FCC ID MZR4401
4401
by Master Lock Company
Grantee Code: MZR Product Code: 4401
Latest application date: 2015-09-17
Device Images
FCC ID Device Details
Operating Frequencies
| Frequency Range | Application Purpose | Final Action Date |
|---|---|---|
| 2402-2480 MHz | Original Equipment | 2015-09-17 |
Exhibits
| Document | Type | Available | File |
|---|---|---|---|
| Exhibit D Users Manual per 2 1033 b3 | Users Manual | 2015-09-17 | PDF 173.5 KB |
| Exhibit C Internal Photographs per 2 1033 b7 | Internal Photos | 2015-09-17 | PDF 337.1 KB |
| Exhibit C External Photographs per 2 1033 b7 | External Photos | 2015-09-17 | PDF 243.6 KB |
| Exhibit A ID Label and location per 2 1033 b7 | ID Label/Location Info | 2015-09-17 | PDF 180.9 KB |
| Exhibit C RE Test Setup photographs | Test Setup Photos | 2015-09-17 | PDF 160.7 KB |
| Exhibit E Test Measurement Report per 2 1033 b6 | Test Report | 2015-09-17 | PDF 2.4 MB |
| Cover Letter Requesting Confidentiality | Cover Letter(s) | 2015-09-17 | PDF 488.9 KB |
| Exhibit B Block Diagram per 2 1033 b5 Metadata only | Block Diagram | PDF 73.9 KB | |
| Exhibit B Schematics per 2 1033 b5 Metadata only | Schematics | PDF 624.1 KB | |
| Exhibit B Operational Description per 2 1033 b4 Metadata only | Operational Description | PDF 248.3 KB | |
| Misc Parts List Exhibits Metadata only | Parts List/Tune Up Info | PDF 86.1 KB |
Application Information
| Application ID | 3OF9MMQxu02iV4gI3AMMBQ== |
|---|---|
| Final Action Date | 2015-09-17 |
| Application Purpose | Original Equipment |
| Applicant FRN | 0021474101 |
| Model | 4401 |
| Frequency Range | 2402-2480 MHz |
| Equipment Class | DTS - Digital Transmission System |
| Device Description | 4401 |
| Responsible Party | Sidnei Stifelmann, Global Product Regulatory Compliance Manager, sstifelmann@mlock.com  , 847-250-7896 |
| Technical Contact | Mike Jonely, Master Lock Company, mjonely@mlock.com , 4147666250 |
| Test Firm | Kevin Halpin, Elite Electronic Engineering Inc., khalpin@elitetest.com  , 630-495-9770 |
| TCB Email | decrowder@elitetest.com |
| TCB Scope | A4: UNII devices & low power transmitters using spread spectrum techniques |
| Short-Term Confidentiality | No |
| Long-Term Confidentiality | Yes |
| Grant Deferral | No |
| Modular Equipment | Does not apply |
| Composite Device | No |
| Composite Part | No |
| Cognitive Radio | No |
| Authorization Waiver | No |
| Authorization Waiver Approved | No |
| Section 5301 Certification | Yes |
| Related OET Knowledge DataBase Inquiry | No |
| Grant Comments | Power Output listed is EIRP. The antenna(s) used for this transmitter must not be collocated or operating in conjunction with any other antenna or transmitter within a host device, except as described in this filing or in accordance with FCC multi-transmitter product procedures. End-users and installers must be provided with antenna installation instructions and transmitter operating conditions for satisfying RF exposure compliance. |
Applications
| Application ID | Date | Purpose |
|---|---|---|
| 3OF9MMQxu02iV4gI3AMMBQ== | 2015-09-17 | Original Equipment |
Equipment Authorization
| Frequency | Output | Rules |
|---|---|---|
| 2402-2480 MHz | 0.0000003 | 15C |
Grants
TCB Grant - Application 3OF9MMQxu02iV4gI3AMMBQ==
| TCB | GRANT OF EQUIPMENT AUTHORIZATION |
TCB |
| Certification | ||
| Issued Under the Authority of the | ||
| Federal Communications Commission | ||
| By: |
|
Elite Electronic Engineering, Inc. 1516 Centre Circle Downers Grove, IL 60515 |
Date of Grant: 09/17/2015 Application Dated: 09/17/2015 |
| Master Lock Company |
| P.O. Box 927 |
| 6744 South Howell Avenue, Oak Creek, WI 53154 |
| Milwaukee, WI 53154 |
| Attention: Sidnei Stifelmann , Global Product Regulatory Compliance Manager |
| NOT TRANSFERABLE |
| EQUIPMENT AUTHORIZATION is hereby issued to the named GRANTEE, and is VALID ONLY for the equipment identified hereon for use under the Commission's Rules and Regulations listed below. |
| FCC IDENTIFIER: | MZR4401 |
| Name of Grantee: | Master Lock Company |
| Equipment Class: | Digital Transmission System |
| Notes: | 4401 |
| Grant Notes | FCC Rule Parts | Frequency Range (MHZ) | Output Watts | Frequency Tolerance | Emission Designator |
| 15C | 2402.0 - 2480.0 | 3E-7 |
| Power Output listed is EIRP. The antenna(s) used for this transmitter must not be collocated or operating in conjunction with any other antenna or transmitter within a host device, except as described in this filing or in accordance with FCC multi-transmitter product procedures. End-users and installers must be provided with antenna installation instructions and transmitter operating conditions for satisfying RF exposure compliance. |
EAS Grant - Application 3OF9MMQxu02iV4gI3AMMBQ==
| COPY |
FEDERAL COMMUNICATIONS COMMISSION WASHINGTON, D.C. 20554 GRANT OF EQUIPMENT AUTHORIZATION |
COPY |
| Certification |
|
Master Lock Company P.O. Box 927 6744 South Howell Avenue, Oak Creek, WI 53154 Milwaukee, WI 53154 United States |
Date of Grant: 09/17/2015 Application Dated: 09/17/2015 |
| Attention: Sidnei Stifelmann , Global Product Regulatory Compliance Manager |
| NOT TRANSFERABLE |
| EQUIPMENT AUTHORIZATION is hereby issued to the named GRANTEE, and is VALID ONLY for the equipment identified hereon for use under the Commission's Rules and Regulations listed below. |
| FCC IDENTIFIER: | MZR4401 |
| Name of Grantee: | Master Lock Company |
| Equipment Class: | Digital Transmission System |
| Notes: | 4401 |
| Modular Type: | Does not apply |
| Grant Notes | FCC Rule Parts | Frequency Range (MHZ) | Output Watts | Frequency Tolerance | Emission Designator |
| 15C | 2402.0 - 2480.0 | 3E-7 |
| Power Output listed is EIRP. The antenna(s) used for this transmitter must not be collocated or operating in conjunction with any other antenna or transmitter within a host device, except as described in this filing or in accordance with FCC multi-transmitter product procedures. End-users and installers must be provided with antenna installation instructions and transmitter operating conditions for satisfying RF exposure compliance. |
