FCC ID NBG01RS54A
Test_Setup_Photos
Advanced Driver Assistance System
Document preview loads when visible.
Document Details
| FCC ID | NBG01RS54A |
|---|---|
| Document ID | 5590233 |
| Document Type | Test Setup Photos |
| Description | Test_Setup_Photos |
| Document Title | Test Report No.: 2-___a/__ |
| Applicant | HELLA GmbH & Co. KGaA |
| Equipment Class | Advanced Driver Assistance System |
| Product Code | 01RS54A |
| Application ID | UqrVEWoK1LrlG7AKpqzxlA== |
| Application Purpose | Original Equipment |
| Application Date | 2021-12-17 |
| Frequency Range | 76000-77000 MHz |
| FRN | 0007615487 |
| Test Firm | CETECOM GmbH |
| Certified By | Bernhard Hlubek |
| Short-Term Confidentiality | Yes |
| Long-Term Confidentiality | No |
| Short-Term Confidentiality Date | 06/15/2022 |
| Grant Deferral | No |
| Modular Equipment | Does not apply |
| Composite Device | No |
| Composite Part | No |
| Submitted | 2021-12-17 |
| Available | 2022-06-15 |
| Created | 2021-12-17 |
| Modified | 2021-12-17 |
| Pages | 7 |
| File Type | Adobe Acrobat PDF |
| File Size | 1183467 |
| File SHA-256 | dfb23b28f24b2abd12f1ff013db5efdd8b78f7da30ebcfe10ec64cdac449a8b3 |
| PDF Metadata Author | Lorenz, Christian [CETECOM] |
| PDF Metadata Producer | Microsoft® Word 2016 Lorenz, Christian [CETECOM] |
| FCC.gov Sources | FCC.gov 5590233 |
