | 2016-04-13 | PDF 547.5 KB |
| Test Setup Photos | Test Setup Photos | 2014-05-23 | PDF 410.5 KB |
| Test Report | Test Report | 2016-04-13 | PDF 803.6 KB |
| Test Report | Test Report | 2014-05-23 | PDF 846.7 KB |
| Modular Approval Attestation | Attestation Statements | 2014-05-23 | PDF 959.8 KB |
| Part 15B Verification Letter | Attestation Statements | 2014-05-23 | PDF 155.2 KB |
| Authority Letter | Cover Letter(s) | 2016-04-13 | PDF 189.7 KB |
| C2PC Request Letter | Cover Letter(s) | 2016-04-13 | PDF 165.7 KB |
| Confidentiality Letter | Cover Letter(s) | 2016-04-13 | PDF 155.1 KB |
| Cover Letter | Cover Letter(s) | 2016-04-13 | PDF 95.1 KB |
| Grantee Contact Authorization | Cover Letter(s) | 2016-04-13 | PDF 135.7 KB |
| Authority Letter | Cover Letter(s) | 2014-05-23 | PDF 196.6 KB |
| Authority_Grantee Contact | Cover Letter(s) | 2014-05-23 | PDF 135.7 KB |
| Confidentiality Letter | Cover Letter(s) | 2014-05-23 | PDF 176.8 KB |
| Cover Letter | Cover Letter(s) | 2014-05-23 | PDF 56.7 KB |
| RF Exposure Info | RF Exposure Info | 2016-04-13 | PDF 101.5 KB |
| RF Exposure Info | RF Exposure Info | 2014-05-23 | PDF 104.4 KB |
| Block Diagram Metadata only | Block Diagram | PDF 173.8 KB | |
| Schematics Metadata only | Schematics | PDF 1.1 MB | |
| Operation Description Metadata only | Operational Description | PDF 121.5 KB | |
| Operational Description Metadata only | Operational Description | PDF 90 KB |
Application Information
| Application ID | CWb4AUHScnRGJ9P8q2qC3w== |
|---|---|
| Final Action Date | 2016-04-13 |
| Application Purpose | Class II permissive change or modification of presently authorized equipment |
| Applicant FRN | 0010283307 |
| Model | S2CTH |
| Frequency Range | 2405-2480 MHz |
| Equipment Class | DTS - Digital Transmission System |
| Device Description | XBee S2C TH Module |
| Responsible Party | Erik Reynolds, Director of Engineering, erik.reynolds@digi.com  , 952-912-4248 |
| Agent | Dharmajit Dharmajit Dharmajit, UltraTech Engineering Labs Inc, dharmajit@ultratech-labs.com  , 9058291570 |
| Test Firm | Tri Luu, UltraTech Engineering Labs Inc., tri@ultratech-labs.com , 905-829-1570 |
| TCB Email | vic@ultratech-labs.com |
| TCB Scope | A4: UNII devices & low power transmitters using spread spectrum techniques |
| Short-Term Confidentiality | No |
| Long-Term Confidentiality | Yes |
| Grant Deferral | No |
| Modular Equipment | Single Modular Approval |
| Composite Device | No |
| Composite Part | No |
| Cognitive Radio | No |
| Authorization Waiver | No |
| Authorization Waiver Approved | No |
| Section 5301 Certification | Yes |
| Related OET Knowledge DataBase Inquiry | No |
| Grant Comments | Single Modular Approval, Power output listed is conducted. This module may only be installed by the OEM or an OEM integrator. For operations in mobile RF Exposure conditions, the antenna used for this transmitter must be installed to provide a separation distance of at least 20 cm from all persons. Antenna used for this transmitter must not be co-located or operating in conjunction with any other antenna or transmitter. Note : Output power is continuously variable from the value listed to 0.03% of this value. Class II Permissive Change adds a new firmware option which uses an RF duty cycle of up to 66% and output power limited to 0.00538 Watts. |
