9574761501 AC1200 Dual-Band Wireless LAN... - FCC ID NDD9574761501
FCC ID NDD9574761501
Test Setup Photos
AC1200 Dual-Band Wireless LAN Repeater
Document preview loads when visible.
Document Details
| FCC ID | NDD9574761501 |
|---|---|
| Document ID | 2706167 |
| Document Type | Test Setup Photos |
| Description | Test Setup Photos |
| Document Title | FCC 47 CFR PART 15 SUBPART E |
| Applicant | Edimax Technology Co Ltd |
| Equipment Class | AC1200 Dual-Band Wireless LAN Repeater |
| Product Code | 9574761501 |
| Application ID | 9/ZEs7GMpjwtjh4DYAbDlA== |
| Application Purpose | Original Equipment |
| Application Date | 2015-08-06 |
| Frequency Range | 5180-5240 MHz |
| FRN | 0008842908 |
| Test Firm | Compliance Certification Services Inc. |
| Certified By | Tracy Cheng Section Manager |
| Short-Term Confidentiality | No |
| Long-Term Confidentiality | No |
| Grant Deferral | No |
| Modular Equipment | Does not apply |
| Composite Device | Yes |
| Composite Part | No |
| Submitted | 2015-08-06 |
| Available | 2015-08-06 |
| Created | 2015-07-23 |
| Modified | 2015-07-23 |
| Pages | 3 |
| File Type | Adobe Acrobat PDF |
| File Size | 533714 |
| File SHA-256 | 054b2056e23e004a26e5da03b722b5cfc02b2feee8db2afdd8a238750a621feb |
| PDF Metadata Author | amy.lee |
| PDF Metadata Producer | amy.lee Microsoft® Word 2010 |
| FCC.gov Sources | FCC.gov 2706167 |
