AC420T 900MHz Transmitter Block Diagram - FCC ID N7TAC420-T

FCC ID N7TAC420-T

Block Diagram

900MHz Transmitter

by Angelcare Monitors Inc.

Document preview loads when visible.

Document Details

FCC IDN7TAC420-T
Document ID771076
Document TypeBlock Diagram
DescriptionBlock Diagram
Document TitleAC_BLK
ApplicantAngelcare Monitors Inc.
Equipment Class900MHz Transmitter
Product CodeAC420T
Application IDLcJAl59xn9dI+K9ctaFEeA==
Application PurposeOriginal Equipment
Application Date2007-03-22
Frequency Range926-927.6 MHz
FRN0006356315
Test FirmIntertek Testing Services Hong Kong
Certified ByKenneth Lam Assistant Supervisor
Short-Term ConfidentialityNo
Long-Term ConfidentialityNo
Grant DeferralNo
Modular EquipmentDoes not apply
Composite DeviceNo
Composite PartYes
Submitted2007-03-22
Available2007-03-22
Created2007-03-22
Modified2007-03-12
Pages2
File TypeAdobe Acrobat PDF
File Size117440
File SHA-25616418fdd88b7d79cb7e61e880887f7393d134f875e64f58aba8a321fd4d75da9
PDF Metadata Authorcmy
PDF Metadata CreatorPScript5.dll Version 5.2
PDF Metadata ProducerGNU Ghostscript 7.06
FCC.gov SourcesFCC.gov 771076
