T180AC Lighting Controller Label Diagram - FCC ID NCG-T180AC

FCC ID NCG-T180AC

Label Material

Lighting Controller

by Cooper Lighting

Document preview loads when visible.

Document Details

FCC IDNCG-T180AC
Document ID343614
Document TypeID Label/Location Info
DescriptionLabel Material
ApplicantCooper Lighting
Equipment ClassLighting Controller
Product CodeT180AC
Application IDy7v3/pNXmRNAm7Y+wT7Ecg==
Application PurposeOriginal Equipment
Application Date2003-07-29
Frequency Range315 MHz
FRN0009217910
Test FirmEMC Testing Laboratories, Inc.
Certified ByKent Stewart
Short-Term ConfidentialityNo
Long-Term ConfidentialityNo
Grant DeferralNo
Modular EquipmentDoes not apply
Composite DeviceNo
Composite PartNo
Submitted2003-07-29
Available2003-07-29
Created2003-07-15
Modified2003-07-15
Pages1
File TypeAdobe Acrobat PDF
File Size31218
File SHA-2563aea5f6b301739f1bb94b2ca8effd0ee36658816c6796a3f0b649cbdebe258df
PDF Metadata ProducerAcrobat 5.0 Scan Plug-in for Windows Acrobat 5.0 Scan Plug-in for Windows
FCC.gov SourcesFCC.gov 343614
