FCC ID MSQX00BD
ASUS Phone
by ASUSTeK Computer Inc
Grantee Code: MSQ Product Code: X00BD
Latest application date: 2016-09-15
Device Images
FCC ID Device Details
Operating Frequencies
| Frequency Range | Application Purpose | Final Action Date |
|---|---|---|
| 2402-2480 MHz | Original Equipment | 2016-09-15 |
| 2402-2480 MHz | Original Equipment | 2016-09-15 |
| 824.2-848.8 MHz | Original Equipment | 2016-09-15 |
Exhibits
| Document | Type | Available | File |
|---|---|---|---|
| Users Manual | Users Manual | 2017-03-14 | PDF 1.1 MB |
| Internal Photos | Internal Photos | 2017-03-14 | PDF 3.7 MB |
| External Photos | External Photos | 2017-03-14 | PDF 1.3 MB |
| Label | ID Label/Location Info | 2016-09-15 | PDF 576.1 KB |
| Label Location | ID Label/Location Info | 2016-09-15 | PDF 56.6 KB |
| Test Setup Photos DSS | Test Setup Photos | 2017-03-14 | PDF 259.2 KB |
| Test Setup Photos DTS BLE | Test Setup Photos | 2017-03-14 | PDF 253.4 KB |
| Test Setup Photos DTS WLAN 4G | Test Setup Photos | 2017-03-14 | PDF 268.9 KB |
| Test Setup Photos HAC RF | Test Setup Photos | 2017-03-14 | PDF 148 KB |
| Test Setup Photos HAC T-Coil | Test Setup Photos | 2017-03-14 | PDF 149.8 KB |
| Test Setup Photos PCE | Test Setup Photos | 2017-03-14 | PDF 341.7 KB |
| Test Setup Photos RF Exposure | Test Setup Photos | 2017-03-14 | PDF 272.5 KB |
| Test Report DSS | Test Report | 2016-09-15 | PDF 2 MB |
| Test Report DTS BLE | Test Report | 2016-09-15 | PDF 2.2 MB |
| Test Report DTS WLAN 2.4G | Test Report | 2016-09-15 | PDF 3.1 MB |
| Test Report HAC RF Part 1 | Test Report | 2016-09-15 | PDF 5 MB |
| Test Report HAC RF Part 2 | Test Report | 2016-09-15 | PDF 5.8 MB |
| Test Report HAC RF Part 3 | Test Report | 2016-09-15 | PDF 1.7 MB |
| Test Report HAC T-Coil | Test Report | 2016-09-15 | PDF 2 MB |
| Test Report PCE | Test Report | 2016-09-15 | PDF 5.7 MB |
| Confidentiality Request Letter Short Term | Cover Letter(s) | 2016-09-15 | PDF 24.9 KB |
| Confidentiality Request Letter WWAN function | Cover Letter(s) | 2016-09-15 | PDF 21.3 KB |
| DOC Letter | Cover Letter(s) | 2016-09-15 | PDF 17 KB |
| Declaration Letter for Cell Phone Device | Cover Letter(s) | 2016-09-15 | PDF 11.9 KB |
| POA | Cover Letter(s) | 2016-09-15 | PDF 26.7 KB |
| RF Exposure Part 1 | RF Exposure Info | 2016-09-15 | PDF 5.6 MB |
| RF Exposure Part 2 | RF Exposure Info | 2016-09-15 | PDF 3.8 MB |
| Block Diagram Metadata only | Block Diagram | PDF 91.6 KB | |
| Schematics Metadata only | Schematics | PDF 2 MB | |
| Operational Description Metadata only | Operational Description | PDF 560.5 KB | |
| Parts List Metadata only | Parts List/Tune Up Info | PDF 84 KB | |
| Tune Up Procedure Metadata only | Parts List/Tune Up Info | PDF 70.7 KB |
Application Information
| Application ID | RAaQTizaATQZxoGxHJcp6g== |
|---|---|
| Final Action Date | 2016-09-15 |
| Application Purpose | Original Equipment |
| Applicant FRN | 0005821988 |
| Model | X00BD |
| Frequency Range | 2402-2480 MHz |
| Equipment Class | DTS - Digital Transmission System |
| Device Description | ASUS Phone |
| Responsible Party | Jackson Yen, Associate Vice President, jackson_yen@asus.com  , +886-2-28943447 |
| Test Firm | Michael Lin, SPORTON International(KunShan) Inc, Michael@sporton.com.tw  , 86-512-57900158 |
| TCB Email | TEI@TIMCOENGR.COM  |
| TCB Scope | A4: UNII devices & low power transmitters using spread spectrum techniques |
| Short-Term Confidentiality | Yes |
| Short-Term Confidentiality Date | 03/14/2017 |
| Long-Term Confidentiality | Yes |
| Grant Deferral | No |
| Modular Equipment | Does not apply |
| Composite Device | Yes |
| Composite Part | No |
| Cognitive Radio | No |
| Authorization Waiver | No |
| Authorization Waiver Approved | No |
| Section 5301 Certification | Yes |
| Related OET Knowledge DataBase Inquiry | No |
| Grant Comments | Output Power listed is the conducted output power. SAR compliance for body-worn operating configurations is limited to the specific body-worn accessories, such as belt-clips and holsters, tested for this filing, or belt-clips and holsters that have no metallic components in the assembly and cause the device to operate with the minimum separation distance of 1.0-cm, as described in this filing. End-users must be informed of the body-worn operating requirements for satisfying RF exposure compliance. The highest reported SAR for head, body-worn accessory, product specific, and simultaneous transmission conditions are 0.78 W/kg, 0.11 W/kg, 0.11 W/kg, and 1.39 W/kg, respectively. This device supports 20 MHz bandwidth modes. |
Applications
| Application ID | Date | Purpose |
|---|---|---|
| RAaQTizaATQZxoGxHJcp6g== | 2016-09-15 | Original Equipment |
| KmFNra8BbrnnI7Dq+DzdLg== | 2016-09-15 | Original Equipment |
| G2ypImQgk6Cb/J3zmSh7Mw== | 2016-09-15 | Original Equipment |
Equipment Authorization
| Frequency | Output | Tolerance | Emission | Rules | Grant Notes |
|---|---|---|---|---|---|
| 824.2-848.8 MHz | 1.0069 | 0.0191ppm | 243KGXW | 22H | HC |
| 824.2-848.8 MHz | 0.2 | 0.0096ppm | 246KG7W | 22H | HX |
| 826.4-846.6 MHz | 0.0879 | 0.0167ppm | 4M17F9W | 22H | HC |
| 1850.2-1909.8 MHz | 1.074 | 0.0144ppm | 242KGXW | 24E | HC |
| 1850.2-1909.8 MHz | 0.3206 | 0.0186ppm | 244KG7W | 24E | HX |
| 1852.4-1907.6 MHz | 0.2188 | 0.0064ppm | 4M17F9W | 24E | HC |
| 2402-2480 MHz | 0.0091000 | 15C | |||
| 2402-2480 MHz | 0.0009 | 15C | |||
| 2412-2462 MHz | 0.1928 | 15C | HC |
Grants
TCB Grant - Application RAaQTizaATQZxoGxHJcp6g==
| TCB | GRANT OF EQUIPMENT AUTHORIZATION |
TCB |
| Certification | ||
| Issued Under the Authority of the | ||
| Federal Communications Commission | ||
| By: |
|
Timco Engineering, Inc. 849 NW State Road 45 Newberry, FL 32669 |
Date of Grant: 09/15/2016 Application Dated: 09/15/2016 |
| ASUSTeK Computer Inc |
| 1F, No. 15, Lide Rd. |
| Beitou, Taipei, 112 Taiwan |
| Attention: Jackson Yen , Associate Vice President |
| NOT TRANSFERABLE |
| EQUIPMENT AUTHORIZATION is hereby issued to the named GRANTEE, and is VALID ONLY for the equipment identified hereon for use under the Commission's Rules and Regulations listed below. |
| FCC IDENTIFIER: | MSQX00BD |
| Name of Grantee: | ASUSTeK Computer Inc |
| Equipment Class: | Digital Transmission System |
| Notes: | ASUS Phone |
| Grant Notes | FCC Rule Parts | Frequency Range (MHZ) | Output Watts | Frequency Tolerance | Emission Designator |
| HC | 15C | 2412.0 - 2462.0 | 0.1928 | ||
| 15C | 2402.0 - 2480.0 | 0.0009 |
| Output Power listed is the conducted output power. SAR compliance for body-worn operating configurations is limited to the specific body-worn accessories, such as belt-clips and holsters, tested for this filing, or belt-clips and holsters that have no metallic components in the assembly and cause the device to operate with the minimum separation distance of 1.0-cm, as described in this filing. End-users must be informed of the body-worn operating requirements for satisfying RF exposure compliance. The highest reported SAR for head, body-worn accessory, product specific, and simultaneous transmission conditions are 0.78 W/kg, 0.11 W/kg, 0.11 W/kg, and 1.39 W/kg, respectively. This device supports 20 MHz bandwidth modes. |
| HC: | This equipment complies with the hearing aid compatibility technical requirements of Section 20.19 of the rules. |
