PR1103 AM/FM WEATHER TV BAND RADIO Block Diagram - FCC ID MU4PR1103

FCC ID MU4PR1103

BLOCK DIAGRAM

AM/FM WEATHER TV BAND RADIO

by Lasco Industries Limited

Document preview loads when visible.

Document Details

FCC IDMU4PR1103
Document ID512601
Document TypeBlock Diagram
DescriptionBLOCK DIAGRAM
ApplicantLasco Industries Limited
Equipment ClassAM/FM WEATHER TV BAND RADIO
Product CodePR1103
Application IDUzbWilrJHqBQpC/qiP2UYA==
Application PurposeOriginal Equipment
Application Date2005-02-04
Frequency Range162.4-162.6 MHz
FRN0011456936
Test FirmSGS IECC Limited
Certified ByFRANKIE LEE MARKETING MANAGER
Short-Term ConfidentialityNo
Long-Term ConfidentialityNo
Grant DeferralNo
Modular EquipmentDoes not apply
Composite DeviceNo
Composite PartNo
Submitted2005-02-07
Available2005-02-04
Created2005-01-31
Modified2005-01-31
Pages1
File TypeAdobe Acrobat PDF
File Size32759
File SHA-25688d004fe04bc428becc0a674a10e0977ecb49e4df1f31b3fad4add71e0591917
PDF Metadata ProducerAcrobat 5.0 Scan Plug-in for Windows Acrobat 5.0 Scan Plug-in for Windows
FCC.gov SourcesFCC.gov 512601
