CCE480N4 UHF Signal Enhancer Block Diagram - FCC ID NEOCCE-480N4
FCC ID NEOCCE-480N4
Block Diagram Updated
UHF Signal Enhancer
Document preview loads when visible.
Document Details
| FCC ID | NEOCCE-480N4 |
|---|---|
| Document ID | 343747 |
| Document Type | Block Diagram |
| Description | Block Diagram Updated |
| Applicant | PBE Europe Ltd. trading as Axell Wireless |
| Equipment Class | UHF Signal Enhancer |
| Product Code | CCE480N4 |
| Application ID | 3eHFrvAS4nCLh+cY/xFGig== |
| Application Purpose | Original Equipment |
| Application Date | 2003-02-24 |
| Frequency Range | 486.063-486.563 MHz |
| FRN | 0007840820 |
| Test Firm | Nemko Dallas, Inc. |
| Certified By | Tom Tidwell Frontline Manager |
| Short-Term Confidentiality | No |
| Long-Term Confidentiality | No |
| Grant Deferral | No |
| Modular Equipment | Does not apply |
| Composite Device | No |
| Composite Part | Yes |
| Submitted | 2003-07-29 |
| Available | 2003-02-24 |
| Created | 2003-07-29 |
| Modified | 2003-07-29 |
| Pages | 1 |
| File Type | Adobe Acrobat PDF |
| File Size | 261319 |
| File SHA-256 | f4364ad6c7d5c1c7d350e4fcbcb3c7859d6ac9ab171ecaa2ea7aefa607f5328a |
| PDF Metadata Producer | Adobe PDF Library 4.0 |
| FCC.gov Sources | FCC.gov 343747 |
