4B838 Remote Transmitter Block Diagram - FCC ID NBQ4B838

FCC ID NBQ4B838

Block Diagram

Remote Transmitter

by Secure Pro Holdings Limited

Document preview loads when visible.

Document Details

FCC IDNBQ4B838
Document ID19467
Document TypeBlock Diagram
DescriptionBlock Diagram
ApplicantSecure Pro Holdings Limited
Equipment ClassRemote Transmitter
Product Code4B838
Application ID71VQSiVDcbREIRb/0JK60g==
Application PurposeOriginal Equipment
Application Date1999-03-12
Frequency Range390-440 MHz
FRN9999999999
Test FirmIntertek Testing Services Hong Kong
Certified ByMr Wilbur Ng Assistant Manager
Short-Term ConfidentialityNo
Long-Term ConfidentialityNo
Grant DeferralNo
Modular EquipmentDoes not apply
Composite DeviceNo
Composite PartYes
Submitted1999-01-14
Available1999-03-12
Created1999-01-06
Modified1999-01-06
Pages1
File TypeAdobe Acrobat PDF
File Size27057
File SHA-256e040fdc6440c8ff307c6275d4ca9126edf6da3d1272ba54df866d38efe4f6848
PDF Metadata ProducerAcrobat 3.0 Scan Plug-in Acrobat 3.0 Scan Plug-in
FCC.gov SourcesFCC.gov 19467
