FCC ID MQ4AM7520
2T2R 802.11b/g/n/ac Module
by Abocom Systems Inc
Grantee Code: MQ4 Product Code: AM7520
Latest application date: 2016-03-31
Device Images
FCC ID Device Details
| FCC ID | MQ4AM7520 |
|---|---|
| Mirrors | fcc.id | gov | fccid.ai |
| Grantee Code | MQ4 |
| Product Code | AM7520 |
| Applicant Business | Abocom Systems Inc 🇹🇼 |
| Related Domains |  abocom.com.tw |
| Equipment Class | 2T2R 802.11b/g/n/ac Module |
| Test Firm | SPORTON International Inc. |
Operating Frequencies
| Frequency Range | Application Purpose | Final Action Date |
|---|---|---|
| 2412-2462 MHz | Original Equipment | 2016-03-31 |
| 5180-5240 MHz | Original Equipment | 2016-03-31 |
Exhibits
| Document | Type | Available | File |
|---|---|---|---|
| Users Manual | Users Manual | 2016-03-31 | PDF 196.9 KB |
| Internal Photos | Internal Photos | 2016-03-31 | PDF 383.8 KB |
| External Photos | External Photos | 2016-03-31 | PDF 109 KB |
| Label & Label Location | ID Label/Location Info | 2016-03-31 | PDF 279.4 KB |
| Test Setup Photos | Test Setup Photos | 2016-03-31 | PDF 384.1 KB |
| Test Report DTS | Test Report | 2016-03-31 | PDF 1.4 MB |
| Test Report NII | Test Report | 2016-03-31 | PDF 1.9 MB |
| Confidentiality Request Letter | Cover Letter(s) | 2016-03-31 | PDF 29 KB |
| DOC Letter | Cover Letter(s) | 2016-03-31 | PDF 23.5 KB |
| Modular Approval Letter | Cover Letter(s) | 2016-03-31 | PDF 26 KB |
| POA | Cover Letter(s) | 2016-03-31 | PDF 24.8 KB |
| POA Grantee Contact Person | Cover Letter(s) | 2016-03-31 | PDF 9.9 KB |
| RF Exposure MPE | RF Exposure Info | 2016-03-31 | PDF 175.3 KB |
| Block Diagram Metadata only | Block Diagram | PDF 36.1 KB | |
| Schematics Metadata only | Schematics | PDF 57.9 KB | |
| Operational Description Metadata only | Operational Description | PDF 106.9 KB | |
| Operational Description Software Security Metadata only | Operational Description | PDF 47.3 KB |
Application Information
| Application ID | kyQndzJDN6607EJncJ7lOQ== |
|---|---|
| Final Action Date | 2016-03-31 |
| Application Purpose | Original Equipment |
| Applicant FRN | 0009543745 |
| Model | AM7520 |
| Frequency Range | 2412-2462 MHz |
| Equipment Class | DTS - Digital Transmission System |
| Device Description | 2T2R 802.11b/g/n/ac Module |
| Responsible Party | Harry Huang, Manager, harryh@abocom.com.tw , 886-3-758-0777 |
| Test Firm | Sharon Jiang, SPORTON International Inc., sharonjiang@sporton.com.tw  , 886-3-656-9065 |
| TCB Email | TEI@TIMCOENGR.COM  |
| TCB Scope | A4: UNII devices & low power transmitters using spread spectrum techniques |
| Short-Term Confidentiality | No |
| Long-Term Confidentiality | Yes |
| Grant Deferral | No |
| Modular Equipment | Single Modular Approval |
| Composite Device | Yes |
| Composite Part | No |
| Cognitive Radio | No |
| Authorization Waiver | No |
| Authorization Waiver Approved | No |
| Section 5301 Certification | Yes |
| Related OET Knowledge DataBase Inquiry | No |
| Grant Comments | Single Modular Approval. Power listed is maximum combined conducted output power. This device is restricted to fixed and mobile use only. Device operates with specific antennas in MIMO configurations as described in this filing. Approval is limited to OEM installation only. Compliance of this device in all final host configurations is the responsibility of the Grantee. The antenna(s) used for this transmitter must be installed to provide a separation distance of at least 20 cm from all persons and must not transmit simultaneously with any other antenna or transmitter, except in accordance with FCC multi-transmitter product procedures. OEM integrators must be provided with antenna installation instructions and labeling requirements for finished products. OEM integrators and end-Users must be provided with transmitter operation conditions for satisfying RF exposure compliance. This grant is valid only when the device is sold to OEM integrators and the OEM integrators are instructed to ensure that the end user has no manual instructions to remove or install the device. Separate approval is required for all other operating configurations, including portable configurations with respect to 2.1093 and different antenna configurations. This device has 20and 40 MHz bandwidth modes. |
