ASFPJ4 TPMS Transmitter External Photos - FCC ID MRXASFPJ4

FCC ID MRXASFPJ4

External Photos

TPMS Transmitter

by Schrader Electronics

Document preview loads when visible.

Document Details

FCC IDMRXASFPJ4
Document ID4904028
Document TypeExternal Photos
DescriptionExternal Photos
ApplicantSchrader Electronics
Equipment ClassTPMS Transmitter
Product CodeASFPJ4
Application IDMMlZG24r22zS86sfvhBPCg==
Application PurposeOriginal Equipment
Application Date2020-09-14
Frequency Range433.92 MHz
FRN0006293260
Test FirmAHD (Amber Helm Development, L.C.)
Certified ByJoseph D. Brunett Executive Director
Short-Term ConfidentialityNo
Long-Term ConfidentialityNo
Grant DeferralNo
Modular EquipmentDoes not apply
Composite DeviceNo
Composite PartNo
Submitted2020-09-14
Available2020-09-14
Created2020-09-09
Modified2020-09-09
Pages3
File TypeAdobe Acrobat PDF
File Size129555
File SHA-256dc51bc2393a3d785a91a67ea1bca826686edd2b456a745e47e62332827da4954
PDF Metadata ProducerNitro Pro (11. 0. 3. 173)
FCC.gov SourcesFCC.gov 4904028
