| Frequency Range | Application Purpose | Final Action Date |
|---|---|---|
| 2412-2462 MHz | Original Equipment | 2016-10-03 |
| 5180-5240 MHz | Original Equipment | 2016-10-03 |
| Document | Type | Available | File |
|---|---|---|---|
| User Manual | Users Manual | 2016-10-03 | PDF 3.6 MB |
| Internal Photo | Internal Photos | 2016-10-03 | PDF 383.1 KB |
| Internal Photos | Internal Photos | 2016-10-03 | PDF 383.1 KB |
| External Photo | External Photos | 2016-10-03 | PDF 188.4 KB |
| External Photos | External Photos | 2016-10-03 | PDF 188.4 KB |
| Label Location | ID Label/Location Info | 2016-10-03 | PDF 72.3 KB |
| Label Sample | ID Label/Location Info | 2016-10-03 | PDF 188.5 KB |
| Test Setup Photos | Test Setup Photos | 2016-10-03 | PDF 450.3 KB |
| Test Report 2.4g-1 | Test Report | 2016-10-03 | PDF 3.4 MB |
| Test Report 2.4g-2 | Test Report | 2016-10-03 | PDF 3.2 MB |
| Test Report 5g-1 | Test Report | 2016-10-03 | PDF 4.9 MB |
| Test Report 5g-2 | Test Report | 2016-10-03 | PDF 1.9 MB |
| Attestation Letter | Cover Letter(s) | 2016-10-03 | PDF 36.8 KB |
| Confidentiality Letter | Cover Letter(s) | 2016-10-03 | PDF 36.1 KB |
| Declaration of Authorization | Cover Letter(s) | 2016-10-03 | PDF 38.4 KB |
| RF Exposure | RF Exposure Info | 2016-10-03 | PDF 96.1 KB |
| Block Diagram Metadata only | Block Diagram | PDF 87.1 KB | |
| Schematics Metadata only | Schematics | PDF 225 KB | |
| Operational Description Metadata only | Operational Description | PDF 32 KB | |
| Software Operating Description Metadata only | Operational Description | PDF 74.9 KB |
| Application ID | WXOLXxL5UmR4tkznvVNnuw== |
|---|---|
| Final Action Date | 2016-10-03 |
| Application Purpose | Original Equipment |
| Applicant FRN | 0005821988 |
| Model | PCEAC1N00 |
| Frequency Range | 2412-2462 MHz |
| Equipment Class | DTS - Digital Transmission System |
| Device Description | Dual-Band Wireless-AC PCI-E Adapter |
| Responsible Party | Jackson Yen, Associate Vice President, jackson_yen@asus.com  , +886-2-28943447 |
| Test Firm | Warren Lin, DEKRA TESTING AND CERTIFICATION CO., LTD., warren.lin@dekra.com  , +886-3-582-8001 |
| TCB Email | TEI@TIMCOENGR.COM  |
| TCB Scope | A4: UNII devices & low power transmitters using spread spectrum techniques |
| Short-Term Confidentiality | No |
| Long-Term Confidentiality | Yes |
| Grant Deferral | No |
| Modular Equipment | Does not apply |
| Composite Device | Yes |
| Composite Part | No |
| Cognitive Radio | No |
| Authorization Waiver | No |
| Authorization Waiver Approved | No |
| Section 5301 Certification | Yes |
| Related OET Knowledge DataBase Inquiry | No |
| Grant Comments | Power listed is maximum combined output power conducted. Device operates with specific antennas in MIMO configurations as described in this filing. The antenna(s) used for this transmitter must be installed to provide a separation distance of at least 20 cm from all persons and must not transmit simultaneously with any other antenna or transmitter. Users and installers must be provided with antenna installation instructions and transmitter operating conditions for satisfying RF exposure compliance. This device has 20 and 40 MHz bandwidth modes. |
