SG402 3G Smart Phone Teardown Internal Photos - FCC ID N2GSG402

FCC ID N2GSG402

Internal Photos

3G Smart Phone

by DOPPIO MOBILE INTERNATIONAL LIMITED

Document preview loads when visible.

Document Details

FCC IDN2GSG402
Document ID3261144
Document TypeInternal Photos
DescriptionInternal Photos
ApplicantDOPPIO MOBILE INTERNATIONAL LIMITED
Equipment Class3G Smart Phone
Product CodeSG402
Application IDA+4TzvRdbLLg3h0sDZnYQg==
Application PurposeOriginal Equipment
Application Date2017-01-17
Frequency Range1850.2-1909.8 MHz
FRN0021700281
Test FirmWaltek Services(Shenzhen) Co., Ltd.
Certified ByPhilo zhong Manager
Short-Term ConfidentialityNo
Long-Term ConfidentialityNo
Grant DeferralNo
Modular EquipmentDoes not apply
Composite DeviceYes
Composite PartNo
Submitted2017-01-17
Available2017-01-17
Created2017-01-09
Modified2017-01-09
Pages4
File TypeAdobe Acrobat PDF
File Size787905
File SHA-256a027e6b5baa93f55c83ea8ba9c2eafb7b917e2eb68440d444e930ec74099f322
PDF Metadata AuthorAdministrator
PDF Metadata ProducerAdministrator Microsoft? Office Word 2007
FCC.gov SourcesFCC.gov 3261144, FCC.gov 3261112, FCC.gov 3261070
