FCC ID MQ4AMB7220
2x2 11ac+BT4.0 Wi-Fi Module
by Abocom Systems Inc
Grantee Code: MQ4 Product Code: AMB7220
Latest application date: 2016-03-11
Device Images
FCC ID Device Details
| FCC ID | MQ4AMB7220 |
|---|---|
| Mirrors | fcc.id | gov | fccid.ai |
| Grantee Code | MQ4 |
| Product Code | AMB7220 |
| Applicant Business | Abocom Systems Inc 🇹🇼 |
| Related Domains |  abocom.com.tw |
| Equipment Class | 2x2 11ac+BT4.0 Wi-Fi Module |
| Test Firm | SPORTON International Inc. |
Operating Frequencies
| Frequency Range | Application Purpose | Final Action Date |
|---|---|---|
| 2402-2480 MHz | Original Equipment | 2016-03-11 |
| 2402-2480 MHz | Original Equipment | 2016-03-11 |
| 5180-5240 MHz | Original Equipment | 2016-03-11 |
Exhibits
| Document | Type | Available | File |
|---|---|---|---|
| Users Manual | Users Manual | 2016-03-11 | PDF 194.8 KB |
| Internal Photos | Internal Photos | 2016-03-11 | PDF 245.6 KB |
| External Photos | External Photos | 2016-03-11 | PDF 386.6 KB |
| Label and Location | ID Label/Location Info | 2016-03-11 | PDF 92.1 KB |
| Test Setup Photos BT | Test Setup Photos | 2016-03-11 | PDF 358.9 KB |
| Test Setup Photos WLAN | Test Setup Photos | 2016-03-11 | PDF 326.5 KB |
| Radiated Emission Co Location Report | Test Report | 2016-03-11 | PDF 139.5 KB |
| Radiated Emissions Co Location Report | Test Report | 2016-03-11 | PDF 139.5 KB |
| Test Report 5G NII | Test Report | 2016-03-11 | PDF 2.5 MB |
| Test Report BT Metadata only | Test Report | 2016-03-11 | PDF 358.9 KB |
| Test Report DSS BT2.1 | Test Report | 2016-03-11 | PDF 1.6 MB |
| Test Report DTS 2.4G | Test Report | 2016-03-11 | PDF 1.5 MB |
| Test Report DTS BT 4.0 | Test Report | 2016-03-11 | PDF 688 KB |
| Test Report WLAN Metadata only | Test Report | 2016-03-11 | PDF 326.5 KB |
| Confidentiality Request Letter | Cover Letter(s) | 2016-03-11 | PDF 29 KB |
| DOC Letter | Cover Letter(s) | 2016-03-11 | PDF 25 KB |
| Modular Approval Letter | Cover Letter(s) | 2016-03-11 | PDF 25.6 KB |
| POA | Cover Letter(s) | 2016-03-11 | PDF 26 KB |
| POA Grantee Contact Person | Cover Letter(s) | 2016-03-11 | PDF 9.5 KB |
| Human Exposure | RF Exposure Info | 2016-03-11 | PDF 185.5 KB |
| Block Diagram Metadata only | Block Diagram | PDF 80.5 KB | |
| Schematics Metadata only | Schematics | PDF 56 KB | |
| Operational Description Metadata only | Operational Description | PDF 104.1 KB | |
| Operational Description Software Security Metadata only | Operational Description | PDF 46.5 KB |
Application Information
| Application ID | q6xSURBwnOQrERWWSTCz9w== |
|---|---|
| Final Action Date | 2016-03-11 |
| Application Purpose | Original Equipment |
| Applicant FRN | 0009543745 |
| Model | AMB7220 |
| Frequency Range | 2402-2480 MHz |
| Equipment Class | DSS - Part 15 Spread Spectrum Transmitter |
| Device Description | 2x2 11ac+BT4.0 Wi-Fi Module |
| Responsible Party | Harry Huang, Manager, harryh@abocom.com.tw , 886-3-758-0777 |
| Test Firm | Sharon Jiang, SPORTON International Inc., sharonjiang@sporton.com.tw  , 886-3-656-9065 |
| TCB Email | TEI@TIMCOENGR.COM  |
| TCB Scope | A4: UNII devices & low power transmitters using spread spectrum techniques |
| Short-Term Confidentiality | No |
| Long-Term Confidentiality | Yes |
| Grant Deferral | No |
| Modular Equipment | Single Modular Approval |
| Composite Device | Yes |
| Composite Part | No |
| Cognitive Radio | No |
| Authorization Waiver | No |
| Authorization Waiver Approved | No |
| Section 5301 Certification | Yes |
| Related OET Knowledge DataBase Inquiry | No |
| Grant Comments | Single Modular Approval. Power listed is maximum combined conducted output power. This device is restricted to fixed and mobile use only. Device operates with specific antennas in MIMO configurations as described in this filing. Approval is limited to OEM installation only. Compliance of this device in all final host configurations is the responsibility of the Grantee. The antenna(s) used for this transmitter must be installed to provide a separation distance of at least 20 cm from all persons and must not transmit simultaneously with any other antenna or transmitter, except in accordance with FCC multi-transmitter product procedures. OEM integrators must be provided with antenna installation instructions and labeling requirements for finished products. OEM integrators and end-Users must be provided with transmitter operation conditions for satisfying RF exposure compliance. This grant is valid only when the device is sold to OEM integrators and the OEM integrators are instructed to ensure that the end user has no manual instructions to remove or install the device. Separate approval is required for all other operating configurations, including portable configurations with respect to 2.1093 and different antenna configurations. |
